As a leading manufacturer from Anping Xinye Metal Wire Mesh Products Co., Ltd in Hengshui, Hebei, China, we specialize in producing high-quality Steel Grating Flooring specifically designed for demanding environments like oil and gas platforms. Our product features a precise 40x40mm mesh with an anti-slip surface and hot dip galvanized finish, ensuring long-lasting performance and safety in the harshest offshore conditions. With years of expertise in metal wire mesh fabrication, we deliver a solution that combines structural integrity, corrosion resistance, and reliable slip protection.
This steel grating is engineered to meet the rigorous demands of oil and gas platforms, where safety, durability, and ease of maintenance are paramount. The hot dip galvanized coating provides excellent resistance to rust and corrosion, even in saltwater and chemical-laden environments. The 40x40mm mesh openings offer a balance of weight reduction and load-bearing capacity, while the anti-slip surface (available with serrated or twisted bars) minimizes the risk of slips and falls, even when wet or oily.
Key Features & Technical Specifications
- Material: High-quality carbon steel (Q235 or Q345) – robust and impact-resistant.
- Surface Finish: Hot dip galvanized (HDG) – uniform coating thickness, no sharp edges, long-lasting corrosion protection.
- Mesh Size: 40mm x 40mm (center-to-center) – suitable for moderate foot traffic and light equipment.
- Anti-Slip Design: Available with serrated (toothed) or twisted (ridged) bars for enhanced grip.
- Load Capacity: Customizable bar thickness and bearing bar spacing to meet specific weight requirements.
- Panel Sizes: Standard dimensions or custom-cut to your project specifications.
- Connection Method: Welded construction for maximum strength, or press-locked for lighter applications.
- Compliance: Manufactured in accordance with international industry standards (details available upon request).
| Parameter | Specification |
|---|---|
| Bearing Bar Thickness | 3mm, 4mm, 5mm (customizable) |
| Bearing Bar Height | 25mm, 30mm, 40mm, 50mm |
| Cross Bar Spacing | 50mm, 100mm (standard) or custom |
| Panel Width | Up to 1200mm standard; wider available |
| Panel Length | Up to 6000mm or customized |
| Surface Treatment | Hot Dip Galvanized (avg. 85μm coating) |
Advantages & Benefits for Your Project
- Enhanced Safety: The anti-slip surface significantly reduces the risk of accidents on oil rigs, refineries, and offshore platforms, even in wet or oily conditions.
- Corrosion Resistance: Hot dip galvanizing provides a self-healing, durable barrier against seawater, chemicals, and extreme weather, extending service life by decades.
- Low Maintenance: No need for painting or frequent coating repairs – just occasional cleaning saves time and cost.
- High Strength-to-Weight Ratio: The open mesh design reduces weight while maintaining strong load-bearing capacity, making installation easier and reducing structural support costs.
- Versatile Applications: Ideal for walkways, platforms, stair treads, trench covers, and ventilation grids in oil & gas, marine, petrochemical, and industrial facilities.
- Customizable Options: We can tailor the grating dimensions, bar thickness, and surface finish to match your exact engineering drawings and load requirements.
Our manufacturing process at Anping Xinye ensures each panel is precision-cut, welded, and galvanized under strict quality control. We have supplied steel grating to numerous projects in the Middle East, Southeast Asia, and Africa, earning trust for our reliability and on-time delivery. With a dedicated team of engineers, we provide technical support and fast sample production to meet urgent project deadlines.
Frequently Asked Questions (FAQ)
Q1: What is the typical lead time for hot dip galvanized steel grating?
A: Lead time depends on order quantity and customization. For standard panels (e.g., 40x40mm mesh, 3mm thickness), we can ship within 15-20 working days after order confirmation. Custom sizes may require 25-30 working days.
Q2: Can I get a sample before bulk order?
A: Yes, we offer free samples (only shipping cost is charged). Sample size is typically 300x300mm. Please contact our sales team for details.
Q3: Is the anti-slip feature available on both sides?
A: The anti-slip surface is typically applied on the top side. If you require both sides, we can discuss customization options (e.g., serrated bars on both top and bottom).
Q4: What is the maximum load capacity for a 40x40mm mesh grating?
A: Load capacity depends on bearing bar thickness, height, and span. For a standard 30mm height x 3mm thick bar with 500mm span, it can support up to 4 kN/m². For higher loads, please provide your specific requirements.
Q5: How do you ensure the galvanized coating quality?
A: We follow hot dip galvanizing standards (e.g., ASTM A123, ISO 1461). Each batch is tested for coating thickness, uniformity, and adhesion. We can provide test reports upon request.
Q6: Can the grating be supplied with additional cutouts or holes for pipes?
A: Yes, we offer custom cutouts, notches, and holes based on your engineering drawings. Please provide a detailed layout for accurate fabrication.
Q7: Is it suitable for use in explosive environments (ATEX/IECEx)?
A: Steel grating is non-sparking when used with proper tools, but for explosive environments, anti-static options may be required. Please consult our technical team for specific recommendations.
Q8: What packing do you use for export?
A: Standard export packing: steel pallets or wooden crates, with steel straps and waterproof wrapping to prevent damage during sea freight. We can also pack according to your requirements.
With a strong track record of supplying steel grating for oil & gas platforms worldwide, Anping Xinye Metal Wire Mesh Products Co., Ltd is your trusted partner for quality, durability, and competitive pricing. Our factory in Hengshui, Hebei, China, is equipped with advanced production lines and a skilled workforce. We invite you to contact us for a quote or technical consultation. Let us help you ensure safety and performance in your next offshore project.
