LCD 4002 Character LCD Module 40*2dots
Product Spotlights
LCD 4002 Character LCD Module 40*2dots
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Certification:
ROHS
Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
shen zhen
Delivery Detail:
3 days
Related Products
-
VA 7 Segment Monochrome LCD Panel LCD Display for For Electric Vehicle Dashboard LCD Display ManufactoryUS$ 3.6MOQ: 1 Piece -
3.2-inch TFT Display With 320*480 Resolution, RGB/MCU Interface,US$ 6.8 - 7.8MOQ: 1 Piece
-
128*64 Graphic DOT-Matrix LCD Screen Cog12864 LCD Display SPI InterfaceUS$ 4.2 - 5.2MOQ: 1 Piece
-
20 Characters X 2 Lines Monochrome FSTN DOT Matrix LCD Type 2002 LCDUS$ 4.6 - 5.5MOQ: 1 Piece
-
1602 LCD Screen, 1602A Blue/Yellow-Green, 5V White Text With Backlight, LCD1602US$ 1.86 - 2.3MOQ: 1 Unit
Certification
ROHS
Origin
China
nterface with 4-bit or 8-bit MPU (directly connected M6800 serial MPU)
Display Specification
Display Character: 40 character X 2 line Character Font:5X8dots+cursor
Display color-Display background color : STN, Blue-Yellow
Polarize mode: positive, Transflective
Viewing angle: 6:00
Display duty: 1/16 Driving bias: 1/5
Character Generator ROM (CGROM): 8320 bits (204 characterX5X8 dots) &(32
characterX5X10 dots)
Character Generator RAM (CGRAM): 64X8 bits (8 charactersX5X8 dots)
Display Data RAM (DDRAM) :80X8 bits (80 characters max)
Mechanical characteristics (Unit: mm)
Extenal dimension: 182.0X33.5X13.5
View area : 152.6X16.5 Character font: 5X8 dots + cursor
Character size: 3.2X5.55 Dots size:0.65X0.6
Character pitch: 0.7X0.65
Weight ：60g
