20 Characters X 2 Lines Monochrome FSTN DOT Matrix LCD Type 2002 LCD
Product Spotlights
interface with 4-bit or 8-bit MPU (directly connected M6800 serial MPU)
Display Specification
Display Character: 20 character X 2 line Character Font:5X7dots+cursor
Display color-Display background color : STN, Black-Yellow/Green
Polarize mode: positive, Transflective
Viewing angle: 6:00
Display duty: 1/16 Driving bias: 1/5
US$ 5.5
1 - 999 Piece
US$ 4.6
≥1000 Piece
Key Specifications
Get Latest Price
Certification:
ROHS
Display Type:
Other, character lcd display
Specification:
146.0X43.0X13.5
Payment & Shipping
Payment Methods:
Port of Shipment:
shen zhen
Delivery Detail:
2 days
Related Products
-
1602 LCD Screen, 1602A Blue/Yellow-Green, 5V White Text With Backlight, LCD1602US$ 1.86 - 2.3MOQ: 1 Unit -
LCD Screen, 24 Character X 2 Line STN POS Customer Pole Display Character/Graphic COB LCD Display for Sale118*36 mmUS$ 3.0 - 3.5MOQ: 1 Piece
-
128x64 COG 12864 Blue Background White Words LCD Display Dimensions:60*50.3MMUS$ 5.0 - 6MOQ: 1 Piece
-
1602 Character Screen With Metal Pin External SPI InterfaceUS$ 2.5 - 2.6MOQ: 1 Piece
-
128*64 Graphic DOT-Matrix 12864LCD Screen Cog12864 LCD DisplayUS$ 3.6MOQ: 1 Piece
Certification
ROHS
Display Type
Other, character lcd display
Specification
146.0X43.0X13.5
Origin
shen zhen
interface with 4-bit or 8-bit MPU (directly connected M6800 serial MPU)
Display Specification
Display Character: 20 character X 2 line Character Font:5X7dots+cursor
Display color-Display background color : STN, Black-Yellow/Green
Polarize mode: positive, Transflective
Viewing angle: 6:00
Display duty: 1/16 Driving bias: 1/5
Character Generator ROM (CGROM): 8320 bits (192 characterX5X7 dots) &(32
characterX5X10 dots)
Character Generator RAM (CGRAM): 64X8 bits (8 charactersX5X8 dots)
Display Data RAM (DDRAM) :40X8 bits (80 characters max)
Mechanical characteristics (Unit: mm)
Extenal dimension: 146.0X43.0X13.5
View area : 123.0X23.0 Character font: 5X7 dots + cursor
Character size: 4.84X9.22 Dots size:1.1X0.92
Character pitch: 6.0X9.75
Weight ： g
POWER： +5V
