Conductor Material: Bare Copper Wire
Conductor Class: Compliant with IEC 60228 Class 5 Standard
Insulation: SRPVC-80-001
Core Identification:
＜0.5 mm²: Cores with color coding per DIN 47100 for 5 cores and less; multi-core cables above 5 cores adopt color-coded cores marked with white ink dots.
≥0.5 mm²: Cores with color coding including yellow/green earth wire per DIN 47100 for 5 cores and less; multi-core cables above 5 cores use black cores numbered by white ink printing. (Customizable upon special requirements)
Stranding: Layered Stranding
Shield: Tinned Copper Braid, approx. 70% coverage rate
Outer Sheath: PVC-H-70-001
Sheath Color: Black RAL9005; Grey RAL 7001
Rated Voltage: 300/300V for cross-section ≤0.5mm²; 300/500V for cross-section ＞0.5mm²
Test Voltage: 1500V for cross-section ≤0.5mm²; 2000V for cross-section ＞0.5mm²
Conductor Resistance: Compliant with IEC 60228 Class 5 Standard
Insulation Resistance: ≥20 MΩ·km
Capacitance: approx. 120 nF/km
Minimum Bending Radius for Fixed Installation: 5×D for OD ≤12mm; 7.5×D for OD ≤20mm; 10×D for OD ＞20mm
Minimum Bending Radius for Flexible Moving Application: 10×D for OD ≤12mm; 15×D for OD ≤20mm; 20×D for OD ＞20mm
Temperature Range (Fixed Laying): -15 ℃ to +80 ℃
Temperature Range (Flexible Movement): -5 ℃ to +80 ℃
Applicable Standard: DIN VDE 0812
Cable Marking: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO,LTD, Model, Cross-section, Rated Voltage, CE Mark, Continuous Meter Marking
