Overhead Working Truck 20m Street Light Maintenance Vehicles For Sales by our Factory Call Ms.Pinky 0086 15897603919
|
We can Provide you the following Overhead Working Truck: |
SINO SHACMAN ,DONGFENG DFL,FAW,BEIBEN NORTH BENZ , HOWO ,FOTON ,JAC I,SUZU Chassis,DF NISSAN-UD Chassis,HINO Chassis, JMC Chassis,JAC Chassis, Hongyan IVECO, Hualing-CAMC Chassis,MAN chassis or tractor tank trailer and so on all are optioanl
1.Factory direct sale
2.Specialized in Trucks 10 years
3.a competitive price.
4.with CCC,ISO9001,SGS,ASME
5.chassis is optional SINO SHACMAN ,HOWO, DFL, HINO /UD, BENZ, MAN ,I,SUZU 4x2 ,4x4,6X4 ,6x6,8x4,8x8 .
6.Engine min horse power is 120HP~ 240HP~380HP
7.Loading Capacity: From 2Tons to 60Tons
More information, please contact with me.
0086 15897603919 Ms. Pinky
Skype ID: pinky585
|
The Specification of Dongfeng Overhead Working Truck: |
| outside dimension (L×W×H)mm | 8600×2500×3000 |
| Total mass | 16000 Kg |
| Kerb mass | 15805 Kg |
| driving type | 4×2 |
| Cabin | With one bed |
| Wheelbase | 4700 mm |
| Engine | |
| model | B190 33 |
| Type | Diesel, 6-cylinder in line with water cooling, |
| turbo-charging &electri cal control inner EGR Euro 3 | |
| Max. power/rotated speed | 140(KW) /2500(rpm) |
| Displacement(ML) | 5900 |
| Company of engine | Dongfeng Cummins |
| Compression ratio | (17.3±0.5):1 |
| Gear box | |
| clutch | Φ395mm diaphragm clutch, |
| Hydraulic remote control transmission | |
| Front axle | 4.5T |
| Rear axle | 9T |
| Tyre | 9.00R20 |
| Max Speed | 90 Km/h |
| air condition | With |
| Max. working height | 20m |
| Cage dimension(L*W*H) | 1240*800*1100(mm) |
| Payload of cage | 200KG |
| Swinging angle | 360 degree continues. |
| Type of Stabilizer and Q’t: H type | Four ones and adjustable. |
| Controls | electric control shall be provided at base and at operator’s cage |
| Three knuckled booms, with double balance valve, electric operation lifting boom, with 1Tons hook. Four stabilizer can adjust with double hydraulic lock. | |
| With emergency equipment. | |
|
Characteristic of Dongfeng Overhead Working Truck, High Altitude Operation Truck : |
-About Aerial Platform Truck:
Our unique design operation system of full circle swinging three folding arms could help the worker stable operation in the air.The main purposes are:maintaining,installing,cleaning.camera shooting,ship bulding,chemical industry,electric power,pruning and streetlight changing etc. in the air from 8m to 24m height
-Characteristics:
1.The landing leg could be adjusted to keep the whole truck smooth and steady.We set a limit valve to control the hydraulic and electric uld protect workers when fault operation.
2.Adopt water proof switch for operational system,avoid water penetrates the switch for fear that corrosion and leak away.Choose Pipe working bucket.with elegant apperance. Double operating controls between the working bucket and rotating platform,easy to operate and maintenance,Safe and reliable.
|
Detail Photos of Overhead Working Truck, High Altitude Operation Truck : |
|
our producing equipment and advantage for High Altitude operation truck: |
More Overhead Working Truck, High Altitude operation Truck at our factory for you Choice:
|
Our Payment terms and delivery time: |
Delivery time: 15-20days after get the deposit or LC
Packing: nacked package, waxed before delivery by sea.
Documents: B/L, Commercial invoice, Packing list, Certificate of origin etc
|
Our Bank Information: |
BENEFICIARY: HUBEI RUNLI SPECIAL AUTOMOBILE CO., LTD
Address: NO.77, century ave, suizhou city, hubei province
BANK OF BENEFICIARY: BANK OF CHINA, HUBEI BRANCH, SUIZHOU SUB BRANCH
ADDRESS OF BANK: NO.69 LIESHAN ROAD, SUIZHOU, HUBEI, CHINA
ACCOUNT NO.: 20310608092001
SWIFT NO.: BKCHCNBJ600
1. Water truck
2. Fuel tanker truck, Oil Truck, Tanker Truck
3.Fire engine truck
4.Truck mounted with crane
5.Dump truck,tipper,heavy duty truck
6.LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker
6. Bulk cement truck
7. Concrete mixer truck, mixer truck, cement mixer truck
8. Garbage truck, Self-loading garbage truck,garbage compactor truck,sealed garbage truck
9.Fecal suction truck,sewage suction truck
10. High altitude working truck
11. Chemical liquid truck
12. Van truck,insulated truck,refrigeration truck
13. Semi Trailer, Low plate semi-trailer,oil semi-trailer,van semi-trailer,bulk cement transportation semi-trailer,container semi-trailer,chemical liquid semitrailer,etc more than 300 types in total.
Our company covers an area of 155,000square metres, factory area of 25000m3, manufacturing capability 5000 sets every year, include sales branch, producing manage centre and more than thirty branches in China.
Our company has D grade spressure vessel manufacturing ability, and war industry manufacturing ability and got the certification in 2005, is the producing basic of Chinese Sinopec.
our products not only gains the good reputations in domestic, but also be sold to oversea market, such as Qatar, Algeria, Bolivia, Burundi, Cameroon, Nigeria, Congo, East Timor, Ghana, Libya, Angola, O'zbekiston, South Africa, Afghanistan, vietnam, kazakhtan, Thailand, Mongolia, etc.
Our client:
please contact with Ms Pinky. Hotline: 0086 15897603919
Welcome to visit our company! suizhou city, Hubei Province.
