Deqing Leixin Coating Equipment Co., Ltd., an ISO9001-certified manufacturer established in 2011, proudly presents our Rail-Mounted Trolley Type Industrial Oven — an electric heating solution specifically engineered for coating cross-linking and solidification processes. With over a decade of expertise and a factory spanning 1,000–3,000 square meters, we deliver robust ovens that ensure consistent, high-quality curing for diverse industrial applications. This oven is designed to optimize workflow efficiency, minimize energy consumption, and provide precise temperature control, making it an ideal choice for automotive, aerospace, furniture, and powder coating industries.
Key Features & Technical Specifications
Rail-Mounted Trolley System: Enables easy loading/unloading of heavy workpieces; reduces manual handling and cycle time.
Electric Heating Elements: High-efficiency stainless steel heating tubes ensure rapid heat-up and uniform temperature distribution.
Cross-Linking & Solidification Optimization: Specialized airflow design (horizontal/vertical forced convection) provides optimal heat transfer for complete polymerization.
PID Programmable Control: Touchscreen interface with multi-stage temperature/time programming ensures repeatable curing profiles.
Energy-Saving Insulation: Thick mineral wool insulation (100mm-150mm) reduces heat loss and operating costs.
Durable Construction: Available in stainless steel or cold-rolled steel inner lining, resistant to corrosion and easy to clean.
Safety Features: Over-temperature protection, door interlock, and emergency stop button for operator safety.
Technical Parameters (Typical Model)
| Parameter | Value |
| Temperature Range | 50°C – 300°C (customizable to 400°C) |
| Temperature Uniformity | ±5°C (at steady state) |
| Heating Power | 30–120 kW (model dependent) |
| Internal Dimensions (W×H×D) | 1500×1800×2000 mm (standard) |
| Trolley Load Capacity | 1000 kg (up to 3000 kg optional) |
| Power Supply | 380V/3Ph/50-60Hz (custom voltage available) |
| Control System | PLC + Touchscreen (Siemens/Omron available) |
Benefits for Your Production
Higher Productivity: Rail-mounted trolleys allow batch processing of large parts, reducing loading time by up to 40%.
Consistent Quality: PID-controlled airflow ensures every workpiece receives identical curing conditions, minimizing rejects.
Lower Operating Costs: Energy-efficient design and electric heating reduce fuel expenses compared to gas-fired ovens.
Flexibility: Customizable temperature profiles, trolley dimensions, and control interfaces to fit your unique process.
Easy Maintenance: Access panels and modular heating elements simplify servicing, minimizing downtime.
With an annual export value of US$1 million–US$1.5 million and a team of 51–100 experienced professionals, Deqing Leixin has supplied rail-mounted trolley ovens to markets across North America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Every oven is backed by ISO9001 quality management and rigorous factory testing before shipment. We provide 12-month warranty and lifetime technical support, ensuring your investment delivers long-term value.
Contact our sales engineers today for a customized quotation or to discuss your coating cross-linking and solidification requirements. Our team is ready to help you achieve faster cure cycles, superior finish quality, and lower total cost of ownership.
Frequently Asked Questions
What coatings can this oven cure? It is suitable for thermosetting powders, liquid paints, varnishes, adhesives, and other cross-linking coatings that require controlled heating.
Is the oven explosion-proof? Our standard design is not explosion-proof. For flammable solvents, optional explosion-relief panels and ATEX-compliant components are available upon request.
What is the typical delivery time? Standard models ship within 30–45 days after order confirmation. Customized ovens require 45–60 days.
Can I integrate existing PLC system? Yes, our control system supports Profibus, Modbus, or Ethernet communication for easy integration with your factory automation.
Do you provide installation and training? We offer remote commissioning guidance and on-site training (travel expenses apply). Detailed manuals and video tutorials are included.
What are the power requirements? Standard is 380V/3Ph/50Hz; 60Hz and other voltages (e.g., 220V/3Ph) are customizable.
How often should heating elements be replaced? With proper maintenance, heating elements typically last 3–5 years. We keep spare parts in stock.
What is the maximum workpiece size? The standard internal dimension is 1500×1800×2000 mm, but we can design larger chambers up to 6m length per request.
