Help CenterFull Port Flanged Ball Valve With Locking Device for Secure Operation
Product Spotlights
Related Products
-
304 Stainless Steel Flanged Ball Valve DN50 PN16 for Water TreatmentNegotiableMOQ: 1 Piece -
Oil & Gas Pipeline Flanged Ball Valve With Fire-Safe Design API 607NegotiableMOQ: 1 Piece
-
PTFE Seated Flanged Ball Valve for Chemical Media With Mill Test ReportNegotiableMOQ: 1 Piece
-
Flanged Ball Valve With 2-Year Warranty and Technical Support PackageNegotiableMOQ: 1 Piece
-
DN15-DN300 Flanged Ball Valve With Worm Gear Drive for Industrial PipingNegotiableMOQ: 1 Piece
Shanghai CAMP Environmental Protection Technology Co., Ltd., established in 2015, specializes in delivering industrial fluid control solutions to global markets. Our Full Port Flanged Ball Valve with Locking Device is engineered for operations demanding uncompromised security and optimal flow efficiency. Designed to meet rigorous industrial requirements, this valve ensures reliable performance in critical applications while providing enhanced safety through its integrated locking mechanism.
Core Technical Specifications:
- Full Bore Design: Minimizes pressure drop and allows full pipeline pigging
- Robust Construction: Forged body with ASTM standards-compliant materials
- Fire-Safe Option: Optional soft seat replacement system available
- Anti-Static Design: Ensures static electricity discharge for hazardous environments
| Nominal Size | Pressure Class | Torque Requirement |
| DN15-DN50 | PN16/Class150 | ≤50 Nm |
| DN65-DN150 | PN16/Class150 | ≤350 Nm |
| DN200-DN300 | PN16/Class150 | Gear Operator Recommended |
Operational Advantages:
- ⛓️ Security Lock: Integrated lock tab prevents unauthorized operation
- 🔧 Maintenance-Friendly: Top-entry design for in-line servicing
- 🔄 Bidirectional Sealing: Equal sealing performance in both flow directions
- 🧪 Chemical Resistance: PTFE seats compatible with aggressive media
With established supply networks across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, and Domestic Market, our solutions are trusted by industrial operators worldwide. This valve represents our commitment to delivering security-focused flow control technology that reduces operational risks.
FAQ Section:
Q: What is the purpose of the locking device?
A: The integrated lock tab allows padlock application to prevent unauthorized valve operation, crucial for safety-critical processes.
Q: Is this valve suitable for steam applications?
A: Yes, with standard temperature range of -20°C to 200°C. Extended range options available upon request.
Q: Can it handle abrasive slurries?
A: While standard seats work for most media, hardened seat versions are available for abrasive service.
Q: Are different flange standards accommodated?
A: Yes, we provide ANSI, DIN, JIS, and other flange standards as required.
Q: What maintenance is required?
A: Our top-entry design allows seal replacement without pipeline removal. Lubrication intervals vary by service conditions.
Q: Is fire-safe certification available?
A: Fire-safe tested models meeting API 607 standards can be provided.
Q: Can the valve be automated?
A: Yes, it's compatible with pneumatic/electric actuators. Mounting pads are standardized per ISO 5211.
Q: What is the lead time for DN200 valves?
A: Standard sizes ship in 15-20 days. Contact for exact delivery schedule.
