Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a leading manufacturer specializing in industrial crystallization and evaporation solutions. Since our establishment in 2015, we have grown into a trusted partner with a 10,000-30,000 sqm factory, 201-300 skilled employees, and an annual export value exceeding US$10 million. Our Semi-Automatic Forced Evaporation Crystallizer is designed for demanding applications where reliable, high-temperature operation and corrosion resistance are critical. Made from premium 316L stainless steel and capable of handling up to 120°C, this equipment delivers consistent performance for wastewater treatment, chemical processing, and pharmaceutical production.
This crystallizer employs a forced evaporation principle to achieve rapid concentration and crystallization of solutions. The semi-automatic control system simplifies operation while maintaining high efficiency. Whether you need to recover valuable byproducts or reduce waste volume, our crystallizer offers a robust solution with minimal maintenance.
Key Features and Technical Specifications
- Superior Material: Constructed entirely from 316L stainless steel, providing excellent resistance to chlorides, acids, and alkalis, ensuring long service life even in harsh environments.
- High Temperature Capability: Designed for continuous operation at up to 120°C, enabling efficient processing of high-boiling-point solutions.
- Forced Circulation Design: A dedicated circulation pump ensures uniform heat transfer and prevents scaling, significantly improving crystallization efficiency.
- Semi-Automatic Control: Intuitive interface with adjustable parameters for temperature, pressure, and feed rate. Operators can easily monitor and adjust the process without full automation complexity.
- Energy Efficient: Optimized heat exchanger design reduces energy consumption by up to 20% compared to traditional evaporators.
- Compact Footprint: Space-saving layout suitable for retrofit projects or new installations with limited floor space.
- Easy Maintenance: Quick-access design for cleaning and inspection minimizes downtime.
| Parameter | Specification |
|---|---|
| Model | SFE-120 (Customizable) |
| Material of Construction | 316L Stainless Steel |
| Max Working Temperature | 120°C (248°F) |
| Max Working Pressure | 0.3 MPa (optional higher) |
| Evaporation Capacity | 50 – 500 kg/h (customizable) |
| Power Supply | 380V / 50Hz (or as required) |
| Control System | Semi-automatic PLC with touch screen (optional) |
| Dimensions (L×W×H) | 2200×1500×2800 mm (approx., varies by capacity) |
Benefits for Your Business:
- Significantly reduces waste volume, lowering disposal costs.
- Recovers valuable solids from solutions, generating additional revenue streams.
- Operates reliably with minimal supervision, reducing labor costs.
- 316L construction ensures compliance with stringent hygiene and corrosion standards (e.g., food/pharma applications).
- Customizable capacity and features to match your specific process requirements.
Trusted by Global Clients: Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been serving clients across North America, South America, Europe, Southeast Asia, Africa, and the Middle East. Our products are backed by certifications including ISO9001, ISO14000, HACCP, and others. With a dedicated R&D team and after-sales support, we ensure your investment delivers maximum returns. Contact us today to discuss your crystallization needs and receive a customized solution.
Frequently Asked Questions (FAQ)
Q1: What is the maximum working temperature of this crystallizer?
A: The designed maximum working temperature is 120°C (248°F). This allows efficient processing of solutions with high boiling points.
Q2: Can the crystallizer handle corrosive liquids?
A: Yes, the use of 316L stainless steel provides excellent resistance to chlorides, acids, and many corrosive chemicals. For extremely aggressive media, optional lining or special alloys are available upon request.
Q3: Is the operation fully automatic?
A: It is semi-automatic. The system includes automatic temperature control and safety interlocks, but manual intervention may be required for startup, shutdown, and parameter adjustments. Full automation (PLC + SCADA) is available as an upgrade.
Q4: What is the typical evaporation capacity?
A: Standard capacities range from 50 kg/h to 500 kg/h. Custom designs for larger or smaller capacities can be engineered to meet your needs.
Q5: How does forced evaporation differ from natural evaporation?
A: Forced evaporation uses a circulation pump to maintain high flow velocity across the heat transfer surface, which prevents scaling and fouling, improves heat transfer efficiency, and allows operation at higher concentrations.
Q6: What maintenance is required?
A: Regular inspection of seals, gaskets, and the circulation pump is recommended. The heat exchanger should be cleaned periodically depending on the feed quality. Our design allows easy access for cleaning.
Q7: Do you provide installation and training?
A: Yes, we offer on-site installation supervision and operator training as part of our service package. Remote technical support is also available.
Q8: What is the lead time for delivery?
A: Typical lead time is 4-6 weeks after order confirmation, depending on customization level. We can expedite for urgent projects.
