As a leading manufacturer established in 2015, Qingdao Conqinphi Environmental Technology Group specializes in providing advanced and reliable environmental solutions. Our MVR Evaporator Equipment represents our commitment to innovation and sustainability, designed to deliver exceptional energy efficiency and operational reliability for industrial concentration and wastewater treatment processes. With a factory spanning over 10,000 square meters and a dedicated team, we ensure every unit is built to the highest standards, supported by comprehensive documentation including a Mill Test Report and a detailed Installation Guide.
This equipment utilizes Mechanical Vapor Recompression (MVR) technology, a highly efficient method for evaporation. Unlike traditional multi-effect evaporators, an MVR system reuses the vapor generated during boiling by mechanically compressing it, raising its temperature and pressure so it can be reused as the heating steam. This closed-loop process drastically reduces energy consumption, primarily requiring only electrical power for the compressor.
Core Product Features & Technical Advantages:
- Superior Energy Efficiency: By recycling latent heat, our MVR evaporators can achieve steam economy ratios significantly higher than conventional systems, leading to substantial reductions in operational costs.
- Compact & Modular Design: The integrated design saves valuable floor space and allows for easier installation and future expansion, which is clearly outlined in our provided Installation Guide.
- Precise Process Control: Equipped with an advanced PLC and HMI (Human-Machine Interface) system, the equipment allows for fully automatic operation, precise temperature/pressure control, and remote monitoring capabilities.
- High-Quality Construction: Critical wetted parts are constructed from corrosion-resistant stainless steel (304 or 316L), with material quality verified by the accompanying Mill Test Report.
- Wide Application Versatility: Engineered to handle various feeds, including high-salinity wastewater, chemical solutions, and heat-sensitive food or pharmaceutical products.
- Environmentally Friendly: Minimizes wastewater discharge and reduces the carbon footprint associated with thermal processes.
Typical Technical Specifications & Configurations:
| Parameter | Specification / Option |
| Evaporation Capacity | 500 L/Hr to 50,000 L/Hr (Customizable) |
| Compressor Type | Centrifugal Fan / Roots Blower / Turbo Compressor |
| Heat Exchanger Type | Falling Film / Forced Circulation (Selectable) |
| Operating Temperature | Typically 60°C - 100°C (Adjustable) |
| Vacuum System | Integrated for lower boiling points |
| Control System | PLC (Siemens/Mitsubishi) with Touch Screen HMI |
Benefits for Your Operation:
- Cost Savings: Drastically lowers energy consumption, often by 60-90% compared to single-effect evaporation, offering a rapid return on investment.
- Operational Simplicity: The detailed Installation Guide and automated controls reduce manual intervention and training requirements.
- Product Quality: Gentle evaporation conditions are suitable for heat-sensitive materials, preserving product integrity.
- Compliance & Traceability: The Mill Test Report provides full material traceability, supporting quality audits and regulatory compliance in industries like food and pharmaceuticals.
- Reduced Environmental Impact: Achieves zero-liquid-discharge (ZLD) goals and lowers overall plant utility demands.
Backed by our ISO9001-certified quality management system and nearly a decade of manufacturing expertise, Qingdao Conqinphi delivers equipment you can trust. Our significant annual export value to markets worldwide, including North America, Europe, and Southeast Asia, is a testament to the global acceptance of our technology and reliability. We don't just sell equipment; we provide a complete solution package—from engineering support to documentation—ensuring a smooth project lifecycle. Contact us today to discuss how our MVR Evaporator Equipment can optimize your process, reduce your costs, and enhance your sustainability profile.
Frequently Asked Questions (FAQ)
Q1: What is the main advantage of MVR technology over a traditional multi-effect evaporator?
A: The primary advantage is dramatic energy savings. An MVR system recompresses and reuses vapor, requiring primarily electrical energy for the compressor. A multi-effect evaporator requires a continuous input of fresh steam, leading to significantly higher energy consumption and cost.
Q2: What does the Mill Test Report include, and why is it important?
A: The Mill Test Report (MTR) is a certified document from the material manufacturer. It details the chemical composition, mechanical properties, heat treatment, and test results (like tensile strength) for the stainless steel plates and pipes used in your evaporator. It is crucial for quality verification, regulatory compliance, and maintenance of audit trails in regulated industries.
Q3: Is the installation process complicated? Do you provide on-site support?
A: Our equipment is designed for modularity to simplify installation. We provide a comprehensive, step-by-step Installation Guide covering foundation, piping, electrical connections, and commissioning checks. For complex projects, we can arrange for our engineers to provide on-site supervision and commissioning support, available upon request.
Q4: Can this evaporator handle high-viscosity or scaling-prone fluids?
A: Yes. We offer different evaporator body designs. For viscous or scaling solutions, a Forced Circulation (FC) type is often recommended over a Falling Film type. Our engineering team will analyze your feed characteristics during the design phase to recommend the most suitable and robust configuration.
Q5: What is the typical lead time for a standard unit?
A: Lead time depends on the capacity and customization level. For a standard design model, production typically takes 90 to 120 days after order confirmation and receipt of advance payment. We maintain efficient production scheduling across our large factory facility to meet delivery commitments.
Q6: Do you offer a performance guarantee or warranty?
A: Yes. We provide a standard warranty covering manufacturing defects for a specified period (e.g., 12 months from shipment). Furthermore, based on a clear process design agreement, we can offer performance guarantees for key parameters like evaporation capacity and specific energy consumption.
Q7: How does the control system work, and can it be integrated with our plant DCS?
A: The system is controlled by a programmable logic controller (PLC) with a user-friendly touchscreen interface. It manages startup, shutdown, parameter adjustment, and safety interlocks automatically. Standard communication protocols (like Modbus TCP/IP, Profibus) are available, allowing for seamless integration into your plant's existing Distributed Control System (DCS).
Q8: What after-sales services do you provide?
A: Our support extends beyond delivery. We offer remote technical assistance, readily available spare parts supply, and optional maintenance contracts. Our experienced team, backed by our presence in major global markets, is committed to ensuring the long-term, reliable operation of your equipment.
