Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma

Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma thumbnail-1
Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma thumbnail-2
Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma thumbnail-3
Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma thumbnail-4
Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma thumbnail-5
Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma photo-1
Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma photo-2
Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma photo-3
Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma photo-4
Sanitary V-Type Ball Valve With Tri-Clamp Ends for Pharma photo-5

Product Spotlights

Precision-engineered V-port design enables accurate flow control for pharmaceutical applications. Tri-clamp connections facilitate rapid installation and hygienic cleaning. Constructed with 316L stainless steel featuring Ra ≤0.8μm finish to prevent contamination. Withstands frequent CIP/SIP cycles and offers full material traceability. Reduces downtime in critical bioprocessing operations.
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, 316L Stainless Steel
Application:
Other, Pharmaceutical
Connection Type:
Tri-Clamp Ends
Contact Supplier Request Quote Chat Now
Shanghai CAMP Environmental Protection Technology Co., Ltd.
Platinum Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, 316L Stainless Steel
Application Other, Pharmaceutical
Connection Type Tri-Clamp Ends
Size Range 1/2“ to 4“ (DN15 to DN100)
Ball Design V-Type (V-Port)
Operating Pressure Up to 10 bar (145 psi)
Temperature Range -10°C to 150°C
Surface Finish Ra ≤ 0.8 μm (32 μin)
Actuation Type Manual or Automated

Shanghai CAMP Environmental Protection Technology Co., Ltd., established in 2015, proudly provides high-integrity fluid control solutions to global partners. Our sanitary V-Type ball valves with tri-clamp ends are engineered for precision flow control in critical pharmaceutical processes where hygiene and reliability are non-negotiable.

Designed with GMP standards in mind, this valve features a unique V-port ball that delivers exceptional linear flow characteristics and minimizes dead zones. The tri-clamp connections ensure swift installation and frequent cleaning cycles required in aseptic processing. As your trusted partner with distribution networks across 15 major markets worldwide, we deliver products meeting the stringent demands of bioprocessing and CIP/SIP systems.

Key Technical Specifications:

Parameter Specification
Pressure Rating 10 bar @ 120°C (Full vacuum rated)
Leakage Class ANSI/FCI 70-2 Class VI
Face-to-Face ISO 5211 / DIN 3202 F4

Critical Design Advantages:

  • Zero Dead Leg Design: Tri-clamp ends with optimized cavity depth prevent bacterial growth
  • Precise Flow Modulation: V-port ball provides linear flow characteristics (±5% deviation)
  • Sterilization Resilience: PTFE encapsulated stem seals withstand 50+ SIP cycles
  • Material Traceability: Full material certification available upon request

Backed by our experience serving pharmaceutical manufacturers across North America, Europe, and Asia-Pacific since 2015, we understand the critical nature of valve performance in sterile processes. Our technical support team provides:

  • Installation guidance for aseptic environments
  • Customization options for specific process requirements
  • Documentation packages including material certifications

Frequently Asked Questions:

  • Q: Is this valve suitable for steam-in-place (SIP) applications?
    A: Yes, the standard design withstands SIP cycles up to 150°C with optional high-temperature seals available.
  • Q: What documentation accompanies the valve?
    A: We provide material test certificates (3.1), certificates of conformity, and cleaning validation support documents.
  • Q: Are different V-port angles available?
    A: Standard V-port is 60° with optional 30°, 45°, and 90° configurations for specific flow characteristics.
  • Q: Can the valve be automated?
    A: Yes, we offer pneumatic and electric actuators compatible with all major automation systems.
  • Q: What is the lead time for custom configurations?
    A: Standard products ship in 2 weeks, while customized valves require 4-6 weeks depending on specifications.
  • Q: How does the V-port design improve performance?
    A: The V-shaped orifice provides precise flow control with minimal shear, ideal for sensitive biologics and shear-sensitive fluids.

With distribution capabilities spanning five continents through our Shanghai hub, we've supplied over 15,000 sanitary valves to pharmaceutical partners since 2015. Contact our technical team today to discuss how our V-Type ball valves can enhance your process efficiency while maintaining compliance with FDA 21 CFR Part 11 and EU GMP Annex 1 requirements.
