Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly introduces our Turnkey Brine Evaporation and Crystallization System, designed to transform challenging saline wastewater into valuable solids and clean water. As a manufacturer with over 9 years of experience and a 10,000–30,000 m² factory, we deliver complete, ready-to-install solutions that ensure regulatory compliance and operational efficiency. This integrated system includes a 1-year warranty, a comprehensive Mill Test Report, and global technical support, making it a reliable choice for industries tackling high-salinity streams.
Our system employs advanced evaporation and crystallization technologies to achieve zero liquid discharge (ZLD), turning brine into high-purity crystals and reusable distillate. It is ideal for sectors such as oil & gas, chemical processing, desalination plants, mining, and wastewater treatment. With annual exports exceeding US$10 million and a team of 201–300 experienced professionals, we guarantee robust construction and long-term performance.
Product Features & Technical Specifications
- Turnkey Solution: Pre-engineered skid-mounted or containerized units reduce installation time and site work.
- High Recovery Rate: Achieves up to 95% water recovery, minimizing waste volume.
- Energy Efficient: Optional Mechanical Vapor Recompression (MVR) cuts energy consumption by up to 60% compared to conventional methods.
- Automated Control: PLC-based system with HMI interface allows remote monitoring and one-touch operation.
- Corrosion-Resistant Construction: High-grade stainless steel (304/316L) and titanium internals ensure longevity in aggressive brine environments.
- Included Mill Test Report: Every unit is factory-tested, and a detailed report certifies performance parameters like evaporation capacity, steam consumption, and crystal purity.
- Global Support: Our engineering team provides remote diagnostics, spare parts, and on-site commissioning worldwide.
| Parameter | Typical Value | Remarks |
|---|---|---|
| Evaporation Capacity | 10 – 500 m³/day | Customizable |
| Feed Salinity TDS | Up to 360,000 ppm | Lower salinity also applicable |
| Operating Temperature | 40 – 105°C | Depends on pressure |
| Crystal Purity | ≥ 95% | Mixed salts depending on feed |
| Steam Consumption (MEE) | 0.15 – 0.4 kg steam/kg water | Lower with MVR option |
| Power Consumption (MVR) | 30 – 80 kWh/m³ | Varies with TDS |
Customer Benefits: By implementing our turnkey brine evaporation and crystallization system, clients achieve full compliance with environmental discharge standards, significantly reduce volume for solid disposal, and recover valuable water that can be reused in processes. The 1-year warranty and included Mill Test Report provide confidence in performance from day one. Furthermore, our global technical support means expert assistance is always just a call or email away, minimizing downtime.
Founded in 2015 and based in Qingdao, Shandong, China, Qingdao Conqinphi has shipped its equipment to North America, Europe, Southeast Asia, Africa, and the Middle East, with an annual export value of US$10–50 million. Our factory is run by a dedicated team of 201–300 employees, and we adhere to rigorous internal quality control standards. We are proud to offer a system that combines proven engineering with turnkey convenience, supported by a Mill Test Report that verifies every critical function. Contact us today to discuss your brine treatment challenges and see how our crystallization system can turn your waste into value.
Frequently Asked Questions
Q1: What types of brine can this system handle?
A: Our system is designed for high-salinity wastewater, including seawater RO reject, produced water from oil & gas, industrial effluents from chemical plants, and landfill leachate. It handles TDS up to 360,000 ppm effectively.
Q2: What is the typical delivery time for a turnkey unit?
A: Delivery depends on capacity and customization. Standard units can be shipped in 8–12 weeks after order confirmation. Larger systems require 14–20 weeks. We will provide a confirmed schedule upon quotation.
Q3: Does the 1-year warranty cover on-site labor?
A: Yes, our warranty covers parts, materials, and labor for repairs within the warranty period. Travel and accommodation for on-site support are included for remote locations (subject to contract terms).
Q4: What information does the Mill Test Report include?
A: The report documents actual test results of your specific unit, including evaporation capacity, steam consumption, product crystal quality, and all pressure/temperature parameters. It verifies compliance with design specifications.
Q5: Can the system be integrated with existing treatment plants?
A: Absolutely. Our turnkey solution comes with flexible flanges and control interfaces. We provide technical drawings and on-site guidance for smooth integration with your existing piping and control systems.
Q6: Is global technical support available 24/7?
A: Yes. Our support team operates across multiple time zones and can be reached via email, phone, or our online portal. Emergency remote troubleshooting is available around the clock.
Q7: What crystallization byproducts are produced?
A: The system typically produces mixed salt crystals (e.g., NaCl, Na₂SO₄, CaCl₂). If your brine composition is single-salt dominant, high-purity crystalline products can be recovered for reuse or sale.
Q8: Do you provide pilot testing before purchase?
A: Yes, we offer a mobile pilot unit for on-site trials. The results help optimize the final design to match your actual wastewater characteristics. A nominal fee applies and can be credited toward a full system order.
