NEW Roll to Roll Automatic Label Die Cutting Machine

NEW Roll to Roll Automatic Label Die Cutting Machine photo-1
US$ 1 - 1,111 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Letterpress
Place of Origin:
Zhejiang, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Letterpress
Place of Origin Zhejiang, China
Brand Name XH
Model Number MQ
Usage Paper Printer
Automatic Grade Automatic
Voltage 220V
Gross Power 2.2kw
Dimensions(L*W*H) 2800*1100*1600mm
Weight 1500kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

roll to roll Label die cutting in printing machine



Usage:
1.
It is used for cutting the plastic label on the electronic products and all kinds of adhesive tapes.

2.This machine adopts flat to flat platen,high accurate mould die cutting,label conveyor and sheeting controlled by micro-computer and touch screen ,two side of printed mark and longitudinal direction tracked by three photoelectric cell(web guide).Die cutting,rewind waste paper, sheeting can finish at one time.This machine and label slitter is necessary auxiliary machine for the flexo printing machine or continuous screen printing machine.


Specification:



Model No. MQ-320
Max web width 320mm
Max die cutting width 300mm
Max die cutting length 290mm
Unwinder diameter  500mm
Cutting speed 20-170times/ min
Precision ±0.1mm
Total power 2.2kw
Machine weight 1500kg
Machine dimension 2800x1100x1600mm







Remark:

Also you can choose the machine to be with inner attached material die cutting,delay roller hot stamping die cutting,laser holograph die cutting .
