Help CenterResidential 1KW Hybrid Wind Solar Power System
Related Products
-
2KVA Wind Solar Hybrid Power System for Home Quality ChoiceUS$ 4,750 - 6,060MOQ: 1 Set -
4KW Wind and Solar Hybrid Energy SystemUS$ 9,180 - 9,180MOQ: 1 Set
-
Cubic 400W Mobile Home Solar SystemUS$ 1,700 - 1,850MOQ: 1 Set
-
New Generation 1.5KW Complete Off Grid Mobile Solar Power System Quality ChoiceUS$ 4,700 - 5,100MOQ: 1 Set
-
Maintenance Free 500W Solar Energy System Quality ChoiceUS$ 1,150 - 1,260MOQ: 1 Set
GOOD NEWS: SAIAM has been verified as a gold supplier with TRADE ASSURANCE service, which means your purchase here directly through our web is perfectly secured by Alibaba. You're highly recommended to order via TRADE ASSURANCE!
To know more about Alibaba TRADE ASSURANCE, please CLICK HERE
OVERALL:
SAIAM H100 hybrid wind solar power system is a plug & play generator.
Its monthly power output can reach 216KWh under the common average wind speed of 6m/s and average daily solar radiation time of 5.5 hours.
Featuring convenience of all-in-one and plug & play design, super high inversion efficiency up to over 95%, and triple inputs (solar & wind & grid/disel generator) availability, this product could be a very capable power supply for residential and commercial use!
If you're an end user, it is a perfect off-grid solution helps you save money from paying electric bills. If you're to resell it in your market, it will bring you a great sale increasement of millions of dollars in the coming few years!
Innovative design and CE approved quality ensure excellent experience!
FEATURE:
♦ Minimum installation needed and maintainance free
♦ System kits & control panel integrated within a compact cube
♦ NSK bearing used on the wind turbine
♦ Controller-inverter integrated kit ensures the high conversion efficiency of 95%
♦ Long lifespan
PHOTOGRAPHIC SHOW:
SPECIFICATION:
| H100 Overall Tech Specification | |
PV Power |
500W |
Number of PV Modules |
2*250W |
Rated Wind Power |
500W |
Number of Wind Generator |
1*500W HAWT |
Inverter Power |
1600W |
Batteries |
4pcs 6V 225A lead acid battery |
Battery Capacity |
5400W |
Case Dimension |
49*49*90cm |
Case Net Weight |
130kg |
Total Net Weight |
225kg |
| Solar Cube Tech Specification (M50) | |
| PV Power (Poly) | 500W |
| Inverter Power | 800W |
| Battery | 2pcs 6V 225Ah |
| Battery Capacity | 2640W (24V 225Ah) |
| Case Dimension | 49*49*57cm |
| Case Weight | 130kg |
| Total Weight (Case & panels) | 175kg |
| Optional Tweaks |
DC Output 5V 12V AC Output 110V 60Hz Mounting systems for solar panels Remote Monitor Control System Add Recharge from Wind Turbine |
Wind Turbine Tech Specification (SA-500W) | |
Performance | |
Rated power |
500W @8.8m/s |
Peak power |
780W |
Start-up wind speed |
3m/s |
Cut-in wind speed |
3.5m/s |
Survival wind speed |
35m/s |
Rotor | |
Rotor diameter |
2.5m |
Swept area |
4.9m2 |
Blade |
3pcs reinforced fiber glass |
Blade length |
119cm |
Shell material |
Aluminum Alloy |
Rated RPM |
400 |
Net weight |
45kg |
Others | |
Generator type |
3-phase AC PMG |
Speed regulation & protection |
Yawing + electromagnetic brake |
Controller rated voltage |
DC 12V/24V |
Suggested battery capacity |
2pcs 200AH/12VDC |
Suggested tower |
6m guyed cable tower |
Working temperature |
-40 - 60°C |
Power curve | |
| |
| SAIAM H100 Packing | |
| Packing type | 3 Plywood cases |
| Carton dimension | 60*60*62cm, 172*112*10cm, 142*52*37cm |
| Gross weight | 320kg |
| Loadability | 40sets/20'GP |
| |
Tips:
Sample order of H100 is acceptable, it is recommended to be delivered via LCL sea shipping. Please contact us to get the detailed suggestion on delivery.
| ||||
|
|
|
|
|
QUALITY CONTROL:
Q: How to place order via TRADE ASSURANCE?
A: On the top of this page, please click "Start Order" button.
Q: Does the price of SA-500W listed above include the charge controller and others? If not, where can I purchase the controller and inverter, etc.?
A: The listed price of is for wind turbine only (generator + blades), not including controller, inverter and other parts. Please contact us for the controller, inverter and other system parts for on-grid/off-grid application.
Q: What is the working voltage of SA-500W for my battery bank or grid utility?
A: Please find our recommended working voltage for SA-500W below:
SA-500W: 12V/24V(off grid)/220V(on grid)
Q: What thickness of pole shall I use for SA-500W and what would be the height approximately of the section that we would add on to your unit?
A: We recommend you use 3mm-5mm thickness, 6-12m height guyed cable tower or 5mm-8mm thickness, 6-15m height free standing tower for our HAWT 500W-10KW. Please contact us to get more tower information.
Q: How do your HAWTs realize the security protection during heavy winds?
A: Multi-protection ensure sour HAWTs' speed regulation and protection during high winds: yawing + electromagnetic brake(by controller) + manual brake(available on HAWT 5KW and 10KW models).
