Help CenterFood-Grade Wafer Butterfly Valve With Sanitary Design for Beverage Production Lines
Product Spotlights
Related Products
-
EPDM Seated Wafer Butterfly Valve for Water Treatment and Chemical ProcessingNegotiableMOQ: 1 Piece -
DN50-DN600 Wafer-Type Butterfly Valve With Gear Operator for Industrial Piping SystemsNegotiableMOQ: 1 Piece
-
Fire-Safe API 607 Certified Wafer-Type Butterfly Valve for Hazardous EnvironmentsNegotiableMOQ: 1 Piece
-
Compact Wafer-Style Butterfly Valve With Lever Handle for HVAC SystemsNegotiableMOQ: 1 Piece
-
10-Year Warranty Wafer Butterfly Valve With Mill Test Report for Oil & Gas IndustryNegotiableMOQ: 1 Piece
Shanghai CAMP Environmental Protection Technology Co., Ltd., established in 2015, specializes in providing premium sanitary solutions for global beverage production facilities. Our food-grade wafer butterfly valve delivers exceptional hygiene performance through its crevice-free design and polished surfaces, preventing bacterial growth in critical processing lines. Engineered for CIP/SIP compatibility, this valve maintains product purity while reducing maintenance downtime.
Core Technical Specifications:
- Zero dead space construction eliminates product trapment areas
- Electropolished surfaces achieve Ra≤0.8μm surface roughness
- PTFE-free EPDM seals comply with FDA 21 CFR 177.2600
- Bubble-tight shutoff ensures leak-free operation
- 360° radial seal design withstands thermal cycling
| Size (DN) | Torque (Nm) | Flow Coefficient (Cv) | Weight (kg) |
|---|---|---|---|
| 15-50 | 4-12 | 18-95 | 0.8-3.2 |
| 65-100 | 16-45 | 120-310 | 4.5-9.8 |
| 125-200 | 52-140 | 420-980 | 12-28 |
The valve's low-friction disc movement minimizes product shear while maintaining precise flow control. Integrated alignment pins ensure gasket protection during installation, and the symmetrical body design permits bidirectional flow without performance compromise. Optional position indicators and limit switches provide real-time operational feedback.
Backed by Shanghai CAMP's global distribution network serving 14 major markets including North America, Europe and Southeast Asia since 2015, this valve delivers proven reliability in juice, dairy and carbonated drink facilities. Our technical support team provides application-specific guidance to optimize your production efficiency. Contact us today for customized solutions matching your exact line requirements.
Frequently Asked Questions:
-
Q: Are these valves suitable for aseptic processing?
A: Yes, the full-face gasket design and polished surfaces meet strict aseptic standards. -
Q: What maintenance intervals are recommended?
A: Standard maintenance cycles are 6-12 months depending on media abrasiveness. -
Q: Can I retrofit existing pipelines?
A: The wafer design allows installation between existing DIN/ANSI flanges without modification. -
Q: Do you provide material certificates?
A: Mill test certificates are available upon request for all metallic components. -
Q: What's the lead time for custom sizes?
A: DN15-DN100 sizes ship in 15 days; larger diameters require 25 days production. -
Q: Are pneumatic actuators available?
A: Yes, we offer ISO 5211-compliant actuators with positioners and solenoid valves.
