semi automatic corrugated box making machine
Description of semi automatic corrugated box making machine:
machine is pivotal equipment, which is designed for die cutting, creasing and cold embossing paper products such as paper cassettes, box board containers, paper trademarks etc.
Unique drive gears are adopted such as high-precision indexing mechanism, pneumatic closed up, pneumatic clutch, overpower protection, manual compression relief etc., to ensure stable and high speed running of the machine.
This machine is equipped with practical and reliable mechanisms such as pre-stack device, secondary delivery mechanisms, manual sampling etc., which ensure the excellent performance of the machine.
Electrical components and driving elements of internationally known brands are adopted to ensure die cutting precision and reliability of running. Also man-machine interface is used to monitor the machine state to display running status, trouble location, troubleshooting and relevant help information to fully actualize man-machine communication
Uses and features of semi automatic corrugated box making machine:
Design speed: 200m/min
Economic speed:180m/min
Effective width :1400mm-2200mm
Main roller :Φ380mm(different roller type)
Pressure roller:Φ385mm
Pre-heating roller:Φ400mm
There are two groups of corrugated rollers on machine ,when working you can choose one of them ,the other one is to pre-heat to change corrugated type
It takes small space (other machine like this machine need two single facer machine and take large space )
This machine is controlled by PLC ,touch screen show the data and easy operation
Vacuum adsorption single facer machine .upper and lower roller adopts excellent alloy steel , by heat processing ,hardness is HRC58°-60°,surface is grinding and hard chrome plating or adopts Tungsten Carbon corrugated roll
Independent driving box , 5 shafts transmission . Hard gear , low noise , working stable and the gear has long life
The gluing thickness is adjusted by push rod electrically
Corrugated roller and pressure roller lift lower and upper by hydraulic control , stable working pressure
Corrugated paper be with wet device by steam adjust
This machine is suitable for single facer production line (with two type corrugated roller ), if 5-ply production line adopts two SF-380T , it equals 4 corrugated rollers and it has big market competition
advantages of semi automatic corrugated box making machine:
- Numerical control thin blade corrugated cardboard nc slitter scorer
- Design speed: 200m/min
- Design width: 1400mm
- 999 group of orders storage is available, changing order automatically without stopping the line, manual changing order is available too.
- Just need 3-8seconds for the quick order changing, with the helical cross cutter machine together to achieve qucik order changing without speed down.
- Automatically follow up the speed of production line, synchronize with the production, also can be implanted into production management system.
- The CNC control system is composed of imported high quality industrial PC and PLC.
- Equipped with three type of scores: concave-convex(3ply), convex-concave(5ply), convex-flat, these 3 type could be electrical converted automatically, as well as the depth of scores.
- The blades are made of tungsten alloy steel, the lifetime will over 3 million meter.
- Both automatic self blade sharpening system and manual blade sharpening system are available, and both systems could be operated without stopping the line, which improves the working efficiency.
- Equipped with imported synchronous belt drive device, which has the advantages of high precision and low noise.
Electrical control of semi automatic corrugated box making machine:
Electrical control system uses the microcomputer control, realized visual display from the feeding, die cutting, delivery each working state and troubleshooting method. With various safety devices to guarantee machine and human safety. Imported Japan Stepless Inverter-controlled main motor. Efficiency enhancement type high power, low energy consumption, lower noise.
The machine adopts Japan OMRON PLC program control, all kinds of electrical components, the detection switch are used German Siemens, French Schneider and other famous international brands, making the performance more stable and reliable. All electronic components are CE standard.
