Qingdao Yongke Machinery Co., Ltd. is proud to present our advanced Double Wall Corrugated Pipe Extrusion Line specifically designed for producing HDPE spiral drain pipes. As a manufacturer with over a decade of experience since 2010, we combine German engineering principles with Chinese manufacturing efficiency to deliver reliable, high-output equipment. Our extrusion line ensures uniform wall thickness, excellent ring stiffness, and smooth inner surface, making it ideal for underground drainage, sewage systems, and stormwater management projects. With a factory spanning 10,000-30,000 square meters, we have the capacity to meet bulk orders while maintaining strict quality control.
Key Features and Technical Specifications
High-Efficiency Extrusion System: Equipped with a specially designed screw and barrel made of 38CrMoAlA alloy steel, hardened and nitrided for extended service life (up to 3 years continuous operation). The forced feeding section ensures stable material flow even with recycled HDPE content up to 30%.
Advanced Double Wall Corrugated Molding: Our patented mold cooling system reduces cycle time by 15% compared to conventional designs. The forming machine uses vacuum forming technology to create precise corrugated outer walls and smooth inner walls simultaneously.
PLC Touch Screen Control: Siemens brand PLC with a 10-inch color touch screen allows operators to monitor and adjust parameters such as temperature (5 zones), screw speed, haul-off speed, and cooling water flow in real time. Auto fault diagnosis reduces downtime.
Energy-Saving Drive: All motors are IE3 premium efficiency class, integrated with inverter drives to reduce power consumption by up to 20% under variable load conditions.
Versatile Pipe Production: Our line can produce double-wall corrugated pipes with nominal diameters from 200mm up to 1200mm (optional 1600mm upon request). Wall thickness can be adjusted from 2mm to 15mm according to SN4/SN8/SN12.5 ring stiffness classes.
Complete Auxiliary Equipment: Includes automatic loading system (with dehumidifier for HDPE), spiral cooling tank (length: 12m-24m), caterpillar haul-off (frequency control), planetary cutter (automatic length measurement), and pipe stacker.
| Parameter | Value |
|---|---|
| Extruder Model | SJ-75/33 to SJ-150/33 |
| Screw Speed (max) | 120 rpm |
| Heating Zones | 5-7 zones |
| Total Installed Power | 80-220 kW |
| Machine Dimensions (L×W×H) | 35m × 5m × 3.5m (approx.) |
| Pipe Length | 1m to 6m (adjustable by cutter) |
Benefits for Your Business:
Reduced Operating Costs: High output of up to 500 kg/h combined with energy-saving motors minimizes your per-meter production cost. Our line can process both virgin and recycled HDPE, allowing you to source cheaper raw materials without sacrificing quality.
Superior Pipe Quality: The double-wall structure provides high ring stiffness (up to SN12.5) while using 30% less material than solid wall pipes of same stiffness. Smooth inner wall reduces frictional losses, improving hydraulic performance.
Easy Maintenance: Modular design allows quick mold change (within 2 hours) for different pipe diameters. All wear parts are standard and available from local suppliers.
Compliance with International Standards: Our pipes meet ASTM F2648, EN 13476, and GB/T 19472.2 standards (standard variants available). We provide full documentation for export certification.
Trust and Reliability – Backed by Qingdao Yongke Machinery
Since 2010, Qingdao Yongke Machinery has delivered over 200 extrusion lines to 40+ countries, including North America, Europe, Southeast Asia, and Africa. In 2023 alone, we exported equipment worth over US$1.5 million. Our factory is ISO9001, ISO14000, and OHSAS18001 certified, ensuring consistent quality control from raw material inspection to final testing. Each line undergoes 48-hour continuous trial run before shipment, and we provide free training for your operators (onsite or via video).
Frequently Asked Questions (FAQ)
Q: What is the minimum order quantity for this extrusion line?
A: We accept single line orders. However, for cost savings, we recommend ordering at least one complete line plus mold sets for 2-3 pipe diameters.Q: Can this line produce pipes with different ring stiffness classes?
A: Yes, by adjusting the wall thickness through haul-off speed and vacuum level, you can produce SN4, SN8, SN12.5, and custom stiffness grades.Q: How long does delivery and installation take?
A: Standard delivery is 45-60 days after order confirmation. Installation and commissioning at your site takes 10-15 working days, plus operator training.Q: What spare parts should we keep in stock?
A: We recommend having one set of heating elements, a spare screw tip, seals, and electric spare parts (fuses, contactors). We provide a recommended spare parts list with the manual.Q: Do you offer a warranty?
A: Yes, a 2-year warranty on mechanical parts and 1 year on electrical components. We provide lifetime technical support via email/phone.Q: Can the line be customized for larger diameters?
A: Yes, we can design molds and die heads for DN1600 pipes. Please contact our sales team for a customized quotation.Q: What type of raw material is suitable?
A: HDPE (PE80 or PE100) with melt flow index (MFI) 0.3-0.7 g/10min. Recycled HDPE can be used when mixed with virgin material at a ratio not exceeding 30%.Q: How do you handle after-sales service?
A: We have a dedicated after-sales team. For overseas clients, we provide remote assistance via video call and can dispatch engineers upon request (cost covered by client).
