Welcome to Hengshui Ruibin New Materials LLC – a professional manufacturer of high-quality composite products since 2019. Our Composite Polyester Fiberglass Pedestrian Decking (Pultruded GRP/FRP Gratings) is engineered to deliver superior strength, durability, and safety for pedestrian walkways, industrial platforms, and architectural applications. Manufactured in our 1,000–3,000 sqm ISO9001 certified facility, these gratings combine lightweight design with excellent corrosion resistance, making them a reliable choice for harsh environments. With an annual export value of US$2.5–5 million, we serve clients across North America, Europe, Asia, Africa, and Oceania.
Product Features & Technical Advantages
Pultrusion Process: Continuous fiberglass roving impregnated with polyester resin ensures consistent mechanical properties and a smooth surface.
High Load Capacity: Designed to withstand pedestrian traffic, light vehicles, and equipment loads with minimal deflection.
Slip Resistance: Optional gritted or sanded top surface provides excellent traction, even in wet or oily conditions.
Corrosion & Chemical Resistance: Ideal for chemical plants, wastewater treatment, marine environments, and food processing areas.
Non-Conductive & Non-Magnetic: Safe for electrical substations and sensitive equipment areas.
Lightweight: Up to 75% lighter than steel gratings, reducing installation costs and structural load.
UV & Weather Resistance: UV-stabilized resin ensures long-term outdoor performance without fading or degradation.
Customizable Options: Available in various colors, thicknesses, mesh sizes, and panel dimensions to suit project requirements.
Typical Specifications (Reference Data)
| Parameter | Standard Range |
|---|---|
| Panel Thickness | 25mm, 30mm, 38mm (customizable) |
| Mesh Size (Center-to-Center) | 30x30mm, 40x40mm, 50x50mm |
| Bar Width | 6mm, 8mm, 10mm |
| Standard Panel Size | 1220 x 3660 mm (4′ x 12′) |
| Load Capacity (Uniform) | Up to 500 kg/m² (depending on configuration) |
| Weight (approx.) | 12–18 kg/m² |
| Fire Rating | Class B1 (optional) / Non-combustible upon request |
Why Choose Our Composite Polyester Fiberglass Pedestrian Decking?
Cost-Effective: Lower total cost of ownership compared to steel or aluminum due to zero maintenance (no painting, no rust).
Easy Installation: Lightweight panels can be cut, drilled, and assembled on-site with standard tools.
Long Service Life: Resistant to moisture, chemicals, and UV radiation – usually lasts 20+ years without replacement.
Eco-Friendly: Made from inert materials, fully recyclable, and reduces energy consumption during transport.
Global Shipping: Shipped from Port of Tianjin or Qingdao; we handle export documentation and logistics to major markets worldwide.
Trusted by International Clients – Over the past five years, Hengshui Ruibin New Materials LLC has supplied fiberglass gratings to more than 20 countries, including the USA, Canada, Germany, Australia, and South Africa. Our factory employs 101–200 skilled workers and operates under strict ISO9001 quality management systems. We have an annual export value of US$2.5–5 million, reflecting our commitment to reliable delivery and consistent product quality. Whether you need standard pedestrian decking or custom-designed gratings for a specialized project, we are ready to provide tailored solutions. Contact us today for a quote or technical consultation – your satisfaction is our priority.
Frequently Asked Questions (FAQ)
1. What is the difference between pultruded and molded grating?
Pultruded grating is made by pulling continuous fiberglass rovings through a resin bath and a heated die, resulting in a high-strength, unidirectional structure. Molded grating is formed by laying fiberglass mats and resin in a mold (compression or injection). Pultruded gratings offer higher strength-to-weight ratio and are often used for load-bearing applications like pedestrian decking, while molded gratings are more cost-effective for light-duty use.
2. Can this pedestrian decking be used in wet or chemical environments?
Yes. Our polyester resin system provides excellent resistance to water, saltwater, and many chemicals. For highly corrosive environments, we recommend our vinyl ester resin option (available upon request).
3. What load capacity can I expect?
Standard configurations support up to 500 kg/m² uniform load. However, load capacity depends on panel thickness, mesh size, and support spacing. We can design gratings to meet specific load requirements (e.g., for light vehicle traffic or heavy pedestrian traffic).
4. How do I install these gratings?
Installation is similar to steel gratings. Panels can be cut with a saw, drilled for bolts, and secured using clips, hold-downs, or a frame. Lightweight nature makes handling easy. We provide installation guidelines upon request.
5. Are custom sizes and colors available?
Absolutely. We offer custom panel dimensions, thicknesses, mesh sizes, and colors (including safety yellow, gray, green, and more). Minimum order quantity may apply for custom specifications.
6. Is the grating UV-resistant? Will it fade or degrade in sunlight?
Our standard resin includes UV stabilizers, ensuring long-term outdoor performance. However, over many years, slight color change may occur but does not affect structural integrity. For critical UV exposure, we can add additional UV protection.
7. What is the typical lead time and shipping method?
Lead time is 10–20 working days for standard sizes, and 20–30 days for custom orders. We ship via FOB Tianjin or Qingdao, using sea freight, air freight, or express courier depending on your urgency and budget.
8. Do you have certifications or quality control?
Our factory is ISO9001:2015 certified. We perform in-house testing for dimensional accuracy, load capacity, and resin content. Third-party inspections are welcome at your cost.
