Home > Industrial Equipment & Components > Environment Protection Device > Waste Treatment Equipment > Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp thumbnail-2

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp thumbnail-3

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp thumbnail-4

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp thumbnail-5

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp photo-1

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp photo-2

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp photo-3

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp photo-4

Automatic Industrial High-Salt Wastewater Treatment Machine 80°C Max Operating Temp photo-5

Product Spotlights

Full automatic high-salt wastewater evaporation system operating up to 80°C. Handles TDS up to 250,000 mg/L, customizable capacity from 1 to 20 m³/h, low energy consumption via MVR/TVR, corrosion-resistant SS316L construction, and PLC/HMI control. Ideal for ZLD applications in chemical, textile, and oil industries.

US$ 628000 ≥1 Combo

Key Specifications

Get Latest Price

Material:

Stainless Steel (SS316L or equivalent)

Max Operating Temperature:

80°C

Processing Capacity:

Customizable (e.g., 1–20 m³/h)

Contact Supplier Request Quote Chat Now

Qingdao Conqinphi Environmental Technology Group Co., Ltd.

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

50 days

Product Details
Company Profile
Contact Us

Material Stainless Steel (SS316L or equivalent)

Max Operating Temperature 80°C

Processing Capacity Customizable (e.g., 1–20 m³/h)

Power Supply 380V / 50Hz (optional 60Hz)

Automation Level Full PLC & HMI automatic control

Applicable Industries Chemical, Pharmaceutical, Textile, Oil & Gas, Desalination

Operation Mode Continuous automatic

Model Number CQ-HS-80 series (optional)

Function Evaporation & crystallization for high-salinity wastewater

Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 and occupying a 10,000–30,000 m² modern factory, proudly introduces our Automatic Industrial High-Salt Wastewater Treatment Machine with a maximum operating temperature of 80°C. This machine is engineered to efficiently treat high-salinity industrial effluents, reduce disposal costs, and recover valuable resources. With an annual export value of US$10–50 million and a dedicated team of 201–300 employees, we ensure every unit meets rigorous international standards. Our equipment is trusted across North America, Europe, Asia, and Africa for its reliability and superior performance.

The machine adopts advanced forced-circulation evaporation and crystallization technology, specifically designed for high TDS (Total Dissolved Solids) wastewater. It operates automatically with PLC & HMI control, minimizing manual intervention while maximizing uptime. The 80°C max operating temperature allows efficient concentration of brine without reaching boiling point, reducing energy consumption and scaling risks. Whether you are in chemical processing, pharmaceuticals, or textile manufacturing, this solution helps you achieve zero liquid discharge (ZLD) targets with ease.

Key Features & Technical Specifications

Fully automatic operation – integrated PLC and touch screen HMI for parameter monitoring and adjustment.
High corrosion resistance – constructed with SS316L or duplex stainless steel, suitable for chloride-rich environments.
Efficient heat transfer – shell-and-tube or plate heat exchanger design minimizes fouling.
Low energy consumption – mechanical vapor recompression (MVR) or thermal vapor recompression (TVR) options available upon request.
Compact footprint – modular design for easy installation and integration into existing plants.
Customizable capacity – from 1 m³/h laboratory-scale to 20 m³/h industrial-scale systems.
Safe and compliant – built with multiple safety interlocks, over-temperature protection, and emergency shutdown.

Parameter	Specification	Remarks
Max Operating Temperature	80°C	Adjustable via control system
Feed Salinity Range	Up to 250,000 mg/L TDS	Customizable for higher
Processing Capacity	1 – 20 m³/h (standard)	Other sizes available on request
Power Requirement	380V / 50Hz / 3-phase (or specify)	Can be adapted to local grid
Control System	PLC + HMI, remote monitoring option	Siemens or Mitsubishi available
Wetted Materials	SS316L / Duplex 2205 / Titanium (optional)	Depends on chloride concentration
Dimensions (L×W×H)	Custom per capacity	Provided after process design

Advantages for Your Business

Cost reduction – recover water and salt for reuse, slash disposal expenses.
Regulatory compliance – meet stringent environmental discharge norms (ZLD capability).
Low maintenance – anti-scaling design and automatic cleaning cycles extend service life.
Scalable – modular construction allows easy capacity expansion.
Energy optimization – MVR/TVR options cut steam or electricity consumption by up to 30% vs. traditional evaporators.

Our machines have been delivered to over 30 countries and regions, with proven performance in treating high-salinity brine from reverse osmosis reject, industrial cooling tower blowdown, chemical reaction waste, and more. Each unit undergoes strict quality control and is backed by comprehensive after-sales support including on-site commissioning, training, and 1-year warranty (extended warranty available).

Why Choose Qingdao Conqinphi Environmental Technology Group?

As a leading manufacturer with a 10,000–30,000 m² facility and annual export value exceeding US$10 million, we have supplied high-quality wastewater treatment systems to clients in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and beyond. Our team of 201–300 professionals holds multiple certifications including ISO9001, ISO14000, OHSAS18001, HACCP, SA8000, and more (partial list). We are ready to customize this automatic high-salt wastewater treatment machine to your specific salinity, flow rate, and site conditions.

The 80°C operating temperature ensures gentle evaporation, reducing scaling and corrosion while maintaining high concentration efficiency. Combined with our robust automation, you get a reliable, low-operator solution that runs 24/7. Contact us today for a detailed proposal and process simulation. Let’s work together to turn your problematic high-salt wastewater into a manageable resource.

Frequently Asked Questions (FAQ)

Q: What types of high-salt wastewater can this machine handle?
A: It is suitable for most industrial high-salinity effluents, including brine from RO reject, chemical process waste, textile dyeing, pickling, and oil & gas produced water. The maximum TDS can reach 250,000 mg/L or higher with customization.
Q: What is the typical power consumption per ton of treated water?
A: Depending on the configuration (MVR/TVR) and feed salinity, electricity consumption ranges from 30 to 80 kWh per ton of evaporated water. We can provide a precise estimate after analyzing your water sample.
Q: Does the machine come with a warranty?
A: Yes, a standard 1-year warranty covers manufacturing defects and workmanship. Extended warranty or service contracts can be arranged upon request.
Q: Can the system be integrated with existing wastewater plant?
A: Absolutely. Our design team will assess your site layout and provide a modular solution that seamlessly integrates with your existing piping, electrical, and control systems.
Q: How often does the heat exchanger need cleaning?
A: Thanks to our anti-scaling design and automatic cleaning cycles (CIP), cleaning intervals typically range from 2 to 4 weeks depending on water chemistry. Detailed maintenance schedule is provided during commissioning.
Q: What is the delivery time?
A: Standard models can be delivered within 30–45 days after order confirmation. Customized units may require 60–90 days due to engineering and fabrication.
Q: Do you provide on-site installation and training?
A: Yes, we offer worldwide on-site commissioning, operator training, and technical support. Remote assistance is also available via video call.
Q: Can the machine handle slurry or suspended solids?
A: It is designed for clarified brine; however, we can incorporate pre-filtration or a settling tank if your wastewater contains significant suspended solids. Discuss your specific needs with our engineers.
