Help CenterHigh-Pressure Flanged Ball Valve 10.0MPa With Manual/Gear Operation
Product Spotlights
Related Products
-
CF8M 316 Stainless Steel Flanged Ball Valve -20℃ to 400℃ Temperature RangeNegotiableMOQ: 1 Piece -
Food Grade Flanged Ball Valve With Polished Bore for Dairy ProcessingNegotiableMOQ: 1 Piece
-
Low-Torque Y-Type Three-Way Ball Valve With NEMA 4X Pneumatic Actuator for Harsh EnvironmentsNegotiableMOQ: 1 Piece
-
Food-Grade Pneumatic Y-Type Three-Way Ball Valve for Dairy Processing LinesNegotiableMOQ: 1 Piece
-
Maintenance-Free Pneumatic Y-Type Three-Way Valve With Hardened 316L Ball for Abrasive SlurriesNegotiableMOQ: 1 Piece
Shanghai CAMP Environmental Protection Technology Co., Ltd., established in 2015, specializes in providing robust industrial solutions for global markets including North America, Europe, Asia, and beyond. Our High-Pressure Flanged Ball Valve is engineered to meet the rigorous demands of high-pressure applications while ensuring operational reliability. With dual manual and gear operation modes, this valve delivers exceptional performance in critical systems where safety and precision are non-negotiable.
Core Technical Specifications:
- Pressure Performance: Designed for sustained 10.0MPa operation with tested burst pressure exceeding 15.0MPa
- Structural Integrity: Full-bore design minimizes pressure drop and eliminates flow turbulence
- Fire-Safe Design: Secondary metal sealing ensures emergency shut-off during extreme conditions
- Anti-Blowout Stem: Integrated stem safety mechanism prevents accidental disengagement
| Parameter | Specification |
|---|---|
| Temperature Range | -29°C to 200°C |
| Flow Coefficient (Cv) | Up to 4500 (DN300) |
| Gearbox Ratio | 15:1 / 20:1 (Optional) |
Material Advantages:
The valve body utilizes ASTM A216 WCB carbon steel with 200μm electrostatic epoxy coating for corrosion resistance. Ball surfaces undergo HVOF (High-Velocity Oxygen Fuel) tungsten carbide coating, achieving surface hardness of 70 HRC for superior erosion resistance.
Operation Features:
- Manual Override: All gear-operated units include ISO 5211 mounting pad for manual intervention
- Position Indicators: Visual open/close indicators with mechanical position transmission
- Low Torque Design: PTFE-encapsulated bearings reduce operating torque by 40% vs standard designs
Trusted by clients across 15 global markets from Oceania to Northern Europe, our valves undergo stringent quality verification including hydrostatic testing at 1.5x working pressure and helium leak testing. The dual-operation flexibility provides operational continuity assurance - manual mode for regular maintenance and gear operation for automated process control integration.
FAQs:
Q: Can this valve handle frequent pressure surges above 10.0MPa?
A: Designed with 150% pressure safety margin, occasional surges up to 15.0MPa are permissible per API 598 standards.
Q: What determines choice between manual vs gear operation?
A: Manual suits valves below DN100 with accessible locations. Gear operation is recommended for larger sizes (DN150+) or automated systems.
Q: Are alternative materials available?
A: Stainless steel (CF8M) and duplex versions can be provided upon request for corrosive media applications.
Q: What is the delivery lead time?
A: Standard sizes ship in 3-5 weeks. Non-standard configurations require 8-10 weeks for manufacturing.
