1.Easy to operate, easy to change the screen mesh, easy to clean.
2.The screen net is hardly plugged by even the most difficultly screened materials.
3.Fully enclosed structure, automatic layout, more suitable for pipeline operations.
4.With small amplitude, high frequency, large-inclination structure, high efficiency, large capacity, long service life, low power consumption and noise.
5.Every part of the screen box used copper plate and section welded together.(part of the group between body are jointed by bolts)The overall stiffness is good,strong and reliable.
The motor make the exciter eccentric producing high-speed rotation through the triangle belt .The operation of the eccentric produce great centrifugal force ,exciting the screen box to do a certain amplitude circular motion .The materials on the sieve get the impulse from the screen box on the inclined screen surface to do continuous casting movement .During the process of encounter between materials and screen surface ,the granule smaller than the sieve will go through the sieve to achieve classification .
1) Chemical industry: resin pigment, medicine, grease, paint, palette, etc.
2) Abrasive material and ceramic industry: building sand, mica, alumina, abrasive, refractory material, slurry, etc.
3) Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
4) Paper-making industry: coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
5) Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide, etc.
6) Mechanical industry: casting sand, powder metallurgy, electromagnetic material and metal powder, etc.
Model | DZSF-520 | DZSF-525 | DZSF-1020 | DZSF-1025 | DZSF-1030 |
Dimension(mm) | 500*2000 | 500*2500 | 1000*2000 | 1000*2500 | 1000*3000 |
Granularity(mm) | 0.074-60 | 0.074-60 | 0.074-60 | 0.074-60 | 0.074-60 |
Speed(r/min) | 960 | 960 | 960 | 960 | 960 |
Amplitude | 2-6 | 2-6 | 2-6 | 2-6 | 2-6 |
Deck | 1-4 | 1-4 | 1-4 | 1-4 | 1-4 |
Power(kw) | 2*(0.37~0.75) | 2*(0.37~0.75) | 2*(0.37~0.75) | 2*(0.37~0.75) | 2*(0.37~0.75) |
Before Sales:
1> Accept customer consultation, according to the customer demand; determine the scale of factory management, providing solutions.
2> For customer training and technical personnel;
3> According to customer request, design and manufacture products;
4> The company sent engineering and technical personnel to the user scene, planning for the optimal design of the flow field, and the solutions;
5> For customers in relevant technical documents.
Medium-sales:
1> Acceptance of the product;
2> Assist client protocol construction scheme;
After-sales:
1> On-site training personnel;
2> Appoint special after-sale service staff, arrived at the scene guide clients installation and commissioning;
3> Regular visit customer, consult with the customer feedback, come true with the customer's two-way communication.
1.Trade Terms:FOB,CIF;
2.Payment:T/T,L/C,Western Union,Escrow;
3.Port: Shanghai;Qingdao;Guangzhou;
4.Delivery Time:15-20 working days after receiving your payment;
5.Packing: Standard export package;
6.Shipping:By sea,by air,and by rail
