Energy Saving Sand Grinding Miller With ISO Certificate
- 120 Set / Sets per Month
- Tianjin Qingdao Shanghai etc
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Ball Mill | Motor Type: | AC Motor |
Power(W): | 18.5-800kw | Capacity(t/h): | 0.3-90 | Place of Origin: | Henan, China |
Brand Name: | Weilite | Model Number: | MQJ Series | Dimension(L*W*H): | 1950x1200x1000mm |
Weight: | 4.6-137 Tons | Certification: | ISO9001:2000, ISO9001:2000 | Warranty: | 1 year, 1 year(excluding wearing parts) |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1.Sand Grinding Miller Introduction
Sand grinding miller is mainly used for sand, in the process of aerated concrete production is mainly used to grind sand or lime piece of equipment, it is different depending on the type of technology used in the different, need to use in the production of sand aerated block two ball mill, a used for wet ball mill, grinding sand is used for grinding lime pieces a day, dry type ball mill.In the fly ash aerated concrete block production with one, is used for grinding lime pieces.
2.Sand Grinding Miller Working Theory
The main body of the iron ore powder making machine is a low-speed rotary cylinder mounted on two large bearings horizontally. Theiron ore powder making machine’s rotary part is driven at reducing speed by motor through speed reducer and gear weheel or by low-speed synchronous motor through gearwheel. Inside the cylinder feed proper grinding medium-steel balls. The medium will be lifted to certain height under the action of centrifugal force and friction and drop or fall. The material to grind is fed to the cylinder in succession and crushed by grinding medium, then discharged through overflow and continual feeding force, and enter the next procedure.
3.More Sand Grinding Miller Pictures
1).sand grinding miller In Workshop
2).sand grinding miller Installation Pictures
4.Sand Grinding Miller Technical Datas
Type | Shaft Rotation Speed | Ball Load (t) | Feeding Size | Discharging Size | Capacity (t/h) | Motor Power | Weight(t) |
MQJ900×1800 | 38 | 1.5 | ≤20 | 0.075-0.89 | 0.65-2 | 18.5 | 3.6 |
MQJ900×3000 | 38 | 2.7 | ≤20 | 0.075-0.89 | 1.1-3.5 | 22 | 4.6 |
MQJ1200×2400 | 32 | 3.8 | ≤25 | 0.075-0.6 | 1.5-4.8 | 45 | 12.5 |
MQJ1200×3000 | 32 | 5 | ≤25 | 0.074-0.4 | 1.6-5 | 45 | 12.8 |
MQJ1200×4500 | 32 | 7 | ≤25 | 0.074-0.4 | 1.6.5.8 | 55 | 13.8 |
MQJ1500×3000 | 27 | 8 | ≤25 | 0.074-0.4 | 2-5 | 90 | 17 |
MQJ1500×4500 | 27 | 14 | ≤25 | 0.074-0.4 | 3-6 | 110 | 21 |
MQJ1500×5700 | 27 | 15 | ≤25 | 0.074-0.4 | 3.5-8 | 132 | 24.7 |
MQJ1830×3000 | 24 | 11 | ≤25 | 0.074-0.4 | 4-10 | 180 | 28 |
MQJ1830×4500 | 25.4 | 15 | ≤25 | 0.074-0.4 | 4.5-12 | 155 | 32 |
MQJ1830×6400 | 24 | 23 | ≤25 | 0.074-0.4 | 6.5-15 | 210 | 34 |
MQJ1830×7000 | 24 | 25 | ≤25 | 0.074-0.4 | 7.5-17 | 245 | 36 |
MQJ2100×3000 | 23.7 | 15 | ≤25 | 0.074-0.4 | 6.5-36 | 210 | 34 |
MQJ2100×4500 | 23.7 | 24 | ≤25 | 0.074-0.4 | 8-43 | 245 | 42 |
MQJ2100×7000 | 23.7 | 26 | ≤25 | 0.074-0.4 | 8-48 | 280 | 50 |
MQJ2200×4500 | 21.5 | 27 | ≤25 | 0.074-0.4 | 9-45 | 280 | 48.5 |
MQJ2200×6500 | 21 | 31 | ≤25 | 0.074-0.4 | 14-26 | 380 | 52.8 |
MQJ2200×7000 | 21.7 | 35 | ≤25 | 0.074-0.4 | 15-28 | 380 | 54 |
MQJ2200×7500 | 21.7 | 35 | ≤25 | 0.074-0.4 | 15-30 | 380 | 56 |
MQJ 2400×4500 | 21 | 30 | ≤25 | 0.074-0.4 | 8.5-60 | 320 | 65 |
MQJ 2700×4000 | 20.7 | 40 | ≤25 | 0.074-0.4 | 12-80 | 400 | 94 |
MQJ 2700×4500 | 20.7 | 48 | ≤25 | 0.074-0.4 | 12-90 | 430 | 102 |
MQJ 3200×4500 | 18 | 65 | ≤25 | 0.074-0.4 | Set According to the Technology | 800 | 137 |
5.Sand Grinding Miller Packaging And Shipping
6.Our Services For Sand Grinding Miller
a). If any interest in our sand grinding miller, please feel free to contact me and let me know your requirement on capacity and feeding and discharging material size.
b). We are professional machine manufacturer, we will help to choose the most suitable machine for you.
c). Quality Commitment: Quality Warranty, Grantee Period: 1 year. Supply wearing parts with favorable price and long term after-sales service.
d). If you need, we will dispatch professional engineer for installation, trail and worker training.
7.About Us--Zhengzhou Weilite Machinery
Zhengzhou Weilite Machinery Equipment Co., Ltd is a manufacturer and exporter of mining machine in China. Our main products are crusher, grinding mill, dryer, briquette plant and so on. Welcome to visit and purchase from us!
8.FAQ About Sand Grinding Miller
1).What's the max. feeding material size for the sand grinding miller?
- Answer:25mm.If larger, we will need crusher.
2).What's the discharging material size for the sand grinding miller?
- Answer:Discharging material size varies from 125mesh to 325mesh.
3).What kind of material can be grinded by your sand grinding miller?
- Answer:Iron Ore,Cement Clinker, Coal,Gypsum,Steel Slag,Chrome Ore,etc.
4).Do you provide production line design service?
- Answer:Yes, we are professional machine manufacturer. So we can provide production line design service.
If any interest in our sand grinding miller, please contact me for details.
Tel:+86 (0)371 86687769
Cell Phone:+86 15639260372
Contact Name:Ivy Zhang
Skype:ivyzhang2421
