I. IQS516 Multifunctional Process Calibrator
Product Introduction
The IQS516 multifunctional process calibrator is a thermal instrument calibration device that supports the measurement and output of multiple parameters including current, voltage, resistance, frequency, thermocouples and RTDs (Resistance Temperature Detectors). Featuring high accuracy, compact size and light weight, it can be easily operated with one hand. Only one unit is required to complete the calibration, maintenance and servicing of field secondary instruments, which greatly improves the efficiency of on-site instrument calibration work.
Product Features
● Supports measurement and output of current, voltage, frequency and resistance;
● Equipped with two mutually isolated channels for simultaneous measurement and output;
● Capable of simulating measurement and output of RTDs and thermocouples; cold junction temperature compensation is available for thermocouple measurement and output;
● Customizable thermocouple types can be developed upon request;
● Provides functions of manual stepping, automatic stepping, 0～100% step output and ramp output;
● Built-in 24 V DC loop power supply to facilitate power supply for on-site equipment commissioning;
● Reliable protective performance with IP67 waterproof rating; automatic protection is triggered if any signal terminal is mistakenly connected to 220 V;
● Dual-channel measurement displayed on upper and lower screens for current, voltage, resistance and millivolt signals.
Technical Specifications (Accuracy Class: 0.02%)
| Function | Measurement | Output |
|---|---|---|
| DC Voltage | (-30～30) V | (0～10) V |
| DC Current | (-24～24) mA | (0～24) mA |
| Frequency | 1.000 Hz～100.00 kHz | (0.00～20.000) kHz |
| Resistance | (0～3200) Ω | (0～3200) Ω |
| DC Millivolt | (-200～200) mV | (0～100) mV |
| RTD | Pt100, Pt1000, Cu50, Cu100 | — |
| Thermocouple | E, J, K, T, B, R, S, N | — |
| Others | Isolated loop power supply, stepping output, ramp output, step output, custom measuring ranges |
Other Parameters
● Operating Temperature: (-10～55) ℃● Storage Temperature: (-20～60) ℃● Weight: 600 g● Overall Dimensions: 210 mm × 100 mm × 50 mm● Power Supply: 6 pieces of AAA Ni-MH batteries or AC adapter
II. IQS518 Multifunctional Process Calibrator
Product Introduction
The IQS518 multifunctional process calibrator is a high-precision instrument for measuring and outputting process signals. It has two mutually isolated channels, which can simultaneously measure and output various industrial process signals such as voltage, current, resistance, thermocouple, RTD, frequency, pulse and switch signals. Equipped with built-in HART communication function, it can fully replace a HART communicator.
The IQS518 can substitute multiple measuring and calibrating instruments including current/voltage signal generators, resistance boxes, electronic potentiometers, frequency meters and HART communicators. It is mainly applied to on-site industrial signal calibration and fault diagnosis, as well as signal measurement and calibration in the chemical industry, military sector, various research institutes and laboratories.
Product Features
● Measurement & output: voltage, current, resistance, frequency, pulse and switch signals; current output supports both active and passive modes;
● Two mutually isolated channels for synchronous measurement and output;
● Supports manual step, automatic step, automatic stepping and manual stepping functions;
● RTD and thermocouple simulation functions available;
● Three cold junction temperature compensation modes (built-in, external and manual) for thermocouple measurement and output; the external reference terminal adopts Class A Pt100 platinum resistance;
● Built-in HART function to replace HART communicators for range configuration and calibration of smart transmitters;
● Supports standard temperature measurement via Pt25, Pt100 and Type S thermocouples.
Technical Specifications (Accuracy Class: 0.015%)
| Function | Measurement | Output |
|---|---|---|
| Voltage | (0～200) VAccuracy: ±(0.01% RD + 0.005% FS) | (0～10) VAccuracy: ±(0.01% RD + 0.005% FS) |
| Current | (0～200) mAAccuracy: ±(0.01% RD + 0.005% FS) | (0～30) mAAccuracy: ±(0.01% RD + 0.005% FS) |
| Frequency | 1.000 Hz～10.00 kHzAccuracy: 0.01% FS | (0.00～10.000) kHzAccuracy: 0.01% FS |
| Resistance | (0～5000) ΩAccuracy: ±(0.01% RD + 100 mΩ) | (0～5000) ΩAccuracy: ±(0.01% RD + 0.005% FS) |
| RTD | Pt100-385, Pt100-392, Pt100-JIS, Pt200-385, Pt500-385, Pt1000-385, Cu10, Cu50, Cu100, Ni120, BA1, BA2, Pt10 | — |
| Thermocouple | R, S, K, E, J, T, N, B, L, U, XK, WRE325, WRE526 | — |
| Others | Isolated loop power supply, stepping output, ramp output, step output, custom measuring ranges |
Other Parameters
● Operating Temperature: 20±2 ℃
● Storage Temperature: (-20～60) ℃
● Weight: 600 g
● Overall Dimensions: 210 mm × 105 mm × 55 mm
● Power Supply: Built-in 5000 mAh rechargeable lithium battery
Xiamen Jiangjing Technology Co., Ltd. (Jiangjing Technology for short)
Headquartered in Yuepu Innovation Center, Xiamen, Fujian Province, Xiamen Jiangjing Technology Co., Ltd. is an enterprise integrating R&D, production, sales and after-sales services that specializes in metrological calibration equipment. We professionally supply metrological calibration equipment for pressure, temperature, temperature and humidity, and provide customers with solutions for the construction and renovation of metrological calibration laboratories.
With our service network consisting of the headquarters in Xiamen, a Beijing R&D Center, Shanghai Operation Center, Guangdong Operation Center and Guiyang Operation Center, we have built a technical exchange platform and a rapid service response system, adhering to the customer-centric service philosophy in the long run.
Sticking to independent technological innovation, the company develops calibrators tailored for metrological calibration technicians. Our pressure, temperature as well as temperature & humidity products have obtained a number of patents and software copyrights.
Our corporate mission follows the IQS principle: Innovationthrough collaboration, superior product Quality, and premium Services.Our core value lies in delivering customized metrological calibration laboratory solutions and sustaining long-term services to meet clients’ evolving demands.Our corporate goal is to achieve win-win cooperation with partners and build a customer-oriented technology service enterprise.
The company has independently developed a full range of metrological calibration equipment covering pressure, temperature and humidity fields, including:IQS900-X Laboratory Rapid Calibration Device for Pressure Instruments,IQS800-X Portable Rapid Calibration Device for Pressure Instruments,IQS890 Metrological Verification & Calibration Device for Aneroid Barometers,IQS810-X Handheld Rapid Calibration Device for Pressure Instruments,IQS700 Fully Automatic Gas Pressure Generator,IQS830 Metrological Verification & Calibration Device for Gas Pressure Regulators,IQS60X Portable Intelligent Dry Block Calibrator,IQS30X Portable Precision Constant-Temperature Liquid Bath,IQSLH Temperature & Humidity Calibration Chamber,Wireless Temperature, Pressure and Humidity Data Loggers,IQS516 Multifunctional Process Calibrator.
Our products are widely adopted in metrology institutes, metallurgy, petroleum, chemical, nuclear power, electric power, food, pharmaceutical, railway, shipbuilding, higher education, aerospace, third-party calibration institutions, medical devices, machinery manufacturing and other industries. Some of our products have been exported to Argentina, Serbia, Brazil, the United States, Malaysia, the Philippines, South Korea, Thailand, Singapore, the Democratic Republic of the Congo and many other countries.
