Real Time Video Server,two Channel Audio,4ch Alarm Input/output

Name: Real Time Video Server,two Channel Audio,4ch Alarm Input/output
Brand: BELLSENT
SKU: 100918437
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

BELLSENT

Model Number:

BE-IVS4000D

Shenzhen Bellsent Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name BELLSENT

Model Number BE-IVS4000D

BE-IVS4000D is real time video server,which is self-sustained intelligent video centralized device with built-in video analytics.

1.Built-in high performance self sustained video analytics,requires no additional HW/SW.

2.Integrates with existing stationary and Pan/Tilt/Zoom (PTZ) security cameras.

3.Two-way audio capabilities,4ch alarm input/output.

4. Built-in HTML web server for access, configuration, and viewing through a network via a standard web browser.

5.Converts any analog CCTV surveillance camera to networked MPEG-4 CIF-quality video,

6.Detection rate 99%,false alarm rate is less 1/day.

7.Detection Types:

(1) Intrusion detections:

-Regional entrance

-Tripwire

-Fence Trespassing

(2) unattended baggage detection

(3)object removal detection

(4)overtime stopped vehicle detection

(5)loitering detection

(6)autonomous PTZ tracking detection

(7)camera anomaly detection

full Specifications:

Channels
Number of Channels	4
Analog Video Input
TV Standard	Composite 1Vp-p – NTSC or PAL
Physical Connector	4x BNC 75Ω
Analog Video Output
TV Standard	Composite 1Vp-p – NTSC or PAL
Physical Connector	4x BNC 75Ω
Digital Video Output
IP Video Streaming		MPEG-4 SP and M-JPEG, Two separate, independent and configurable video streams
Max Resolution per Channel	4CIF
Frame Rate	Up to Full Frame Rate
Bit Rate	CBR (128Kbps – 4Mbps), VBR
Network
Ethernet (IEEE 802.3/802.3U)	2x RJ-45 Interface
Services and Protocols	TCP/IP, UDP/IP, HTTP, SMTP, DHCP, DNS, SNTP
Video Streaming	RTP/RTSP
Alarms/Commands	TCP/IP
I/O Interface
Serial (one interface per input for PTZ camera control)	4x RS-232+1x RS-485
IN - Alarm Input	4 x Alarm inputs (from Dry Contacts)
OUT - Relay Output	4x Relay Output (rated load 1A@30VDC)
Power Source
Voltage	220VDC
Power Consumption	19W
Physical Dimensions
Dimensions (mm)	433 x 44x 395 mm (WxHxD)
Dimensions (inches)	17 1/32" x 1 23/32" x15 17/32" (WxHxD)
Mounting	Shelf Mount
Environmental Specifications
Operating Temperature	0° to 50° C
Operating Humidity	5% to 95% (Non-Condensing)
Certifications
Safety	CE, TUV
Electromagnetic Interference (EMC)	FCC part 15, subpart B, Class A
