Deqing Leixin Coating Equipment Co., Ltd., a professional manufacturer established in 2011 with a factory area of 1,000–3,000 square meters and ISO9001 certification, proudly presents our Custom Built Powder Spraying Plant specifically designed for anti-corrosion surface treatment of outdoor telecom equipment. Our plant integrates advanced electrostatic powder spraying technology, a precisely controlled curing oven, and a customizable conveyor system to deliver a complete, turnkey solution for protecting telecom enclosures, cabinets, and towers from harsh environmental conditions. With over a decade of experience and annual exports valued at US$1–1.5 million to markets across North America, South America, Europe, Asia, and Africa, we ensure every system meets the highest standards of durability and performance.
This powder spraying plant is engineered to provide a uniform, long-lasting coating that resists corrosion, UV radiation, and mechanical wear. The entire process—from pretreatment to powder application and curing—is automated with a PLC touch screen control system, ensuring consistent quality and repeatability. Our modular design allows for easy customization of booth dimensions, conveyor speed, oven temperature zones, and filter configurations to match your specific production line requirements. Whether you need to coat small telecom enclosures or large outdoor cabinets, our plant delivers exceptional efficiency and coating adhesion.
Key Features & Technical Specifications
- Electrostatic Powder Spray Booth: Made of stainless steel or anti-corrosion coated steel, with efficient cyclone and cartridge filter recovery system (recovery rate >95%).
- PLC Control System: Touch screen interface for real-time monitoring of temperature, humidity, powder flow, and conveyor speed. Supports recipe storage for different products.
- Gas-Fired / Electric Curing Oven: Multi-zone temperature control with accuracy ±2°C. Maximum temperature 250°C, adjustable for different powder types.
- Conveyor System: Overhead chain conveyor or floor belt conveyor, speed adjustable from 0.5 to 6 m/min, with automatic loading/unloading station.
- Pretreatment Line: Options include degreasing, phosphating, and passivation tanks (stainless steel) or a spray tunnel for high-volume production.
- Environmentally Friendly: Low VOC emissions, energy-efficient design, and optional waste heat recovery system.
| Parameter | Standard Range | Customizable Options |
|---|---|---|
| Production Capacity | 50–500 pieces per shift | Up to 1000+ pieces with extended conveyor |
| Spray Booth Dimensions (L×W×H) | 3m × 2m × 2.2m | Up to 8m × 4m × 3m for large cabinets |
| Curing Oven Temperature Range | 120°C – 250°C | Dual zone or multi-zone for thick substrates |
| Powder Recovery Efficiency | ≥95% | Optional automatic color change system |
| Power Supply | 380V / 50Hz, 3-phase | Custom voltage and frequency available |
Benefits for Your Business
- Enhanced Anti-Corrosion Performance: Our powder coating forms a thick, durable barrier that withstands salt spray, humidity, and temperature extremes, extending the service life of telecom equipment by 3–5 times compared to liquid paint.
- Increased Production Efficiency: Automated line reduces manual labor, minimizes coating defects, and achieves faster cycle times. The PLC system allows quick changeover between different product sizes.
- Cost Savings: High powder recovery rate reduces material waste. Energy-efficient ovens lower operating costs. Minimal maintenance with durable components.
- Environmentally Compliant: Powder coating produces near-zero VOCs, making it easier to meet environmental regulations in your region.
- Customized to Your Layout: We design the plant to fit your existing factory footprint, with flexible configurations for spray booths, ovens, and conveyors.
Company Reliability & After-Sales Support
Deqing Leixin Coating Equipment Co., Ltd. has been a trusted partner for coating solutions since 2011. Our factory covers 1,000–3,000 square meters, employing 51–100 skilled workers, and we export to over 15 countries and regions worldwide. Each plant is tested in our workshop before shipment, and we provide detailed installation manuals, video guidance, and remote troubleshooting. With an annual export value of US$1–1.5 million, we have proven our ability to deliver high-quality, custom-built systems on time. Our ISO9001 certification ensures systematic quality management from design to after-sales. Choose Deqing Leixin for a reliable, long-term partnership in telecom equipment surface treatment.
Frequently Asked Questions (FAQ)
-
Q: What is the typical lead time for a custom powder spraying plant?
A: Depending on the complexity and customization, lead time ranges from 30 to 60 working days, including design, fabrication, and testing. We will provide a detailed schedule upon order confirmation. -
Q: Can this plant handle different sizes of telecom equipment?
A: Yes, the plant is designed with adjustable conveyor speed and modular booth/oven sections. We can accommodate products up to 3m in height and 4m in width. Custom dimensions are available. -
Q: Do you provide installation and training services?
A: We provide detailed installation manuals and video guides. For overseas clients, we can also arrange on-site supervision by our engineers at an additional cost. Online training sessions are included. -
Q: What certifications does your plant have?
A: Our company is ISO9001 certified. The plant components comply with CE standards (optional upon request). We can also provide third-party inspection reports if needed. -
Q: What type of powder materials can be used?
A: The plant is compatible with most thermosetting powder coatings, including epoxy, polyester, hybrid, polyurethane, and acrylic powders. For special requirements, we can adjust the oven temperature and spray parameters. -
Q: How do you ensure the coating quality for outdoor telecom equipment?
A: Our system includes precise temperature control, adjustable powder flow, and electrostatic voltage regulation. We also recommend a pretreatment line (degreasing, phosphating) to ensure adhesion. Pre-shipment testing is performed with your sample parts. -
Q: What is the warranty period for the plant?
A: We offer a standard 12-month warranty covering manufacturing defects. Extended warranty options are available. Spare parts can be supplied at cost after warranty. -
Q: Can I visit your factory to see the plant in operation?
A: Absolutely. Our factory is located in Huzhou, Zhejiang, China, close to Ningbo and Shanghai ports. We welcome clients to visit and inspect our production line. Virtual tours are also available.
Ready to upgrade your surface treatment capabilities? Contact Deqing Leixin today for a customized quotation. Our team will analyze your specific requirements and provide a tailored solution for your outdoor telecom equipment anti-corrosion coating needs.
