Deqing Leixin Coating Equipment Co., Ltd., established in 2011, specializes in manufacturing high-performance industrial ovens. Our Customizable Industrial Curing Oven with Stainless Steel Chamber and Over-Temperature Protection is engineered to deliver precision curing, drying, and baking for a wide range of industries. Built with a robust stainless steel interior and advanced safety features, this oven ensures consistent temperature distribution and reliable operation. Whether you need a standard model or a fully customized solution, our oven adapts to your production requirements, offering long-term durability and energy efficiency.
Key Features & Benefits
- Stainless Steel Chamber: Corrosion-resistant, easy to clean, and suitable for cleanroom environments. Available in grade 304 or 316L upon request.
- Over-Temperature Protection: Dual independent thermostat system automatically cuts off heating if temperature exceeds set point, preventing damage to products and equipment.
- Customizable Design: Options for chamber dimensions, temperature range (up to 300°C), heating method (electric or gas), air circulation type, and control system.
- Uniform Heat Distribution: Horizontal or vertical airflow design with high-efficiency fans ensures temperature variance within ±2°C across all shelves.
- Energy-Saving Insulation: Thick layer of rock wool insulation reduces heat loss, lowering operational costs by up to 20% compared to conventional ovens.
- User-Friendly Control: PID digital controller with programmable timer, alarm output, and data logging capability for precise process control.
- Robust Construction: Heavy-duty steel frame with electrostatic powder coating exterior for long service life in harsh industrial environments.
- Safety Compliance: Built-in emergency stop, door interlock switch, and over-current protection as standard features.
Technical Specifications (Example – Customizable)
| Parameter | Standard Option | Custom Range |
| Chamber Material | 304 Stainless Steel | 316L Stainless Steel available |
| Temperature Range | Room Temp ~ 300°C | Up to 500°C on request |
| Chamber Dimensions (W×D×H) | 1000×1000×1200 mm | Any size from 500×500×500 mm |
| Heating Power | 12 kW (Electric) | 6 kW – 48 kW adjustable |
| Air Circulation | Horizontal, 2.2 kW fan | Vertical or multi-zone available |
| Control System | PID with timer & alarm | PLC + HMI, remote monitoring |
| Over-Temperature Protection | Independent mechanical thermostat | Dual digital/mechanical (redundant) |
| Weight (approx.) | 800 kg | Varies with dimensions |
Applications
Our curing oven is widely used in powder coating lines, automotive parts finishing, electronic component baking, composite material curing, food packaging drying, and pharmaceutical processing. The stainless steel chamber complies with food-grade and cleanroom standards, making it suitable for sensitive applications. With customizable shelving and loading systems, it integrates seamlessly into automated production lines.
Why Choose Deqing Leixin?
Deqing Leixin Coating Equipment Co., Ltd. is a professional manufacturer with a factory area of 1,000-3,000 square meters and over 50 skilled employees. Since 2011, we have exported to North America, South America, Europe, Southeast Asia, Africa, and Oceania with an annual export value of US$1-1.5 million. Our products are ISO9001 certified, ensuring consistent quality management. We ship from the ports of Ningbo and Shanghai, providing fast delivery worldwide. Every oven undergoes rigorous testing before shipment, including temperature accuracy, safety device, and insulation performance checks.
We offer 24/7 technical support and a 12-month warranty. Spare parts such as heaters, fans, and controllers are readily available. Our engineering team can design custom solutions for your specific curing needs – from explosive-proof environments to ultra-high temperature requirements. Contact us today to discuss your project and receive a free quotation.
Frequently Asked Questions
-
Q: What is the typical lead time for a custom curing oven?
A: For standard sizes, lead time is 20-25 working days. Custom designs may take 35-45 working days depending on complexity. We provide a detailed schedule upon order confirmation. -
Q: Can the oven be used for food drying?
A: Yes, the stainless steel chamber (304 or 316L) meets food contact safety requirements. We can also add UV sterilization or HEPA filters if needed. -
Q: What voltage and frequency are available?
A: Standard options include 220V/380V/415V/480V, 50Hz/60Hz, single-phase or three-phase. We can customize the electrical configuration to match your local grid. -
Q: How does the over-temperature protection work?
A: It uses an independent temperature sensor and a mechanical thermostat that disconnects the heating circuit if the chamber temperature exceeds the set limit by 5-10°C. This provides a fail-safe even if the main controller fails. -
Q: Do you provide installation and training?
A: Yes, we offer remote guidance via video call and detailed manuals. On-site installation and training can be arranged at extra cost. Our local agents in some regions also provide support. -
Q: What is the warranty period?
A: Standard warranty is 12 months from shipment date, covering manufacturing defects. Extended warranty up to 36 months is available upon request. -
Q: Can I test samples before ordering?
A: Absolutely. You can send your samples to our factory in Huzhou, China, for free trial curing. We will provide a test report and video recording. -
Q: How do you ensure temperature uniformity?
A: We use computational fluid dynamics (CFD) simulation during design, and each oven undergoes a 9-point temperature uniformity test before delivery, with results documented.
