4ch DVR

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Bellsent
Model Number	BE-DVR7604

Stand-Alone DVR, H.264 Compression (ASIC)
High quality video Display : NTSC (720x480),
PAL (704x576) real time display

FEATURES:

• Stand-Alone DVR, H.264 Compression (ASIC)

• High quality video Display : NTSC (720x480),

PAL (704x576) real time display

• Multiple Recording/ Search Categories:

Date/Time, Event, Manual, Schedule,alarm, motion detection

• Real time recording support:

120 Fps for NTSC for playback image (100 Fps for PAL)

• 4ch Video recording at the same time

• Pentaplex: Live, Record, Playback, Back-up and Network at the same time

• Backup: USB 2.0 and NET backup supported

• PTZ camera control in local and remote area with 256 positions cruise

Network Viewer

• Static, Dynamic IP and DDNS , Support Internet Explorer and special client software

• Remote Live Monitoring, file searching, Backup, Playback

• Remote Configuration, Firmware Upgrade

• Mobile monitoring (3G) and E-mail notification

Items	Specifications
Model Name	DVRBE-7604H
Compression Standard	H.264 ( ASIC )
Resolution	Preview resolution: 704 x 576 ( PAL ) , 720 x 480 ( NTSC ) Playback resolution: 1 x D1 + 3 x CIF Frames: 1F/S ~ 30F/S (Adjustable)
Hard Disk	1 SATA Hard Disk interface (Support Capacity from 40G to 2T )
Video Input	4 channel, BNC , 1.0V p-p/75Ω
Composite Video Output	1 channel, BNC, 1.0V p-p/75Ω
VGA Interface	1 VGA, Resolution: 800x600, 1024x768, 1280x1024, 1024x600 optional
Audio Input	1 BNC
Audio Output	1 BNC
Alarm Input	2 ch
Alarm Output	1 ch
Network	Ethernet (10/100M ),LAN,WAN and ADSL
Control Way	USB2.0 Mouse, Remote Control
Backup	USB2.0, Network
Bit Rate	Main Stream : 5 Levels optional:120MB/H ~ 500MB/H and self-defined Secondary Stream: 5 Levels optional : 20MB/H ~ 140MB/H and self-defined
Password	Encrypted by 128-bit Numerical Digits with 2-Level Password Protection
Power Supply	DC12V 3.0A
Consumption	15W(Without HDD)
Working Environment	Temperature: +5°C~+50°C; Humid:< 90%
Device Dimension	220×210 X 44 mm (WDH)
Weight	N.W: 2.5KG G.W: 3.0KG
