Tianjin ZhuoLiNeng (ZLN) Technology Co., Ltd. is a professional manufacturer specializing in advanced electrochemical water treatment equipment. Our Skid Mounted Liquid Chlorine Production System is designed to deliver high-purity liquid chlorine on-site with fully automatic control, significantly reducing both salt and electricity consumption. This system is ideal for municipal water treatment, industrial disinfection, and bleaching applications, providing a safe and cost-effective alternative to traditional chlorine supply methods.
With years of engineering expertise and a dedicated R&D team, we have optimized the electrolysis process to achieve lower operating costs while maintaining consistent output quality. The system is pre-assembled on a compact skid, minimizing installation time and site requirements. Whether you need a standalone unit or integration into an existing plant, our solution offers flexibility and reliability.
Below are the key features, technical specifications, and benefits of our Skid Mounted Liquid Chlorine Production System.
Key Features & Advantages
Fully Automatic Control – PLC-based system with HMI touch screen, real-time monitoring, and remote operation capability. Auto-start/stop, alarm, and data logging functions ensure hassle-free operation.
Low Salt Consumption – Advanced membrane technology and optimized brine circulation reduce salt usage by up to 30% compared to conventional systems, lowering your raw material cost.
Energy Efficient – High-efficiency electrolytic cells and intelligent power management cut electricity consumption by 15–20%, achieving
Skid Mounted Design – All components (electrolyzer, brine tank, rectifier, control panel, pumps, and piping) are integrated on a single skid. Pre-wired and pre-tested for quick installation.
Robust Construction – Electrodes made of titanium coated with mixed metal oxide (MMO) for long service life. Corrosion-resistant materials throughout.
Safety Features – Hydrogen gas detection, automatic ventilation, pressure relief valves, and emergency shutdown system ensure safe operation.
Customizable Capacity – Available in standard capacities from 50 kg/h to 500 kg/h, with custom designs for larger or smaller requirements.
Low Maintenance – Self-cleaning electrode design and easy access for inspection reduce downtime and maintenance costs.
Technical Specifications
| Parameter | Value |
| Production Capacity | 50 – 500 kg Cl₂/h (customizable) |
| Chlorine Purity | ≥ 99.5% (liquid) |
| Salt Consumption | ≤ 2.0 kg per kg Cl₂ |
| Power Consumption | ≤ 2.5 kWh per kg Cl₂ |
| Operating Voltage | 380V / 50Hz (3-phase) or custom |
| Control System | PLC + HMI (touch screen), remote monitoring optional |
| Operating Temperature | 10 – 40°C (ambient) |
| Skid Dimensions (L×W×H) | Varies per capacity; typically 6m×2.4m×2.8m (for 200 kg/h) |
Benefits for Your Business
Cost Savings – Reduced salt and electricity consumption directly lower your operational expenses. The fully automatic system also reduces labor costs.
Reliable Chlorine Supply – On-site production eliminates transportation risks and price fluctuations of purchased chlorine. You have full control over production.
Environmental Compliance – Lower energy and salt usage contribute to a smaller carbon footprint. The system is designed to meet stringent environmental standards.
Easy Installation – Skid-mounted design means minimal site preparation. Just connect utilities and start production within days.
Scalability – Modular design allows you to add more units as your capacity needs grow.
Frequently Asked Questions (FAQ)
Q: What raw materials are required for this system?
A: The main raw material is common salt (NaCl) and water. The system automatically dissolves and filters the brine before electrolysis.Q: How is the liquid chlorine stored?
A: The produced chlorine gas is cooled and liquefied, then stored in pressurized tanks. The system includes a storage module if required.Q: What safety measures are included?
A: Continuous hydrogen monitoring, automatic ventilation, emergency shutdown, and leak detection are standard. Our system complies with international safety guidelines.Q: Can the system be integrated with existing SCADA?
A: Yes, the PLC supports Modbus RTU/TCP, Profibus, and other communication protocols for remote monitoring and control.Q: What is the typical lifespan of the electrolytic cell?
A: With proper maintenance, the MMO-coated titanium electrodes can last 5–8 years, depending on operating conditions.Q: Do you provide installation and training?
A: Yes, we offer on-site installation supervision and operator training. Remote technical support is also available.Q: What is the delivery time?
A: Standard units are delivered within 6–8 weeks after order confirmation. Custom configurations may take longer.Q: Are there any special requirements for the site?
A: The system requires a concrete foundation, power supply, water supply, and drainage. A detailed site preparation document is provided upon order.
Why Choose Tianjin ZhuoLiNeng (ZLN) Technology Co., Ltd.?
As a dedicated manufacturer based in Tianjin, China, we have been serving global markets including North America, South America, Europe, Southeast Asia, Africa, and Oceania. Our team of experienced engineers ensures that every system is designed and tested for optimum performance. We pride ourselves on delivering customized solutions, competitive pricing, and timely after-sales support. With a strong domestic market presence and a growing international footprint, we are committed to helping you achieve efficient and sustainable chlorine production.
Contact us today to discuss your specific requirements and receive a customized quotation. Our technical team will help you select the right capacity and configuration for your application. Choose ZLN for reliable, low-cost, and fully automatic liquid chlorine production.
