Plate-type Four-effect Evaporator 1-Year Warranty Factory Direct Technical Support
Product Spotlights
Four-effect energy-saving plate design reduces steam consumption by up to 60%. Compact structure, easy maintenance, and customizable evaporation capacity. Factory-direct with 1-year warranty and lifetime technical support. Ideal for wastewater, food, chemical, and pharmaceutical concentration processes.
US$ 8400 - 870000
MOQ: 2 Combos
Key Specifications
Get Latest Price
Material:
Other, Stainless Steel 304/316L (Customizable)
Application:
Other, Wastewater Treatment
Warranty:
1 Year (Standard)
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
20 days
Related Products
-
Plate-type Four-effect Evaporator for Food Processing Concentration Milk Juice 316SSUS$ 8400 - 870000MOQ: 2 Combos -
Compact Plate-type Four-effect Evaporator 10TPH PLC Touch Screen 304/316LUS$ 8400 - 870000MOQ: 2 Combos
-
Plate-type Four-effect Evaporator Mill Test Report Standard Compliant Installation IncludedUS$ 8400 - 870000MOQ: 2 Combos
-
Energy-Saving Plate-type Four-effect Evaporator 2000L/H Automatic Cleaning 220V/380VUS$ 8400 - 870000MOQ: 2 Combos
-
Automatic Plate-type Four-effect Evaporator 316L Stainless Steel 380V 50Hz With CIPUS$ 8400 - 870000MOQ: 2 Combos
Material
Other, Stainless Steel 304/316L (Customizable)
Application
Other, Wastewater Treatment
Warranty
1 Year (Standard)
After-sales Service
Online Technical Support, Field Maintenance, Spare Parts Supply
Evaporation Capacity
500 kg/h - 5000 kg/h (Customizable)
Heating Area
50 m² - 500 m² (Depends on Model)
Voltage
380V / 440V / Customizable
Power
15 kW - 150 kW (Model Dependent)
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. Since our establishment in 2015, we have been dedicated to manufacturing high-efficiency evaporation systems for global industrial clients. Our Plate-type Four-effect Evaporator represents a breakthrough in energy-saving concentration technology, designed to reduce operational costs while maximizing throughput. Backed by our 10,000–30,000 m² factory and a team of 201–300 skilled professionals, every unit is built with precision and reliability in mind. With an annual export value exceeding US$10–50 million, our equipment is trusted across North America, Europe, Southeast Asia, and beyond. We offer a standard 1-year warranty and direct factory technical support to ensure your production runs smoothly.
Key Features and Technical Advantages
- Four-Effect Design: Utilizes four sequential evaporation stages to recover latent heat, achieving up to 60% energy savings compared to single-effect systems.
- Plate-type Heat Exchanger: High thermal efficiency and compact footprint; easy to clean and maintain. Ideal for heat-sensitive liquids and viscous solutions.
- Robust Construction: Made from premium stainless steel (304 or 316L) to withstand corrosive environments and high temperatures.
- Automated Control: PLC-based operation with touch-screen interface for real-time monitoring of temperature, pressure, and flow rate.
- Flexible Capacity: Evaporation rates from 500 kg/h to 5000 kg/h can be customized according to your process requirements.
- 1-Year Warranty: Full coverage on manufacturing defects, plus lifetime remote technical support from our experienced engineers.
Technical Specifications (Example Model: CQ-4P-2000)
| Parameter | Value |
|---|---|
| Type | Plate-type, Four-effect |
| Evaporation Capacity | 2000 kg/h |
| Heating Area per Effect | 80 m² |
| Operating Temperature | 60–120 °C (adjustable) |
| Operating Pressure | -0.09 MPa to 0.3 MPa |
| Material | SS304 / SS316L |
| Power Consumption | 45 kW |
| Dimensions (L×W×H) | 6000 × 2500 × 3500 mm |
Customer Benefits
- Lower Energy Costs: The four-effect configuration recycles vapor heat, reducing steam consumption by up to 60%.
- Compact Footprint: Plate-type design saves floor space compared to traditional tubular evaporators.
- Easy Maintenance: Individual plate panels can be removed for cleaning or replacement without special tools.
- Customizable Solutions: We tailor the system to your specific liquid properties (viscosity, pH, scaling tendency) and target concentration.
- Reliable After-Sales: Factory-direct technical support ensures quick troubleshooting; spare parts are stocked for fast delivery.
Trust and Quality Assurance
Qingdao Conqinphi Environmental Technology Group operates under strict quality management systems, holding certifications such as ISO9001, ISO14000, OHSAS18001, HACCP, and others. Our factory spans over 10,000–30,000 square meters, and we export to major markets worldwide including North & South America, Europe, Africa, and the Middle East. With a dedicated R&D team and years of experience in evaporation technology, we deliver equipment that consistently meets international standards. Every Plate-type Four-effect Evaporator comes with a 1-year warranty and lifetime technical support – a promise we stand behind. Contact us today for a customized proposal and quotation!
Frequently Asked Questions
-
Q: What is the working principle of a four-effect plate evaporator?
A: It uses four separate evaporation chambers (effects) arranged in series. The vapor from the first effect heats the second effect, and so on, recovering latent heat and drastically reducing energy input. -
Q: Can this evaporator handle high-viscosity liquids?
A: Yes, the plate-type design with wide channels allows for processing moderately viscous solutions. For extremely viscous fluids, we can customize the plate gap and flow arrangement. -
Q: What is the standard warranty period and what does it cover?
A: Our standard warranty is 1 year from the date of shipment. It covers any manufacturing defects in materials or workmanship. Consumable parts (gaskets, seals) are covered for 6 months. -
Q: Do you provide on-site installation and training?
A: Yes, we offer field service for commissioning and training at an additional cost. Remote technical support via video call is always available free of charge. -
Q: What is the typical delivery lead time?
A: For standard configurations, lead time is 30–45 days after order confirmation. Customized units may require 45–60 days depending on complexity. -
Q: What certifications does your company hold?
A: Our company is certified under ISO9001, ISO14000, OHSAS18001, HACCP, QS9000, SA8000, and many others. Specific product certifications can be arranged upon request. -
Q: How do I choose the right material for my application?
A: For corrosive or acidic liquids, we recommend SS316L; for general aqueous solutions, SS304 is suitable. Our sales team can guide you based on your liquid analysis report. -
Q: Can I get spare parts locally?
A: We maintain a stock of common spare parts (plates, gaskets, seals) in our warehouse. For international customers, we can ship via express courier to minimize downtime.
