Specifications
DongFeng Vehicle Mounted Aerial Work Platformarticulated boom
max working height 14m
factory sale
ccc certificate
DongFeng Vehicle Mounted Aerial Work Platform
Why choose this DongFeng vehicle mounted aerial work platform:
1. This vehicle mounted aerial work platform is retrofitted from Dongfeng chassis, one of the largest vehicle manufacturer in China.
2. This vehicle mounted aerial work platform is one of the most popular models, because the price is very competive among 14m working height.
3. Double row cabin, 2+3 seats, articulated boom type, both the turntable and bucket could control.
4. Short lead time, quality guaranteed. this vehicle mounted aerial work platform quality have been approved by CCC, ISO. our factory have been in this line for years, we have a wide range of vehicle mounted aerial work platform models option.
Our service
1. Reply your question within 24hour.
2. one year of warranty since bill of lading on board date
3. provide english operation manual, english maintance manual
4. Free trainning in our factory if customer need.
Vehicle name |
Dongfeng Vehicle Mounted Aerial Work Platform |
||
Cabin |
crew cabin, 5 seats |
||
Drive type |
4x2, left hand drive |
||
Wheel base |
3300mm |
||
Overall dimension (L*W*H) |
6750x1950x2990 mm |
||
Weight |
GVW |
5385 kg |
|
Curb weight |
5060 kg |
||
Engine |
Engine model |
CY4102-C3F |
|
Make |
DongFeng Chaoyang Diesel Engine Co., Ltd |
||
Rated power / Displacement |
70 kw / 3856 ml |
||
Emission standard |
Euro 2 |
||
Tire type |
7.00-16, 6 pcs |
||
Gear box |
manual, 5 speed |
||
Brake |
air brake |
||
Max working height |
14 m |
||
Max working radius |
5.5 m |
||
Boom type |
articulated boom, 3 section of boom |
||
Outriggers |
4 pcs, H type |
||
Bucket rated load |
200 kg |
||
Hook lmax. lifting capacity |
1000 kg |
||
Hook max lifting height |
7.3m |
||
Operation |
manual |
||
