As a leading manufacturer in trenchless rehabilitation technology since 2010, Qingdao Yongke Machinery is proud to present our advanced UV CIPP Liner Installation Equipment. Engineered for efficiency and reliability, this system is designed to revolutionize pipe rehabilitation projects by significantly reducing curing times compared to traditional steam or hot water methods. Our equipment integrates high-intensity UV light technology with precise control systems, enabling contractors to complete pipe lining projects faster, with consistent quality and reduced environmental impact. Built in our modern 10,000-30,000 square meter facility by a team of experienced engineers, this equipment represents the culmination of over a decade of specialization in pipeline rehabilitation solutions for global markets.
The core of our system is the high-performance UV curing unit, which delivers rapid and uniform curing of the resin-impregnated CIPP liner inside the host pipe. This process transforms a flexible liner into a strong, jointless, and corrosion-resistant new pipe within the old one. The speed of UV curing not only accelerates project timelines but also minimizes traffic disruption and lowers overall project costs, making it an economically superior choice for municipalities and utility contractors.
- High-Efficiency UV Lamp Array: Features a modular design of high-output UV lamps (typically 365-405 nm wavelength) that provide intense, uniform light coverage. Lamp life and output are continuously monitored by the system.
- Intelligent Curing Control: The PLC-based system allows operators to program curing profiles based on pipe diameter, liner thickness, and resin type. It automatically adjusts UV intensity and winch pull-back speed for optimal results.
- Robust Winch & Pull-in System: A powerful, variable-speed winch system carefully inserts the UV light train and liner into the pipe. It ensures smooth, controlled movement without damaging the liner.
- Comprehensive Safety Suite: Built-in safety is paramount. The system includes emergency stop buttons, UV light containment shields, real-time temperature sensors within the curing zone, and ventilation controls to manage any fumes.
- Modular & Mobile Design: Available in trailer-mounted units for road mobility or skid-mounted frames for easy transport to site. The modular design facilitates maintenance and allows for future upgrades.
- Data Logging & Reporting: The system records all critical curing parameters (time, temperature, UV dose, distance) for each project, providing verifiable quality assurance reports for clients.
The advantages of choosing our UV CIPP equipment translate directly into benefits for your business and your clients.
| Feature / Advantage | Benefit to the Contractor/Client |
| Fast UV Curing Process | Dramatically reduces project duration. Curing can be completed in minutes to a few hours, allowing for multiple installations per day and faster return-to-service. |
| Energy Efficient Operation | Consumes significantly less energy than thermal curing methods, leading to lower operational costs and a smaller carbon footprint. |
| Consistent, High-Quality Results | Programmable curing ensures uniform resin polymerization throughout the liner, resulting in a pipe with consistent wall strength and minimal risk of uncured spots. |
| Minimal Site Footprint & Disruption | The trenchless nature, combined with quick curing, means less excavation, reduced traffic control needs, and less disturbance to businesses and residents. |
| Versatile Application Range | Suitable for rehabilitating pipes from 100mm (4") to 1200mm (48") in diameter, commonly used in sewer, stormwater, and some pressure pipe applications. |
Frequently Asked Questions (FAQ)
-
Q: How does UV curing compare to traditional steam curing in terms of final liner strength?
A: When performed correctly with the appropriate resin and UV dose, UV-cured liners achieve equal or superior mechanical properties (e.g., flexural modulus, tensile strength) to steam-cured liners. The key advantage is the speed and control of the process. -
Q: What is the typical curing time for a 200-meter, 300mm diameter pipe section?
A: Curing time depends on liner thickness and resin formulation. For a standard 6mm liner, our equipment can typically cure at a rate of 0.5 to 1.5 meters per minute. Therefore, a 200m section could be fully cured in approximately 3 to 7 hours of active UV exposure, far faster than traditional methods. -
Q: Is special training required to operate this equipment?
A: Yes. While the control system is user-friendly, we strongly recommend and provide comprehensive operator training. This covers system setup, safety protocols, curing profile programming, routine maintenance, and troubleshooting to ensure optimal and safe project execution. -
Q: Can this equipment cure all types of CIPP liner resins?
A: No. It is specifically designed for UV-curable resins, which are typically polyester, vinyl ester, or epoxy-based formulations activated by UV light. It is not suitable for thermal-cure resins used in steam or hot water systems. -
Q: What kind of power supply is needed on site?
A: Most standard models require a stable 380V/50Hz or 480V/60Hz three-phase power connection. Specific power requirements can be discussed based on your regional standards and the chosen equipment configuration. -
Q: Do you offer after-sales support and spare parts?
A: Absolutely. As an established manufacturer, we maintain a global supply network for critical spare parts like UV lamps, electronic components, and wear parts. We offer remote technical support and can arrange on-site service visits if needed. -
Q: Is the equipment suitable for use in curved pipes or pipes with bends?
A: Yes, within reasonable limits. The equipment is designed to navigate standard bends commonly found in pipeline networks (e.g., 45-degree, 90-degree bends). The flexibility of the liner and the design of the UV train allow for installation through curved sections, though curing consistency in sharp bends should be evaluated during project planning.
Backed by our commitment to quality evidenced by ISO9001 and ISO14000 certifications, and supported by an annual export value exceeding US$1 million to markets across North America, Europe, Asia, and beyond, Qingdao Yongke Machinery stands as a reliable partner. Our equipment is not just a tool; it's a productivity multiplier for your trenchless rehabilitation business. By investing in our UV CIPP Liner Installation Equipment, you are choosing a solution engineered for speed, reliability, and superior project outcomes. Contact us today to discuss how this system can be configured for your specific application and to request a detailed quotation.
