Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process

Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process thumbnail-3

Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process thumbnail-4

Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process thumbnail-5

Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process photo-1

Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process photo-2

Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process photo-3

Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process photo-4

Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process photo-5

Product Spotlights

Deqing Leixin Industrial Curing Oven delivers precision uniformity (±3°C) and customizable sizing for composite bonding and automotive post-cure. Built with robust construction and PLC control, it ensures reliable, energy-efficient thermal processing. Supported by ISO9001-certified manufacturer with global export experience.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

material:

Stainless Steel / Carbon Steel

internal_dimensions:

Customizable (e.g., 1500x1500x1500 mm)

temperature_range:

Ambient to 300°C

Contact Supplier Request Quote Chat Now

Deqing Leixin Coating Equipment Co., Ltd.

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

material Stainless Steel / Carbon Steel

internal_dimensions Customizable (e.g., 1500x1500x1500 mm)

temperature_range Ambient to 300°C

temperature_uniformity ±3°C

heating_method Electric / Gas (optional)

control_system PLC with HMI Touchscreen

power_supply 380V / 220V / Customized

certification ISO9001

application Composite Bonding & Automotive Post-Cure

Deqing Leixin Coating Equipment Co., Ltd., established in 2011 and located in Huzhou, Zhejiang, China, proudly presents our Industrial Curing Oven for Composite Material Bonding and Automotive Parts Post-Cure Process. As a dedicated manufacturer with over a decade of experience, we have engineered this curing oven to meet the rigorous demands of advanced composite manufacturing and automotive production lines. Our oven ensures precise and uniform heat distribution, enabling superior bond strength in composite structures and optimized post-cure properties for automotive components. With a factory spanning 1,000–3,000 square meters and a skilled team of 51–100 employees, we deliver reliable, high-performance thermal processing solutions that enhance product quality and production efficiency.

Key Features and Technical Specifications

Robust Construction: Built with stainless steel or carbon steel panels, the oven withstands rigorous industrial environments and offers excellent corrosion resistance. Optional inner liner material is available upon request.
Precise Temperature Control: Equipped with a PLC-based control system and a high-accuracy PID controller, the oven maintains temperature within ±1°C of the set point. The digital HMI touchscreen provides intuitive programming and real-time monitoring.
Uniform Heat Distribution: Advanced air circulation design with horizontal or vertical airflow ensures temperature uniformity of ±3°C throughout the work chamber, critical for consistent curing of composite materials and automotive parts.
Flexible Heating Options: Standard electric heating with optional gas-fired burner systems. Multiple heating zones are customizable to match specific process profiles.
Large Working Capacity: Internal dimensions are fully customizable to accommodate parts from small brackets to large body panels. Standard sizes range from 1,000 × 1,000 × 1,000 mm to 2,500 × 2,500 × 2,500 mm.
Safety and Compliance: Over-temperature protection, emergency stop, door safety interlock, and audible alarm systems are included. The oven meets ISO9001 quality management standards.
Energy Efficiency: High-density mineral wool insulation with thickness of 100–150 mm reduces heat loss and lowers operating costs. Energy-saving recirculation fans are standard.

Technical Specifications Table

Parameter	Details
Temperature Range	Ambient to 300°C (higher on request)
Temperature Uniformity	±3°C (at 200°C, per ASTM)
Heating Rate	Up to 10°C/min (electric)
Control System	PLC + PID + HMI (Siemens or Schneider optional)
Airflow Type	Horizontal / Vertical (selectable)
Power Supply	380V / 220V / 440V, 3-phase, 50/60Hz
Insulation Thickness	100–150 mm mineral wool
Door Type	Manual swing / Vertical lift / Double door
Certification	ISO9001

Applications and Customer Benefits

Composite Material Bonding: Ideal for curing epoxy, phenolic, and polyurethane adhesives used in aerospace, marine, and wind energy composites. The uniform heating eliminates hot spots, reducing scrap and rework.
Automotive Parts Post-Cure: Perfect for post-curing of carbon fiber panels, battery enclosures, and underhood components. Precise ramp-and-soak profiles ensure maximum dimensional stability and mechanical properties.
R&D and Pilot Production: Programmable cycles allow easy replication of cure schedules for new product development.
Cost Savings: Energy-efficient design and modular construction lower total cost of ownership. Optional data logging software helps optimize process parameters.

Why Choose Deqing Leixin?

Since 2011, Deqing Leixin Coating Equipment Co., Ltd. has been a trusted manufacturer in the thermal processing industry. Our annual export value of US$1–1.5 Million demonstrates our ability to serve clients across North America, South America, Europe, Asia, Africa, and Oceania. With a dedicated team of 51–100 employees and ISO9001-certified production processes, we deliver ovens that consistently meet or exceed international standards. Our factory in Huzhou, Zhejiang, allows convenient shipment from Ningbo and Shanghai ports. We provide comprehensive after-sales support, including installation commissioning, remote troubleshooting, and spare parts supply. Invest in our Industrial Curing Oven to elevate your composite bonding and automotive post-cure processes — contact us for a customized solution tailored to your specific needs.

Frequently Asked Questions

Q: Can this oven handle very large automotive parts?
A: Yes, internal dimensions are fully customizable. We can design a chamber up to 3,000 × 3,000 × 3,000 mm or larger to accommodate body panels, bumpers, or complete sub-assemblies.
Q: What is the typical heating time to 200°C?
A: With electric heating and standard insulation, the oven reaches 200°C from ambient in approximately 20–30 minutes, depending on load and chamber volume. Gas heating offers faster ramp rates.
Q: Do you offer validation or temperature mapping services?
A: Yes, we provide temperature uniformity testing (9-point or 16-point) upon request to comply with industry standards. Documentation is included.
Q: Can the control system be integrated with an existing MES?
A: Our PLC-based system supports communication protocols such as Modbus, Profibus, and Ethernet/IP for integration with your Manufacturing Execution System. Customization is available.
Q: What type of composite materials are compatible?
A: The oven is suitable for epoxy, phenolic, polyimide, and polyester resin systems used in carbon fiber, glass fiber, and aramid composite bonding. It also works for thermoset adhesive curing.
Q: What safety features are included?
A: Standard safety items include over-temperature limit controller, emergency stop button, door interlock, and audible alarm. Explosion-proof options are optional for solvent-based processes.
Q: What is the warranty period?
A: We offer a standard 12-month warranty from the date of commissioning, covering parts and labor. Extended warranty plans are negotiable.
Q: How do you handle international shipping and installation?
A: We ship via Ningbo or Shanghai port with proper export packaging. On-site installation and training can be arranged at additional cost. Remote support is always available.
