At Deqing Leixin Coating Equipment Co., Ltd., we specialize in providing advanced powder coating solutions designed specifically for large-scale communication equipment, including telecom base station cabinets. Since our establishment in 2011, we have focused on delivering high-performance coating systems that ensure superior protection, uniform finish, and long-term durability. Our solutions are engineered to meet the demanding requirements of the telecommunications industry, offering excellent corrosion resistance and weather resistance for outdoor cabinets.
Our powder coating systems are built with state-of-the-art electrostatic spraying technology, enabling precise application and reducing material waste. The automatic spray booths are designed to accommodate large cabinets with dimensions up to 3000mm in height and 2000mm in width, ensuring complete coverage even on complex geometries. The system features adjustable conveyor speeds, programmable coating parameters, and integrated recovery units for efficient powder reuse. This not only enhances productivity but also significantly lowers operational costs compared to traditional liquid painting.
Key technical specifications include:
| Parameter | Details |
| Max Cabinet Size | 3000mm (H) x 2000mm (W) x 1500mm (D) |
| Conveyor Speed | 0.5 – 5 m/min (adjustable) |
| Powder Recovery Efficiency | Up to 98% |
| Coating Thickness | 60 – 120 μm (customizable) |
| Operating Temperature | 180°C – 220°C (curing oven) |
| Power Supply | 380V/50Hz, 3-phase |
Our powder coating solutions offer multiple advantages for telecom equipment manufacturers:
- Enhanced Durability: The powder coating provides excellent resistance to UV radiation, moisture, and chemical corrosion, extending the lifespan of base station cabinets.
- Uniform Finish: Electrostatic application ensures even coverage on edges, corners, and recessed areas, eliminating drips and sags common with liquid paints.
- Environmentally Friendly: Powder coating is solvent-free, reducing VOC emissions and complying with environmental regulations. The high recovery rate minimizes waste.
- Increased Productivity: Automated spray booths and conveyor systems allow continuous operation, significantly boosting throughput compared to manual spraying.
- Customization Flexibility: We offer a wide range of colors, textures (smooth, textured, metallic), and gloss levels to match OEM specifications. Color matching is available upon request.
- Energy Efficiency: Our curing ovens are designed with heat recovery systems, reducing energy consumption by up to 30% compared to conventional models.
Every system is designed with operator safety and ease of maintenance in mind. Features include automatic filter cleaning, explosion-proof electrical components, and user-friendly PLC touchscreen controls. Our team provides comprehensive installation, commissioning, and training services to ensure seamless integration into your production line.
As a trusted manufacturer with ISO9001 certification, Deqing Leixin Coating Equipment Co., Ltd. operates a 1,000–3,000 square meter factory with 51–100 experienced employees. Our annual export value ranges from US$1 million to US$1.5 million, serving customers across North America, South America, Europe, Asia, Africa, and Oceania. We have supplied powder coating systems to numerous telecom equipment manufacturers, helping them achieve consistent quality and cost savings. Our commitment to innovation and customer satisfaction has made us a reliable partner in the coating industry.
We invite you to contact us for a customized solution tailored to your specific telecom cabinet requirements. Our engineers will work with you to design the optimal powder coating system, from spray booth dimensions to conveyor layout and powder selection. With our global shipping ports in Ningbo and Shanghai, we ensure timely delivery worldwide. Experience the difference of professional powder coating solutions that elevate your product quality and production efficiency. Reach out today for a quote or technical consultation.
Frequently Asked Questions
- What types of powder coating can be used with your system? Our system is compatible with most thermosetting powder coatings, including epoxy, polyester, polyurethane, and hybrid types. We can also recommend specific formulations for outdoor telecom applications.
- Can your system handle cabinets with irregular shapes or multiple compartments? Yes, the automatic electrostatic spray guns with adjustable angles and reciprocaters ensure thorough coverage on complex geometries. Additional manual touch-up stations are optional.
- What is the typical curing time for telecom cabinets? Curing time depends on the powder type and thickness, typically ranging from 10 to 20 minutes at 180-220°C. Our conveyor speed can be adjusted accordingly.
- Do you provide installation and training services? Absolutely. We offer on-site installation, commissioning, and operator training to ensure your team can operate the system efficiently. Remote support is also available.
- What is the warranty period for your equipment? Standard warranty is 1 year from the date of installation, covering manufacturing defects in materials and workmanship. Extended warranty options are available upon request.
- How do you ensure consistent coating quality across large batches? Our PLC control system maintains precise temperature, humidity, and spray parameters. The powder recovery unit also filters and recycles powder to maintain consistent quality.
- Can the system be integrated with existing production lines? Yes, we design our systems with modular components that can be integrated into existing conveyor systems or operated as standalone units. Custom interface options are available.
- What is the lead time for a typical system? Lead time varies based on customization, but generally ranges from 4 to 8 weeks after order confirmation. We prioritize urgent orders upon request.
