Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019 with a 1,000-3,000 m² factory and 101-200 skilled employees, brings you the Molded Fiberglass Reinforced Plastic Grating Ventilated Panel — a high-performance flooring solution specifically engineered for aquaculture farm working floors. Our annual export value of US$2.5-5 million and ISO9001 certified production ensure consistent quality. This ventilated panel offers superior corrosion resistance, excellent load-bearing capacity, and a slip-resistant surface, making it the ideal choice for wet, harsh environments in fish farms, shrimp ponds, and hatcheries.
The molded FRP grating is manufactured using a compression molding process, resulting in a one-piece, seamless structure that eliminates weak points. Its open mesh design allows water, air, and debris to pass through freely, keeping the working floor clean, dry, and safe. Lightweight yet strong, it can be easily cut and installed on site, reducing labor costs and downtime. Below we detail the key features, specifications, and benefits of this product.
Key Features & Technical Specifications
- Material: Premium fiberglass reinforced plastic (FRP) with high-quality resin (isophthalic polyester or vinyl ester optional).
- Ventilated Design: Open grid pattern with 38x38mm or 25x25mm mesh, ensuring excellent drainage and air circulation.
- Anti-Slip Surface: Textured top surface (concave/convex or grit-coated) provides secure footing even when wet.
- Corrosion Resistance: Impervious to saltwater, chlorine, ammonia, and other chemicals commonly found in aquaculture environments.
- Lightweight: Approximately 1/4 the weight of steel grating, making handling and installation effortless.
- High Strength: Molded construction delivers uniform strength across the entire panel; load capacity can be customized for light pedestrian to heavy machinery traffic.
- UV Resistance: Stabilized resin formulation prevents degradation from prolonged sunlight exposure.
- Non-Conductive: Electrical insulator, reducing risk of shock in wet areas.
- Low Maintenance: Does not rust, rot, or corrode; only occasional washing required.
- Customizable: Available in various colors (yellow, green, gray, etc.), thicknesses (25mm, 38mm, 50mm), and panel sizes (standard 1220x3660mm or custom).
| Parameter | Value |
|---|---|
| Material | Fiberglass reinforced plastic (FRP) |
| Resin Type | Isophthalic polyester / Vinyl ester (optional) |
| Panel Thickness | 25mm, 38mm, 50mm (customizable) |
| Mesh Size | 38x38mm, 25x25mm, or custom |
| Standard Panel Size | 1220 x 3660 mm (4' x 12') |
| Load Capacity | Light duty to heavy duty (per request) |
| Color Options | Yellow, green, gray, orange, blue, etc. |
| Operating Temperature | -40°C to +80°C (continuous) |
| Surface Finish | Concave/convex texture or grit-top |
| Certification | ISO9001:2015 |
Benefits for Aquaculture Farm Working Floors
- Improved Hygiene: Ventilated design allows water, feed waste, and debris to fall through, reducing bacterial growth and odors.
- Worker Safety: Anti-slip surface and high strength prevent accidents; non-conductive material adds electrical safety.
- Long Service Life: Resists saltwater, UV, and chemicals for 10-20 years with minimal maintenance.
- Easy Installation: Lightweight panels can be cut with standard tools and fastened with clips or screws; no welding required.
- Cost-Effective: Lower lifecycle cost compared to stainless steel or aluminum grating due to reduced corrosion replacement.
- Environmental Friendly: 100% recyclable and manufactured with low energy consumption.
At Hengshui Ruibin New Materials LLC, we have been serving global markets including North America, South America, Europe, Southeast Asia, Africa, and Oceania since 2019. Our ISO9001-certified quality management system ensures every panel meets rigorous standards. With a dedicated team of 101-200 employees and an annual export value of US$2.5-5 million, we have the capacity to fulfill large orders on time. We ship from Port of Tianjin or Port of Qingdao, ensuring fast logistics to worldwide destinations.
Why choose our molded FRP ventilated panel? Because it is not just a grating — it is a complete solution for your aquaculture flooring challenges. We offer free samples, technical support, and custom design services. Contact us today for a quotation or to discuss your project requirements. Your satisfaction is our priority.
Frequently Asked Questions
1. What is the difference between molded FRP grating and pultruded FRP grating?
Molded FRP grating is manufactured in a single compression molding process, creating a one-piece panel with uniform strength and a closed mold surface. Pultruded grating is made by assembling pultruded bars and rods, which may have weaker joints. For aquaculture wet floors, molded grating is preferred because it has no open ends, better corrosion resistance, and a smoother surface.
2. Can this panel be used in direct contact with saltwater?
Yes. Our FRP panels are made with corrosion-resistant resins (isophthalic polyester or vinyl ester) that withstand saltwater, chlorine, and other chemicals used in aquaculture. The material does not rust or degrade, making it ideal for seawater applications.
3. What load capacity does your 25mm thick panel have?
Load capacity depends on the mesh size and resin formulation. Our standard 25mm thick panel with 38x38mm mesh can support a uniform load of approximately 500 kg/m² (light pedestrian). For heavy-duty applications (e.g., feeding carts or light machinery), we recommend 38mm or 50mm thickness. We can provide specific load data upon request.
4. Is the surface slippery when wet?
No. Our panels feature a textured anti-slip surface (either concave/convex pattern or a grit-coated top). This provides excellent traction even in wet, oily conditions, significantly reducing the risk of slips and falls.
5. Can you cut the panels to custom sizes?
Yes. The panels can be cut on-site using a standard circular saw with a carbide blade, or we can precut them to your specified dimensions. We also offer custom shapes and cutouts for drains, pipes, or columns.
6. What is the typical lead time for an order?
For standard sizes and colors, lead time is 7-15 days after confirmation. Custom orders may require 15-25 days. We have a large inventory of raw materials and can expedite urgent orders. Our factory with 101-200 employees ensures efficient production.
7. Do you provide samples before bulk order?
Yes, we offer free samples (usually 300x300mm) for customers to evaluate quality, strength, and finish. You only need to cover the shipping cost. Contact our sales team to arrange sample delivery.
8. Is your product compliant with international standards?
Our manufacturing process is ISO9001:2015 certified. The FRP grating meets general international requirements for strength, fire resistance (optional), and UV stability. We can also provide test reports from third-party laboratories upon request.
