PLC Controlled High-Salt Wastewater Evaporator With IP65 Electrical Cabinet and PID Regulation
Product Spotlights
PLC-controlled automation with PID precision ensures stable evaporation and energy savings. IP65 electrical cabinet withstands harsh environments. Handles TDS up to 250,000 mg/L. Modular skid design for quick installation. Factory direct from ISO-certified manufacturer, customizable capacity and materials.
US$ 5520 - 528900
MOQ: 1 Combo
Key Specifications
Get Latest Price
Certification:
Other, ISO9001
Material:
Stainless Steel (SS304/SS316L optional)
Capacity:
Customizable (e.g., 500 L/h, 1000 L/h)
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
60 days
Related Products
-
1-Year Warranty High-Salt Wastewater Treatment Evaporator With On-Site Commissioning TrainingUS$ 5520 - 528900MOQ: 1 Combo -
Standard Compliant High-Salt Wastewater Evaporator With Mill Test Report and After-Sales SupportUS$ 5520 - 528900MOQ: 1 Combo
-
Multi-Effect Distillation High-Salt Wastewater Treatment Evaporator With MVR TechnologyUS$ 5520 - 528900MOQ: 1 Combo
-
PLC Controlled Industrial Wastewater Treatment Equipment 304 Stainless Steel 50m³/h Flow RateUS$ 47300 - 407900MOQ: 1 Combo
-
Industrial Wastewater Treatment Equipment for Metal Plating Plants Removing Heavy Metals and CyanideUS$ 47300 - 407900MOQ: 1 Combo
Certification
Other, ISO9001
Material
Stainless Steel (SS304/SS316L optional)
Capacity
Customizable (e.g., 500 L/h, 1000 L/h)
Power Supply
380V/50Hz (three-phase) or custom
Control System
Programmable Logic Controller (PLC) with HMI touchscreen
Protection Grade
IP65 Electrical Cabinet
Regulation Method
PID Control (temperature, pressure, flow)
Application
High-salinity wastewater from chemical, pharmaceutical, textile, oil & gas industries
Installation Type
Skid-mounted or containerized
Heating Source
Electric / Steam / Heat pump (optional)
Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 with a factory spanning 10,000–30,000 m², specializes in high-end environmental equipment. Our PLC Controlled High-Salt Wastewater Evaporator combines advanced automation with robust field-proven engineering. It is designed to tackle the toughest industrial wastewater challenges—reducing liquid volume by up to 95% while recovering clean distillate. With an IP65-rated electrical cabinet and PID regulation, this system offers precise, reliable performance in harsh environments, helping you achieve compliance and operational cost savings.
Key Features & Benefits
- PLC + HMI Intelligent Control: Automatic start/stop, fault diagnosis, real-time data logging, and remote monitoring via SCADA (optional). Reduces manual intervention and human error.
- PID Regulation for Optimal Efficiency: Precise control of temperature, pressure, and feed rate ensures stable evaporation, lower energy consumption, and minimal scaling.
- IP65 Electrical Cabinet: Dust-tight and protected against low-pressure water jets—ideal for outdoor or humid industrial environments. Extends component lifespan and safety.
- High-Salt Tolerance: Engineered to handle brine with TDS up to 250,000 mg/L. Anti-crystallization design with automatic blowdown and flushing cycles.
- Modular & Skid-Mounted: Pre-assembled, tested, and ready for quick installation. Available in containerized version for easy transport and relocation.
- Energy Recovery Options: Can integrate mechanical vapor recompression (MVR) or heat pump to reduce energy cost by 30–60% (optional).
| Parameter | Typical Range | Notes |
|---|---|---|
| Evaporation Capacity | 500 – 5000 L/h | Customizable per project |
| Operating Temperature | 70 – 110 °C (adjustable) | Under PID control |
| Maximum Feed TDS | ≤ 250,000 mg/L | Higher upon request |
| Electrical Cabinet Protection | IP65 | NEMA 4X equivalent |
| Power Consumption | 30 – 200 kW (depends on model) | With optional heat recovery |
| Control System | PLC + 7" HMI Touchscreen | Supports Ethernet/IP |
Technical Advantages
The integration of PID (Proportional-Integral-Derivative) regulation ensures that process variables stay within tight tolerances, minimizing fluctuations that lead to foaming or scaling. Combined with the IP65-rated cabinet, the electronics are shielded from corrosive vapors and wash-down procedures—common in chemical and food processing plants.
Our evaporator uses a falling-film or forced-circulation design (depending on feed characteristics) to maximize heat transfer while reducing fouling. The PLC controls automatic blowdown cycles based on conductivity readings, preventing salt saturation and maintaining consistent performance.
Why Choose Conqinphi?
- Factory Direct – 201–300 experienced employees, 10,000–30,000 m² production base.
- Global Reach – Annual export value US$10–50 million, shipping to North America, Europe, SE Asia, Africa, and more.
- Compliance – Factory holds ISO9001, ISO14000, OHSAS18001, and other management system certifications.
- Customization – Tailored capacity, material (SS316L, duplex), heat source (electric/steam/gas), and control options.
Frequently Asked Questions
-
What is the maximum salt concentration this evaporator can handle?
It can treat wastewater with TDS up to 250,000 mg/L. For higher concentrations, we offer custom crystallizer options. -
How does the PID regulation improve energy efficiency?
PID maintains optimal temperature and pressure, preventing energy waste from overshooting. It also reduces scaling, so less frequent cleaning is needed. -
Is the IP65 cabinet suitable for outdoor installation?
Yes, it protects against dust and rain. However, direct sunlight exposure may require a sunshade for prolonged life. -
What maintenance is required?
Routine checks include cleaning heat exchanger surfaces, inspecting seals, and verifying sensor calibration. The PLC automatically logs run hours for preventive maintenance. -
Can I integrate this evaporator with my existing plant SCADA?
Yes, our PLC supports Modbus TCP/IP and other common protocols for seamless integration. -
What is the typical lead time?
For standard models, 30–45 days after order confirmation. Custom projects vary based on complexity. -
Do you provide after-sales service and training?
We offer on-site commissioning, operator training, and remote technical support. Spare parts are available globally. -
What certifications does the equipment meet?
Factory is certified under ISO9001, ISO14000, and OHSAS18001. Individual units can be built to CE or ASME standards upon request.
With a strong track record of over 500 installations worldwide, Qingdao Conqinphi Environmental Technology Group Co., Ltd. is your trusted partner in sustainable wastewater treatment. Contact us today for a free feasibility analysis and quotation. Let us help you turn your high-salt wastewater challenge into a resource recovery opportunity.
