Wet High-intensity Magnetic Separator
Zhengzhou Weilite Machinery Co., Ltd. research and development production of magnetic separator for particle size less than 3mm magnetite, pyrrhotite, roasted ore, ilmenite and other materials wet magnetic separation, but also for coal, non-metallic minerals,building materials and other materials in addition to iron.
1)working principle
This series of briquette machine will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
Pictures at work
2) application
Beneficiation production line
3) advantages
1) simple structure,
2) the large capacity,
3) easy to operate,
4) easy to maintain.
part three: Main technical parameters
Type |
Magnetic Field Strength(gs) |
Capacity(t/h) |
Motor Power(kw) |
Machine Weight(kg) |
CTB600×1200 |
1450 |
8-15 |
1.5 |
910 |
CTB600×1800 |
1500 |
15-25 |
2.2 |
1340 |
CTB750×1800 |
1550 |
30-45 |
3 |
2050 |
CTB900×1800 |
1650 |
30-60 |
4 |
3000 |
CTB1050×2400 |
1650 |
60-95 |
5.5 |
5020 |
CTB1200×3000 |
1650 |
80-150 |
7.5 |
7800 |
CTB1500×3000 |
1650 |
120-200 |
11 |
9600 |
part five:Our service
(1) Pre-sale Service:
Suitable-design products and resonable price will be supplied to you to meet your need. We can also offer experiment to test the equipment that the customer need.
(2) After-sale Service:
On the spot guidance for installation by our engineers, and the buyer is responsible for the expense. We have a perfect after-sales service system and team with professional.
Zhengzhou Weilite Machinery Equipment Co.,Ltd. is a professional mining machine manufacturer, we also offers other machines for such as crusher, mixer, briquette machine,conveyor belts, etc. Website: /
1>How is the quality of your products?
- Our products are manufactured strictly according to national and international standard, and we take a test on every machine before delivery.
2>What guarantee do you provide?
- If products’ quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
3>How about price?
- Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that “ for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity”.
Note:
We can design the production line for you according to your requirments. If you need design service, pelase let us know your raw material size,finished products size and capacity.Our engineer will give you the best solution.
Tel:+86 (0)371 86687769
Contact Name:Ms. Sandy Shi
