BE-IVS100d is a smart intelligent-video-edge-device with built-in self-sustained video analytics. It is ideal for hidden, inconspicuous, or confined space installations. It plugs inline to upgrade a common CCTV security camera (B/W, color, thermal, and infrared) with powerful automated indoor and outdoor detection and autonomous tracking of intruders, suspicious baggage, stopped vehicles, removed items and more.
Key Intelligent Functions:
The connection is as:
Key features:
- One Video Detection Channel
- 4CIF Resolution – low latency-MPEG-4 audio & video streaming
- Intelligent video and network video encoder in one, operates both as a stand-alone unit or as part of an integrated network configuration
- Built-in high-performance self-sustained video analytics, requires no additional HW/SW
- Integrated HTTP Server for live view and configuration
- Integrates with existing analog cameras (stationary or PTZ) for retrofitting existing installations uSupports B/W, color, IR and thermal cameras (PAL/NTSC)
Specifications:
Hardware ( Embedded software) |
Embedded intelligent visual analysis module with multiple detections for regional intrusion, tripwire crossing, fence trespassing, converse moving, left behind baggage, theft, illegal parking, loitering etc. Support multiple detection zones, rules and switch. Also support video quality diagnostic and video signal anomaly alert function. |
Application interface (API) |
Open API and SDK |
Physical Dimensions |
33x 189x 153mm (WxHxD) |
Analog Video Input |
NTSC/ PAL Single channel composite video signal, BNC 75Ω Physical Connector |
Analog Video Output |
|
1ch Composite NTSC or PAL, BNC 75Ω Physical Connector, Support OSD image overlay output |
Digital Video Output |
|
Coding standard: MPEG-4 Max resolution: 4CIF Bit Rate 128kbps~2.5Mbps adjustable, PTZ camera support max 2.0 Mbps, Frame Rate: full real time ( PAL 25fps/NTSC 30 fps) Support fixed Bit rate (CBR) and variable Bit rate (VBR) by user define Support QOS |
Network |
|
Support 10/100 Base-TX Ethernet (auto-adaptive) Ethernet RJ-45 interface Support IEEE802.3/802.3U Support video RTP/IP unicast and multicast Can use IGMP multicast by working with switch/ router which support 802.3 10/100MB Ethernet IGMP multicast protocol. TCP/IP based alert message and command. |
Serial I/O |
RS-232 , RS-485 |
Alarm I/O Interface |
|
4ch alarm inputs (max 12VDC 50mA), 2ch alarm output (max 24VDC 1A/ 125VAC 0.5A) |
Power Source |
12VDC |
Power Voltage |
Power Consumption: 8W |
Working Environment |
|
Operating Temperature: 0°C~50°C (32°F~122°F) Operating Humidity: 5%~95% (Non-Condensing) |
