Help CenterPlate Type Three Effect Evaporator 1 Year Warranty With Installation Guidance and Testing
Product Spotlights
Related Products
-
Plate Type Three Effect Evaporator Falling Film Design for Heat Sensitive Material ProcessingUS$ 8690 - 87500MOQ: 2 Combos -
Industrial Plate Three Effect Evaporator 1500L/H Evaporation Capacity With MVR SystemUS$ 8690 - 87500MOQ: 2 Combos
-
Plate-type Four-effect Evaporator 5-Stage Preheater 0.8MPa Steam Pressure ISO CompliantUS$ 8400 - 870000MOQ: 2 Combos
-
Plate-type Four-effect Evaporator for Wastewater Treatment Pharmaceutical Industry 304LUS$ 8400 - 870000MOQ: 2 Combos
-
Plate-type Four-effect Evaporator 316L SS Industrial Grade 3-Phase 380V 50HzUS$ 8400 - 870000MOQ: 2 Combos
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a reliable manufacturer established in 2015 with a factory area of 10,000-30,000 square meters and an annual export value of US$10-50 million. We specialize in advanced evaporation solutions, and our Plate Type Three Effect Evaporator delivers exceptional energy efficiency, compact design, and robust performance for various industries worldwide. This system comes with a 1-year warranty, comprehensive installation guidance, and full testing services to ensure seamless integration into your production line. Trusted by clients across North America, Europe, Asia, and beyond, our evaporator is engineered to meet the highest standards of quality and reliability.
Key Features and Benefits:
- Three Effect Design: Utilizes vapor from the first effect as heating medium for the second, and so on, dramatically reducing steam consumption by up to 50% compared to single-effect units.
- Plate Type Heat Exchanger: Compact and highly efficient – plates offer large heat transfer area in a small footprint, making it ideal for limited spaces.
- Flexible Operation: Suitable for concentrating aqueous solutions, fruit juices, dairy products, pharmaceutical extracts, chemical intermediates, and wastewater treatment.
- Easy Maintenance: Plate construction allows quick disassembly for cleaning and inspection, reducing downtime.
- Automation Ready: Optional PLC control with touch screen for automatic operation, data logging, and remote monitoring.
- Comprehensive Support: Our team provides step-by-step installation guidance, on-site testing, and after-sales service to ensure optimal performance from day one.
Technical Specifications (Example – customize according to your needs):
| Parameter | Value |
| Number of Effects | 3 |
| Evaporation Capacity | 500 – 5000 kg/h (custom) |
| Steam Consumption | ~0.35 – 0.4 kg steam per kg water evaporated |
| Operating Temperature | 1st effect: 90-100°C | 2nd effect: 75-85°C | 3rd effect: 60-70°C |
| Max Operating Pressure | 0.3 – 0.5 MPa (depends on design) |
| Material of Construction | SS304 / SS316L (option for food/pharma) |
| Power Supply | 380V/50Hz/3Ph (other voltages available) |
| Dimensions (LxWxH) | Customized per capacity |
| Warranty | 1 year (parts & labor) |
Why Choose Our Plate Type Three Effect Evaporator?
- Energy Savings: Three-effect cascade design reduces energy costs significantly. You only pay for about 1/3 of the steam compared to single-effect evaporation.
- Space Efficiency: Plate-type construction requires up to 50% less floor space than traditional tubular evaporators.
- Versatility: Handles a wide range of feed concentrations and viscosities. Ideal for heat-sensitive products due to low residence time.
- Reliability: Manufactured under strict quality control (ISO9001, HACCP, etc.) and tested before shipment.
- Local Support: With 201-300 employees and strong export experience, we offer responsive technical support and spare parts availability.
Installation Guidance & Testing: Our team will remotely or on-site guide your engineers through installation, commissioning, and initial operation. Each unit undergoes a factory acceptance test (FAT) to verify performance, and we can arrange site tests upon request. This ensures your new evaporator meets your production targets from day one.
Trusted by Global Clients: We have served markets in North America, South America, Europe, Africa, Oceania, and Asia. With an annual export value exceeding US$10 million and certifications including ISO9001, HACCP, OHSAS18001, and more, we are committed to delivering quality and value. Our factory spans 10,000-30,000 sqm, equipped with advanced manufacturing and testing facilities. Choose Qingdao Conqinphi for a reliable partner in evaporation technology. Contact us today for a quote or technical consultation – your satisfaction is our priority.
Frequently Asked Questions
-
What does the 1-year warranty cover?
The warranty covers defects in materials and workmanship for 1 year from the date of shipment. It includes replacement parts (excluding wear items) and labor for repairs. For full terms, please refer to our warranty policy.
-
Is installation guidance included? How does it work?
Yes, we provide detailed installation guidance. Our engineers can assist via video call or on-site (depending on agreement). We also supply a comprehensive installation manual and drawings to ensure proper setup.
-
What kind of testing is performed before shipment?
Each evaporator undergoes a Factory Acceptance Test (FAT) including hydrostatic pressure test, performance test with water or representative product, and control system functionality check. A test report is provided.
-
Can this evaporator handle high-viscosity or fouling liquids?
The plate design is less prone to fouling compared to tubular designs. For high-viscosity fluids, we may recommend modifications such as increased plate gap or circulation pumps. Please provide your product details for a custom evaluation.
-
What materials are used for the plates and frame?
Standard material is SS304. For corrosive environments or food/pharma applications, SS316L or other alloys are available upon request. Gaskets can be EPDM, Viton, or PTFE.
-
How much steam and cooling water does it consume?
Steam consumption is approximately 0.35-0.4 kg per kg of evaporated water (depending on temperature and product). Cooling water requirement is roughly 20-30 m³ per ton of evaporation for a standard condenser. These figures can be optimized with customization.
-
What are the main markets and certifications of your company?
We export to North America, South America, Europe, Africa, Oceania, and Asia. Our certificates include ISO9001, HACCP, OHSAS18001, TL900, and many others. We can provide copies upon request.
-
Can I request a trial or sample testing before ordering?
Yes, we have a pilot-scale plate evaporator in our lab. We can test your product and provide a report to confirm feasibility and performance. Contact our sales team to arrange.
