CE Certified Industrial Microwave Drying and Sterilization System for Herbs Production Line
Industrial Microwave Dryer for Herbs – Fast Drying, Sterilization & Moisture Control
Looking for a reliable industrial herb drying and sterilization solution?
Our CE Certified Microwave Drying and Sterilization System for Herbs Production Line is specially designed for continuous drying, sterilizing, moisture reduction, and enzyme deactivation of herbs and botanical materials.
Using advanced microwave heating technology, the machine heats materials from inside to outside, allowing fast and uniform drying while preserving the natural color, aroma, nutrients, and active ingredients of herbs.
It is widely used for:
✔ Chinese herbal medicine drying
✔ Tea leaf drying & sterilization
✔ Flower drying
✔ Leaf drying
✔ Spice sterilization
✔ Botanical powder moisture reduction
✔ Medicinal plant processing
Compared with traditional hot-air drying, microwave drying shortens drying time significantly and improves production efficiency.
Main Advantages of Industrial Microwave Herb Drying Equipment
1. Fast and Uniform Drying
Microwave energy penetrates herbs directly and heats water molecules rapidly.
Benefits:
✔ Short drying cycle
✔ Uniform moisture removal
✔ Prevents overheating
✔ Improves production efficiency
✔ Suitable for continuous production line
Fresh herbs can be dried in minutes instead of hours.
2. Drying + Sterilization in One Machine
Microwave energy not only dries herbs but also sterilizes them during processing.
It helps reduce:
✔ bacteria
✔ mold spores
✔ insects
✔ microbial contamination
Especially suitable for export-grade herbal processing.
3. Preserve Herbal Quality
Low-temperature rapid drying helps preserve:
✔ natural color
✔ fragrance
✔ active ingredients
✔ medicinal value
✔ appearance quality
Very suitable for premium herbs.
Examples:
ginseng
chrysanthemum
rose petals
peppermint
moringa leaves
chamomile
herbal tea ingredients
SUS304 Stainless Steel Structure
The whole machine is made of food-grade Outokumpu SUS304 stainless steel.
Features:
✔ corrosion resistance
✔ hygienic production
✔ easy cleaning
✔ long service life
✔ suitable for GMP food and pharma processing
Optional:
SUS316 stainless steel
automatic feeding conveyor
cooling conveyor
humidity monitoring system
PLC intelligent control
touch screen operation
temperature monitoring
data recording system
Intelligent PLC Control System
The equipment supports intelligent automation:
✔ microwave power adjustable
✔ conveyor speed adjustable
✔ drying temperature control
✔ automatic alarm system
✔ production data monitoring
✔ batch parameter memory
Operator can easily control drying according to herb moisture and production capacity.
Suitable for factory continuous operation.
Applications of Microwave Drying and Sterilization System
Herbal & Botanical Processing
✔ Chinese medicine herbs
✔ tea leaves
✔ mint leaves
✔ basil
✔ moringa
✔ flower petals
✔ medicinal roots
✔ botanical extracts
Food & Spice Processing
✔ chili
✔ turmeric
✔ ginger powder
✔ garlic flakes
✔ pepper powder
Chemical & Agricultural Products
✔ plant fiber drying
✔ agricultural raw materials
✔ biomass drying
Herbs Pharma Microwave Machine Application：
1.Drying kinds of herbs in microwave, it can dry fast, but preserve their flavor, nutrition such as Parsley, rosemary, cilantro, oregano, sage, thyme etc.
2.Drying kind of herbal slices, 50% faster than normal heating, such as Astragalus, angelica, ginseng, aconite, habitat etc.
3.Drying kinds of insects, which can be used in pharma industry, such as Tenebrio molitor, barley pest, hermetia illucens.
4.Sterilize Pharma liquid, especially liquid type medicine.
Technical Specifications
Machine Model |
GS-20HMV |
GS-40HMV |
GS-60HMV |
GS-100HMV |
GS-200HMV |
Work Frequency |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
Rated Apparent Power |
≤25KW |
≤50KW |
≤75KW |
≤120KW |
≤240KW |
Output Power |
≥20KW |
≥40KW |
≥60KW |
≥100KW |
≥200KW |
Dehydration Capacity |
16-20kg/hour |
30-40kg/hour |
48-60kg/hour |
80-100kg/hour |
160-200kg/hour |
Work Process Temperature |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
Cooling Type |
Water Cool/Air Cool |
Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool |
Work Time |
24h Continuously Work |
24h Continuously Work | 24h Continuously Work | 24h Continuously Work | 24h Continuously Work |
Operation |
PLC & Touch Screen |
PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen |
Feeding Inlet Height |
40-100mm |
40-100mm | 40-100mm | 40-100mm | 40-100mm |
Belt Height |
60-1000mm |
60-1000mm | 60-1000mm | 60-1000mm | 60-1000mm |
Belt Running Speed |
0-4.5m/min or Customized |
0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized |
Belt Width |
500±100mm |
800±100mm |
800±100mm |
1000±100mm |
1200±100mm |
Belt Material |
Teflon Material or Customized |
Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized |
Size |
8640×1220×2200mm |
10960×1500×2200mm |
13200×1500×2200mm |
15600×1700×2200mm |
22560×1900×2200mm |
Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request.
Why Buyers Choose Our Industrial Microwave Herb Dryer
✔ CE certified export machine
✔ energy-saving microwave technology
✔ continuous automatic production
✔ drying + sterilization combined
✔ customized capacity available
✔ factory direct supply
✔ professional engineering support
✔ overseas installation support
✔ stable performance
✔ suitable for large-scale industrial production
Frequently Asked Questions：
Q1: Can this machine dry different herbs?
Yes.
It can dry leaves, flowers, roots, powder and botanical ingredients.
Q2: Does microwave drying damage herbal ingredients?
No.
Fast low-temperature drying helps maintain active ingredients better than traditional drying.
Q3: Can you customize machine size?
Yes.
We provide customized microwave systems based on:
material type
moisture level
required output
factory space
local voltage
Q4: Is overseas installation available?
Yes.
Professional engineers can support installation, testing and training.
Send Inquiry Now
Need a CE certified industrial microwave drying and sterilization system for herbs production line?
Contact us now for:
✔ quotation
✔ customized design
✔ factory solution
✔ technical drawings
✔ video demonstration
✔ installation support
Industrial Microwave Drying Machine Manufacturer – Reliable Partner for Herb Processing Production Line
China Gspring Machinery are the manufactuer of Industrial Microwave Dryer, we can supply different kinds of microwave drying machine, like batch
microwave oven for lab use or for small capacity industrial use, industrial automatic tunnel mircrowave dryer, vaccum dryer specially for food & pharma
industry etc. We havemore than 10 years experience on export, export to all over the world, like USA, Canada, Russia, India, Sri Lanka, Turkey, Vietnam,
Indonesia, Pakistan,Philippines, Brazil, Egypt, Czech, Singapore, Armenia, Iraq, Iran, Malaysia, Bangladesh, Mexico, Peru, Algeria, Poland, Thailand, Nepal, Azerbaijan etc.
We are the professional supplier for high quality industrial microwave oven if any questions about the machine, pls email
