Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a leading manufacturer specializing in advanced water treatment solutions since 2015. Our Reliable High-Salt Wastewater Zero-Discharge Treatment Solution is designed to tackle the toughest industrial brine streams, achieving complete water recovery and solid salt production. With a factory spanning 10,000–30,000 square meters and a dedicated team of 201–300 professionals, we deliver turnkey systems backed by free technical training support to ensure your team operates and maintains the equipment with confidence.
This solution is ideal for industries such as petrochemicals, textiles, pharmaceuticals, mining, and power generation where high-salinity wastewater poses environmental and operational challenges. By integrating state-of-the-art evaporation and crystallization technologies, we achieve zero liquid discharge (ZLD), transforming waste into valuable resources. Every system is customized to meet your specific flow rate, salt composition, and site conditions.
Key Features & Technical Specifications
- Zero Discharge Capability: Recovers up to 99% of water for reuse, with solid salt as a byproduct.
- High Salt Tolerance: Handles TDS from 30,000 to 250,000 mg/L, including high-scaling ions (Ca²⁺, Mg²⁺, SO₄²⁻).
- Energy Efficient Design: Multi-effect evaporation (MEE) or mechanical vapor recompression (MVR) to minimize operating costs.
- Corrosion-Resistant Materials: All wetted parts are made of 316L stainless steel, duplex stainless steel, or titanium based on brine corrosivity.
- Automated Operation: PLC-based control with HMI interface; remote monitoring and alarm via SCADA (optional).
- Compact Footprint: Modular skid-mounted design for easy installation and expansion.
- Free Technical Training: Includes onsite training for operators, maintenance manuals, and lifetime technical support.
Typical Technical Parameters (Sample)
| Parameter | Value |
|---|---|
| Feed TDS (mg/L) | 50,000 – 250,000 |
| Distillate TDS (mg/L) | < 10 |
| Evaporation Temperature (°C) | 60 – 100 (adjustable) |
| Water Recovery Rate | ≥ 95% |
| Energy Consumption (kWh/m³ water removed) | 45 – 80 (MVR) / 120 – 200 (MEE with steam) |
| Power Supply | 380V / 50Hz (or custom) |
Why Choose Our Solution?
- Proven Reliability: Hundreds of units installed worldwide across various industries.
- Comprehensive Support: From process design to commissioning and after-sales service.
- Regulatory Compliance: Helps you meet local discharge and environmental standards.
- Cost-Effective Operation: Low energy consumption and minimal chemical dosing requirements.
- Scalable Design: Available from small pilot units (1 m³/day) to industrial scale (500+ m³/day).
As a manufacturer with annual export value exceeding US$10 million and serving markets across North America, South America, Europe, Asia, Africa, and Oceania, Qingdao Conqinphi has built a reputation for quality and innovation. Our factory is certified with ISO9001, ISO14000, OHSAS18001, HACCP, and multiple other management system certificates (available upon request). Each zero-discharge system undergoes strict quality inspection before shipping from Qingdao Port.
Invest in a solution that not only solves your high-salt wastewater problem but also adds value through water reuse and salt recovery. Contact us today for a free technical consultation and project quotation. Our team is ready to provide complete engineering, equipment supply, and free training for your staff.
Frequently Asked Questions (FAQ)
Q1: What types of high-salt wastewater can your system handle?
A1: Our system is designed for various industrial brines including reverse osmosis concentrate, cooling tower blowdown, petrochemical wastewater, textile dyeing effluents, and landfill leachate. We customize the pretreatment and evaporation process based on the specific salt composition.
Q2: What is the typical payback period for this zero-discharge treatment solution?
A2: The payback period depends on factors like water cost, energy cost, and salt reuse value. In many cases, savings from water recycling and reduced disposal fees can achieve payback within 2-4 years. We provide a free ROI analysis upon request.
Q3: Do you provide pilot testing before full-scale installation?
A3: Yes, we offer rental pilot units (1-5 m³/day) for on-site testing. This helps validate the process design and optimize operating parameters. Pilot testing is highly recommended for complex brine compositions.
Q4: What kind of technical training is included for free?
A4: Free training covers system operation, routine maintenance, troubleshooting, and safety procedures. It is conducted at your site by our experienced engineers during commissioning. We also provide detailed manuals and video tutorials for ongoing reference.
Q5: How do you handle scaling and fouling issues in high-salt applications?
A5: We incorporate appropriate pretreatment steps (e.g., softening, antiscalant dosing) and select materials that resist scaling. Our design also includes intermittent cleaning cycles (CIP) and easily accessible components for maintenance.
Q6: What are the shipping terms and lead time?
A6: We ship from Qingdao Port (FOB, CIF, etc., negotiable). Lead time depends on system size and customization; typically 60-120 days for standard systems. We also provide installation supervision and commissioning services worldwide.
Q7: Do you have certifications that prove your quality system?
A7: Yes, our company is certified under ISO9001, ISO14000, OHSAS18001, HACCP, and other standards (full list available upon request). These certifications reflect our commitment to quality, environmental management, and occupational health.
Q8: Can the system be integrated with existing wastewater treatment plants?
A8: Absolutely. Our engineers will evaluate your current layout and design a seamless integration. The modular design allows easy tie-in with existing piping and control systems.
