IVS100 is one channel CIF cctv network video encoder.
Features:
1.one video detection channel;
2.CIF resolution-low latency-MPEG-4 audio &video streaming;
3. Fully integrated and self-sustained video analysis and encoding appliance- no need for additional HW/SW;
4.Real time video analysis (DSP based)
5. High probability of detection, low false alarm rate (POD is 99%,FAR is less 1/day,)
6. 5 minutes setup process
7. Automatic actions can be triggered upon detection
8. Integrated HTTP server for live view and configuration
9. Hybrid video output (Analog &IP streaming)
10. Supports B/W, color, IR and thermal cameras (PAL/NTSC)
11.Detection Types:
(1) Intrusion detections:
-Regional entrance
-Tripwire
-Fence Trespassing
(2) unattended baggage detection
(3)object removal detection
(4)overtime stopped vehicle detection
(5)loitering detection
(6)autonomous PTZ tracking detection
(7)camera anomaly detection
The full specification:
Model |
BE-IVS100 |
|
||
Channels | ||||
Number of Intelligent Video Analysis Channels |
1 |
|
||
Analog Video Input | ||||
TV Standard |
Composite 1Vp-p – NTSC or PAL |
|||
Physical Connector |
1x BNC 75Ω |
|||
Analog Video Output | ||||
TV Standard |
Composite 1Vp-p – NTSC or PAL |
|||
Physical Connector |
1x BNC 75Ω |
|||
Digital Video Output | ||||
IP Video Streaming |
MPEG-4 SP and M-JPEG |
|
||
Max Resolution per Channel |
CIF |
|
||
Frame Rate |
Up to Full Frame Rate |
|||
Bit Rate |
CBR (128Kbps – 4Mbps), VBR |
|||
Network | ||||
Ethernet (IEEE 802.3/802.3U) |
2x RJ-45 Interface |
|||
Services and Protocols |
TCP/IP, UDP/IP, HTTP, SMTP, DHCP, DNS, SNTP |
|||
Video Streaming |
RTP/RTSP |
|||
Alarms/Commands |
TCP/IP |
|||
I/O Interface | ||||
Serial (one interface per input for PTZ camera control) |
2x RS-232+1x RS-485 |
|||
IN - Alarm Input |
4 x Alarm inputs (from Dry Contacts) |
|||
OUT - Relay Output |
2x Relay Output (rated load 1A@30VDC) |
|||
Power Source | ||||
Voltage |
12VDC |
|||
Power Consumption |
5.5W |
|
||
Physical Dimensions | ||||
Dimensions (mm) |
189 x 36 x 164 mm (WxHxD) |
|||
Dimensions (inches) |
7 7/16" x 1 13/32" x 6 7/16" (WxHxD) |
|||
Mounting |
Shelf Mount |
|||
Environmental Specifications | ||||
Operating Temperature |
0° to 50° C |
|||
Operating Humidity |
5% to 95% (Non-Condensing) |
|||
Certifications | ||||
Safety |
CE, TUV |
|||
Electromagnetic Interference (EMC) |
FCC part 15, subpart B, Class A |
|||
