Hengshui Ruibin New Materials LLC, a leading manufacturer established in 2019 with a factory spanning 1,000–3,000 square meters and over 100 skilled employees, proudly presents our Customizable Durable FRP GRP Fiberglass Reinforced Plastic Grating. Designed for demanding industrial environments, this grating combines high strength, corrosion resistance, and lightweight properties to provide a safe and long-lasting flooring solution. Our ISO9001-certified production process ensures consistent quality, while our flexible customization options allow you to tailor panel thickness, mesh size, color, and surface finish to your exact project requirements.
● Key Features & Benefits
- Exceptional Durability: Made from fiberglass reinforced plastic, our grating resists corrosion, rust, chemicals, and moisture – ideal for harsh industrial environments such as chemical plants, wastewater treatment facilities, and offshore platforms.
- High Load-Bearing Capacity: Engineered to withstand heavy loads, our grating is available in light, medium, and heavy-duty configurations. Customizable thickness and mesh density ensure the right strength for your specific application.
- Lightweight & Easy Installation: Weighing only one-third of steel gratings, our FRP grating reduces transportation costs and simplifies handling. Pre-drilled holes and modular panels enable quick, tool-free assembly.
- Slip Resistance: Choose from smooth or grit-top surfaces for enhanced safety in wet or oily conditions. The grit-top option provides excellent traction, minimizing workplace accidents.
- Low Maintenance: Non-conductive, non-magnetic, and UV-resistant, our grating requires no painting or special coatings. Simply wash with water to maintain its appearance and performance.
- Fire Retardant Options: Available with fire-retardant additives to meet specific safety standards (ask for details).
● Technical Specifications (Typical Values)
| Parameter | Standard Options | Custom Range |
|---|---|---|
| Panel Thickness | 25 mm, 30 mm, 38 mm | 20–50 mm |
| Mesh Size | 38×38 mm, 50×50 mm | 25×25 mm to 100×100 mm |
| Load Capacity | Light Duty (2.5 kN/m²), Medium Duty (5 kN/m²), Heavy Duty (10 kN/m²) | Up to 20 kN/m² upon request |
| Surface Finish | Smooth, Grit-Top (Silica) | Custom grit material |
| Color | Yellow, Green, Gray, Red | Any RAL color available |
| Resin Type | Polyester, Vinyl Ester | Phenolic, Epoxy for special chemical resistance |
● Why Choose Hengshui Ruibin?
With an annual export value of US$2.5–5 million and a global reach spanning North America, South America, Europe, Africa, Oceania, and Asia, we have established a reputation for reliable delivery and consistent quality. Our ISO9001 and ISO9000 certifications reflect our commitment to rigorous quality management. We offer flexible customization: from panel dimensions to surface texture, we can produce gratings that exactly match your engineering drawings. Every batch undergoes strict testing for dimensional accuracy, load capacity, and UV resistance before shipment.
● Frequently Asked Questions
- What is the typical lead time for customized FRP grating? – For standard sizes, lead time is 10–15 working days. Custom orders may require 15–25 working days, depending on complexity.
- Can the grating be used in food processing plants? – Yes, our FRP grating is non-toxic, non-porous, and easy to clean. With appropriate resin selection, it is suitable for food contact areas.
- What is the maximum span between supports? – It depends on load and panel thickness. Typically, 38mm thick grating can span up to 600mm under heavy load. We provide span tables upon request.
- Do you provide cutting or drilling services? – Yes, we can cut panels to size and pre-drill holes for bolts or clips. Please specify your requirements when ordering.
- Is the grating UV-resistant? – Yes, we add UV stabilizers to the resin to prevent degradation from sunlight. For outdoor use, we recommend a UV-resistant topcoat for extended life.
- Can I get a sample before placing a bulk order? – Absolutely. We offer small sample panels (e.g., 300×300 mm) for evaluation. Sample cost is refundable upon bulk order.
- What is the fire rating of your grating? – Standard polyester resin meets Class C (according to ASTM E84). Fire-retardant grades can achieve Class B or A. Please contact our sales team for specific requirements.
- How do you package the gratings for export? – Panels are packed in wooden crates or pallets, wrapped with protective film, and secured with straps to prevent damage during transit.
● Trust & Reliability – With over 100 dedicated employees and a modern factory in Hengshui, Hebei, we are capable of handling large-scale projects. Our shipments from Tianjin and Qingdao ports ensure timely delivery. We welcome OEM and ODM inquiries. Contact us today to discuss your industrial grating needs and receive a competitive quote!
