Deqing Leixin Coating Equipment Co., Ltd., a professional manufacturer since 2011 with ISO9001 certification, proudly presents our Industrial Powder Coating Oven Gas Powder Curing Oven for Batch Production. Designed for efficient and uniform curing of powder-coated parts, this oven is built to meet the demanding needs of batch production lines. With a factory area of 1,000–3,000 square meters and a dedicated team of 51–100 skilled employees, we deliver reliable, high-performance curing solutions trusted by clients across North America, Europe, Asia, and beyond. Our gas-powered oven ensures consistent heating, energy savings, and a fast return on investment – the ideal choice for your finishing operations.
This oven features a robust steel structure with multi-layer mineral wool insulation to minimize heat loss. The gas-fired burner system provides rapid temperature recovery and uniform heat distribution, ensuring every part reaches the required curing profile. Equipped with a PLC-based control panel (optional), operators can precisely set and monitor temperature curves, curing time, and airflow. The spacious chamber (customizable dimensions) accommodates large batches of parts on racks or trolleys, maximizing productivity. Safety features include over-temperature protection, gas leak detection, and emergency stop.
Key Features & Specifications
Fuel Type: Natural gas or LPG – clean, efficient, and cost-effective for continuous operation.
Temperature Range: 140°C to 250°C (adjustable), suitable for most common powder coatings (epoxy, polyester, hybrid, etc.).
Heating System: Direct or indirect gas-fired burner with high-efficiency heat exchanger (optional).
Temperature Uniformity: ±5°C across the chamber, achieved via optimized airflow design and multiple thermocouples.
Airtight Construction: Sealed doors and insulated panels reduce energy consumption by up to 30% compared to older models.
Control System: Advanced PID controller with touchscreen interface (optional) for recipe storage, data logging, and remote monitoring.
Safety Components: Auto flame failure shutdown, high-limit thermostat, gas solenoid valve, and audible alarm.
Loading Configuration: Manual roll-in carts, overhead monorail, or forklift-compatible base – customizable to your workflow.
Finish: Powder-coated exterior for corrosion resistance; interior reflective coating for better heat retention.
| Parameter | Value |
|---|---|
| Heating Capacity | 100,000 – 500,000 BTU/hr (customizable) |
| Chamber Dimensions (W×D×H) | 1.5m × 2m × 2m (standard); other sizes available upon request |
| Rated Power | Gas consumption: 5–20 m³/hr (depending on capacity) |
| Curing Time | 10–30 minutes (adjustable by temperature and part mass) |
| Weight | Approx. 1,200 – 3,000 kg |
Why Choose Deqing Leixin Batch Curing Oven?
Uniform Curing: Our proprietary air circulation system eliminates cold spots, ensuring consistent coating adhesion and gloss.
Energy-Efficient: Thick insulation (100–150mm) and tight seals reduce gas usage and shorten cycle times.
Customizable: We adapt oven size, heating capacity, and loading method to your specific batch production needs.
Easy Operation: Simple interface allows workers to set recipes with minimal training; optional automation for larger lines.
Durable Build: Steel frame and high-temperature resistant seals provide long service life even under 24/7 operation.
Compliance: Manufactured under ISO9001 quality management system, meeting international safety standards.
Trust & Reliability: Deqing Leixin Coating Equipment Co., Ltd. is an ISO9001-certified manufacturer with over a decade of experience. With an annual export value of US$1–1.5 million, we serve clients in more than 15 countries across North America, South America, Europe, Africa, and Asia. Our 51–100 skilled workers ensure rigorous quality checks at every stage – from raw material inspection to final testing. Each oven is test-run before shipment, and we provide comprehensive technical documentation and remote support. Contact us today for a customized batch powder curing solution that boosts your production efficiency and product finish quality!
Frequently Asked Questions
Q: What types of powder coating can this oven cure?
A: It is suitable for most thermosetting powders including epoxy, polyester, polyurethane, and hybrid types. The adjustable temperature range (140°C–250°C) covers common curing schedules.Q: How long does it take to cure a batch of parts?
A: Typical curing time is 10–30 minutes, depending on part thickness, coating type, and target temperature. Our oven design ensures rapid heat recovery to minimize overall cycle time.Q: Can I use this oven with other fuels like propane or diesel?
A: Yes, the burner system can be configured for natural gas, LPG, or propane. For diesel or oil, please consult our sales team for customization.Q: What safety features are included?
A: Standard safety features include flame failure protection, over-temperature limit switch, gas leak detection sensor, emergency stop button, and an audible alarm. Additional sensors can be added upon request.Q: Is the oven easy to install and maintain?
A: Yes, we provide detailed installation manual and online support. The oven comes with modular panels for easy assembly. Routine maintenance includes cleaning the burner, checking seals, and verifying thermocouple accuracy.Q: Do you offer a warranty?
A: We provide a standard 12-month warranty against manufacturing defects. Extended warranty options are available. Contact us for terms.Q: What is the lead time for a custom-size oven?
A: Typically 30–45 days after receiving deposit and final specifications. Standard models may ship faster. Shipping is from Ningbo or Shanghai ports.Q: Do you have references or case studies?
A: Yes, we have supplied batch curing ovens to automotive, furniture, and general metal finishing industries worldwide. We can share customer testimonials upon request.
