Weilongda Spray Booth, WLD8400 CE Certificated Water Based Car Paint Booth, Car Painting House
- Guangzhou/Shanghai/Ningbo
- T/T Credit Card PayPal
You May Like
-
WLD9200 Spray Booth, CE Car Painting Room, Weilongda Spray Booth
-
WLD9000 Car Paint Equipment, Car Painting Equipment, Car Spray House
-
WLD9100 CE Spray Booth, Car Painting Cabin, Car Spray Booth
-
WLD9300 Best Quality Spray Booth, WLD9300 CE Certificated Luxury Water Based Paint Spray Booth, Car Spray Booth
-
Spraying Booth Auto Paint Room, Car Spray Booth, Auto Paint Booth
-
BTD9910 Car Painting Room, Car Accident Repair Equipment, Car Paint Equipment
Product Details
| Power | 21KW | External Size | 7mx5.45mx4m | |
| Internal Size | 6.9mx3.9mx2.8m | Voltage | 3Phase 380V/415V/220V,50Hz/60Hz etc | |
| Certification | CE | Place of Origin | Guangdong, China | |
| Brand Name | Weilongda | Model Number | WLD8400 | |
| No Load Speed | None |
Product Description
Weilongda Spray Booth, WLD8400 CE Certificated Water Based Car Paint Booth, Car Painting House, Car Painting Room, Car Spray Room, Car Spray House, Car Spray Cabin, cabina de pintura, cabine de pintura, semburan gerai, spuitcabine, kabina lakiernicza, stendat e llak, sproeikamer, Car Painting House, Car Painting Booth
WhatsApp/Mobile: +86-13738082939, Skype: wikimachine, Tel.: +86-571-82136157
Spray Booth Model: WLD8400
External Size:(mm) | 7000x5450x4000 | Front Door:(mm) Aluminum Frame 3000(w)x2750(h) |
Internal Size:(mm) | 6900x3900x2800 | Total Power:21KW |
Cabin System | Wallboard | Fire-retardant composite molding Sandwich style EPS (epispastics polystyrene) (Rock wool and PU are optional )50mm |
Basement | Powder coated Galvanized steel sheet and square steel pipe construction. Full grids,anti-rust and strong. The bearing capacity of driving grids and plates up to 1000 kg; Basement frame is assembly formed by corrosion | |
Door | 3 pieces of aluminum front doors. Size: 3000(w)*2750(h). 1 piece of emergency door. | |
Air Circulation System | Intake Fan | 2x4kw intake fan. BELIMO 20N electric damper. Siemens technology production, large air volume and low noise. |
Exhaust Fan | 1x5.5kw exhaust fan. Multi-layer fiberglass filter. Siemens technology production,large air volume and low noise. | |
Air Pipe | Made of Galvanized steel sheet consisted of 4 pieces of straight pipe 750*750*1000, and 1piece of elbow. | |
Water based system | 60 units ceiling nozzles with 3 sets of centrifugal fans and 2 sets of dryers inside the booth for drying Water Based Paint. Air Flow: 30000m3/h. Air Speed: 0.3-0.5m/s. | |
Filtering | Dual filtering structure. The primary filter can capture granules larger than10μm. Ceiling filter capture granules bigger than 5μm. The air cleanliness in the working environment can reach 98%. | |
Heating System | Burner | Italy Riello RG5S diesel burner, 260000Kcal/h. The heating time 4-5min (20-60°C) Max. temperature at 80°C. Fuel consumption is 4-5kg/ vehicle. |
Heat Exchanger | Made of stainless steel. The heat exchange rate reaches 85%. | |
Air make up cabinet | The surface plate is galvanized plate, rust force strong, beautiful; The frame is made of high-quality hot-dip galvanized sheet repressionr , anti-rust and strong, more durable than ordinary surface treatment, more beautiful, nodes with no damage spot, rigidity. | |
Oil tank support | Tank carefully made of high quality steel, the powder coating treatment, beautiful and durable. | |
Fume pipe | Fume pipe made of galvanized pipe, diameter of 190mm, 4 pieces of 1000mm long straight pipe, two 90 ° elbows. | |
Lighting System | Light tube | Ceiling light has 24 pieces of 36w lamps. Side light has 16 pieces of 36kw lamps. 900 Lux. the grade of lighting box’s dustproof and waterproof reach IP54 grade. |
Light box | Welded galvanized plate, by the spray treatment, stiffness, repeated disassembly easy deformation, surface brightness, color uniformity, | |
Filtering System | Primary filter | Grade G2 plate type fiber glass filter ; Dual filtering structure. The primary filter can capture granules larger than 10μm. |
Celing filter | EU5 grade high efficient filter ;Ceiling filter capture granules bigger than 5μm.The air cleanliness in the working environment can reaches 98%. | |
Floor filter | Multilayer glass Fiber. The air cleanliness in the working environment can reach 98%. | |
Ceiling filter support | made of tube steel frame, thickness of 1.2mm, epoxy powder coating, rust and strong, rigid, beautiful and durable, can be repeated disassembly,not easy to damage, easy to replace filter cotton. | |
Pollution Control System | Multi-layer fiberglass filter | |
Control System | Control panel | Standard control system |
Function | Painting, constant temperature painting , drying, lighting, painting time and drying time setting ;emergency stop switch, failure indication, over-temperature alarm indication |
Configuration:
Wallboard: Sandwich style EPS (epispastics polystyrene) 50mm thickness. Colorful steel skin boards 0.426mm thickness. Galvanized steel roof panel.
Basement: Galvanized steel sheet and square steel pipe construction. Whole grids with floor filter. Full ramps.
Door: 3 pcs of front doors with aluminum frame. Size: 3000(w) x 2750(h). 1 pc of emergency door.
Air Circulation System: 2x4kw intake fan, 1x5.5kw exhaust fan. BELIMO 20N electric damper.
Water Based Paint Drying System: 60 units ceiling nozzles with 3 sets of centrifugal fans and 2 sets of dryers
inside the booth for Water Based Paint.
Burner: Italy Riello RG5S diesel burner, 260000Kcal/h. The heating time 4-5min(20-60.C). Max. temperature
at 80.C. Fuel consumption is 5-6kg/vehicle.
Heat Exchanger: Made of stainless steel. The heat exchange rate reaches 85%.
Lighting System: Ceiling light has 24 pcs of 36w lamps. Side light has 16 pcs of 36w lamps. 900 Lux.
Air Purification: Dual filtering structure. The primary filter can capture granules larger than 10μm. Ceiling filter
capture granules bigger than 5μm. The air cleanliness in the working environment can reaches 98%.
Pollution Control System: Multi-layer fiberglass filter.
User Case
WhatsApp/Mobile: +86-13738082939, Skype: wikimachine, Tel.: +86-571-82136157
