cellular concrete block making machines DS8-15 automatic hydraulic brick making machine for sale

Specifications

automatic hydraulic brick making machine
1.ISO9001:2008 & CE
2.multi-purpose design
3.Adopt full program

cellular concrete block making machines DS8-15 automatic hydraulic brick making machine



Technical features of DS8-15 concrete block making machine



DS8-15 Block Making Machinery



1. Compatible with fixed standard brick, hollow block, brick and other concrete products;

2. Mandatory feeder to insure uniformity of material and consistent product strength;

3. Adopt full program adopt PLC control and intelligent man-machine interface dialogue system;

4. Reasonable distribution of vibration to increase the effect of vibrating speed.



DS8-15 Block Making Machinery:



Mandatory feeder: once fabric box arrives to the top of the mold box, the mixing fork starts stirring rapidly to insure uniformity of material, and insure consistent product strength.

2. Full program adopt PLC control and intelligent man-machine interface dialogue system: easy to achieve a random signal analysis, fault diagnosis and a variety of parameter settings to ensure the best effectiveness of the block machine.

3. Increase the effective work platform: the application of new vibration technologies makes our block machines work with a larger platform, which greatly raised the production efficiency.

4. Reasonable distribution of vibration: the adoption of the fuel tank will release mold box locked in vibration mode platform, equipped with special vibrator on pressure head to achieve the mold box and platform vibrating at same time, to increase the effect of vibrating speed. The rapid vibration make the concrete rapid-liquefaction and rapid-exhaust, to achieve the finish products high-density and high-strength.



Main technical parameters of DS8-15 block making machinery:



The largest machine dimensions (L×W×H) ---------------------------7200×2100×2825 (mm)

Rated pressure of hydraulic system-------------------------------------21Mpa

Main vibration form------------------------------------------------------- All vibration molded desk

Vibration frequency-------------------------------------------------------50~70Hz

Vibration acceleration-----------------------------------------------------10-15g

To adapt to the high brick-------------------------------------------------50-200mm

Bamboo Pallet size---------------------------------------------------------920×850×40mm

Molding cycle---------------------------------------------------------------15s

Machine power--------------------------------------------------------------36.8kw

Machine weight-------------------------------------------------------------11.8t



(Parameter is changed without prior notice.)
