Help CenterMVR Falling Film Evaporator System With PLC Control and 304 Stainless Steel Construction
Product Spotlights
Related Products
-
Custom-Designed MVR Falling Film Evaporator for Zero Liquid Discharge (ZLD) ProjectsUS$ 42600 - 58000MOQ: 1 Combo -
Automatic MVR Falling Film Evaporator With Integrated CIP Cleaning SystemUS$ 42600 - 58000MOQ: 1 Combo
-
MVR Evaporator With 2-Year Warranty and Technical SupportUS$ 520 - 85000MOQ: 1 Combo
-
304 Stainless Steel MVR Evaporator Equipment With PLC ControlUS$ 520 - 85000MOQ: 1 Combo
-
Automatic MVR Evaporator Equipment for Salt ProductionUS$ 520 - 85000MOQ: 1 Combo
As a leading manufacturer in environmental technology, Qingdao Conqinphi Environmental Technology Group is dedicated to providing advanced, reliable solutions for industrial separation and concentration processes. Our MVR Falling Film Evaporator System with PLC Control and 304 Stainless Steel Construction represents a significant leap in efficiency and operational control. Designed for demanding applications, this system leverages Mechanical Vapor Recompression technology to dramatically reduce energy consumption while ensuring consistent, high-quality output. We understand the critical need for durable and hygienic equipment, which is why we employ premium 304 stainless steel, making this system an ideal choice for industries ranging from food and pharmaceuticals to chemical processing and wastewater treatment.
The core of this system is its intelligent design and robust construction. The falling film evaporation principle ensures efficient heat transfer and minimizes product degradation, which is crucial for heat-sensitive materials. Coupled with a sophisticated PLC control system, operators gain unparalleled precision over the entire evaporation process, from temperature and pressure regulation to automated cleaning cycles (CIP). This level of automation not only enhances product consistency but also reduces labor costs and minimizes human error.
Key Technical Features & Specifications:
- Advanced MVR Technology: The heart of the system recompresses secondary vapor, raising its temperature and pressure to be reused as the primary heating source. This closed-loop design recovers over 90% of the latent heat, slashing steam consumption and operational costs compared to traditional multi-effect evaporators.
- Precision Falling Film Evaporation: The liquid feed distributes evenly as a thin film over the interior of the vertical tubes. This maximizes the surface area for heat exchange, leading to rapid evaporation, short residence time, and gentle treatment of the product.
- Fully Integrated PLC Control: The programmable logic controller allows for complete automation. Key parameters are monitored and adjusted in real-time, ensuring stable operation. The system features user-friendly HMI interfaces, data logging, alarm systems, and can be integrated into broader plant SCADA networks.
- Superior 304 Stainless Steel Build: All wetted parts are constructed from food-grade 304 stainless steel, offering excellent corrosion resistance, ease of cleaning, and compliance with stringent hygiene standards required in food, pharmaceutical, and high-purity chemical applications.
- Modular & Scalable Design: Systems are engineered with flexibility in mind. Capacities and configurations can be customized to match specific feed characteristics, concentration ratios, and final product requirements.
The following table outlines some typical configuration parameters available:
| Parameter | Specification / Option |
|---|---|
| Evaporation Capacity | Customizable (e.g., 500 - 50,000 kg/h water evaporation) |
| Heat Transfer Area | Designed based on capacity and duty |
| Operating Pressure | Vacuum to slightly above atmospheric |
| Final Product Concentration | Adjustable based on process needs |
| Power Supply | 380V/50Hz/3Ph or as per local standards |
| Utility Connections | Cooling water, electricity, instrument air |
Tangible Benefits for Your Operation:
- Substantial Energy Savings: MVR technology can reduce energy consumption by up to 80-90% compared to single-effect evaporation, offering a rapid return on investment.
- Enhanced Product Quality: Low-temperature, short-time processing in a falling film evaporator helps preserve the natural properties, color, and flavor of sensitive products.
- Reduced Environmental Footprint: Lower energy use translates to fewer greenhouse gas emissions. The system also produces a concentrated distillate, reducing wastewater volume for disposal.
- Lower Operational Costs: Automation reduces manual intervention, while the durable stainless steel construction minimizes maintenance downtime and extends equipment lifespan.
- Operational Reliability & Safety: The PLC system provides continuous monitoring, automatic shutdown sequences for fault conditions, and detailed operational records for quality assurance.
Backed by Qingdao Conqinphi's extensive manufacturing expertise in a facility spanning 10,000-30,000 square meters and supported by a dedicated team of 201-300 professionals, this MVR evaporator system is built to global standards. Our commitment to quality is reflected in our management systems, and we have successfully supplied equipment to markets worldwide, including North America, Europe, and Southeast Asia. With an annual export value reflecting our international reach, you can trust in our capability to deliver a robust, efficient, and cost-effective solution tailored to your specific concentration or recovery challenge. Contact us today to discuss how our PLC-controlled MVR Falling Film Evaporator can optimize your process and improve your bottom line.
Frequently Asked Questions (FAQ)
-
What is the primary advantage of MVR over a traditional multi-effect evaporator?
MVR systems use a mechanical compressor to reuse vapor, achieving very high thermal efficiency typically with only one evaporation effect. This often results in significantly lower energy consumption and a smaller physical footprint compared to multi-effect systems that require multiple bodies and external steam. -
Is the falling film design suitable for viscous or fouling liquids?
Falling film evaporators are excellent for low to medium viscosity, heat-sensitive fluids. For highly viscous or severely fouling materials, other designs like forced circulation may be recommended. We can advise on the best configuration during the project consultation phase. -
Can the PLC system be customized for our specific operational sequence?
Yes. The programmable logic controller is highly flexible. We can develop control logic, alarm setpoints, and human-machine interface (HMI) screens to match your exact process requirements and operator preferences. -
What kind of maintenance does this system require?
Routine maintenance includes checking mechanical seals, lubricating the compressor (if applicable), cleaning heat exchanger tubes via CIP, and calibrating instruments. The robust 304 stainless steel construction minimizes corrosion-related upkeep. A detailed maintenance schedule is provided. -
Do you offer different material grades besides 304 stainless steel?
Yes. While 304 SS is standard for many applications, materials like 316L stainless steel or duplex steels are available upon request for handling more corrosive process streams. -
How is the system shipped and installed?
We typically ship major components in modular skids to reduce on-site assembly time. We provide comprehensive general arrangement drawings, piping & instrumentation diagrams (P&IDs), and can offer technical supervision for installation and commissioning. -
What is the expected payback period for the energy savings?
The payback period varies based on local energy costs, system capacity, and hours of operation. In many cases, the substantial reduction in steam or cooling utility costs leads to a payback within 1 to 3 years. -
Can this system handle zero liquid discharge (ZLD) applications?
An MVR falling film evaporator is often a key component in a ZLD process train, used to concentrate brine to a high solid content. It is typically followed by a crystallizer or spray dryer to achieve complete solidification.
