Economical Steel Coil Cut To Length Line Z2CL-6X1600 For Titanium Coil, High-strength Steel, Silicon Steel Coils
Product Spotlights
High Speed Moving Shear Cut-to-Length Line for Steel Coil
Ultra-fast Flying Shear Line Continuous Metal Cutting
High Efficiency Moving Shear Production Line
High Running Speed Servo Flying Shear Cut Line
Ultra-fast Flying Shear Line Continuous Metal Cutting
High Efficiency Moving Shear Production Line
High Running Speed Servo Flying Shear Cut Line
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Warranty:
12 mouths
Cooling System:
Air Cooling
After-sales Service:
All time
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
100 days
Related Products
-
Automatic Thick Plate Steel Coil Cut To Length Machine For 700L, High-strength Steel, Silicon Steel Coils,US$ 80000MOQ: 1 Set -
Intelligent Factory Cut to Length Machine/High Yield Metal Sheet Cut to Length LineUS$ 80000MOQ: 1 Set
-
Excellent Dimensional Accuracy & Consistency Cut to Length Machine Z2CL-14X2000US$ 70000MOQ: 1 Set
-
Automatic Stacking & Easy Subsequent Handling Cut To Length Line Machine Z2CL-12X2000US$ 50000MOQ: 1 Set
-
Cut To Length for H-Type Carbon Steel Coil ZCL-10X1800US$ 10 - 10MOQ: 1 Piece
Warranty
12 mouths
Cooling System
Air Cooling
After-sales Service
All time
Application
Home Appliance, Petroleum Machinery Manufacturing, Aerospace Industry, Automotive Industry
Structure Type
Gantry Type
Technical Class
Continuous Wave Laser
Laser Classification
Free Electron Laser
Applicable Material
Metal
Laser Technology
Other, Plasma
Categories
Cut to Length Line
Certification
CE,ISO
Condition
NEW
Type
Hydraulic Machine
Transport Package
Seaway packing
Specification
Z2CL-12X1600
Trademark
ZEYE
Origin
China
Jinan Zeye Machine Tool Co.,Ltd
Cell & Whatsapp no.:+86 13583106699
E-mail: 2485229105@qq.com
Website:
Jinan Zeye Machine Tool Co.,Ltd, Supply good quality steel coil slitting machine and cut to length line.
If you need cutter machine, please contact me directly.
Welcome you visit our company!
| Hot rolled uncoiling-Levelling-Cutting-Stacking production line | |||||
| Hot rolled plate,pickling palte,stainless steel plate,automobile plate,ship plate,ship plate. | |||||
| Optional pre-leveler,flip type stacking machine,mobile shears. | |||||
| Main Technical Parameters | |||||
| Model | ZCL-6 | ZCL-8 | ZCL-12 | ZCL-16 | ZCL-20 |
| Material thickness | 1.5-6 | 2.0-8.0 | 3.0-12.0 | 4.0-16.0 | 6-20/25 |
| Material Width | 800-2000 | 800-2000 | 800-2000 | 800-2200 | 800-2500 |
| Finished length | 1000-6000 | 1000-8000 | 1000-12000 | 2000-14000 | 2000-14000 |
| Length accuracy | 1 | 1 | 1 | 1 | 1 |
| Diagonal accuracy | 1 | 1 | 1.5 | 1.5 | 1.5 |
| Leveling accuracy | 1 | 1 | 1.5 | 1.5 | 1.5 |
| Line speed | 50m/min | 40m/min | 40m/min | 40m/min | 30m/min |
| Coil Weight | 20,30 | 20,30 | 20，35 | 20，35 | 20，35 |
| Cold rolled uncoiling-Slitting-Recoiling Production Line | |||||
| Cold-rolled plate,electrolytic galvanzied plate,hot dip galvanized plate,color-coated plate,aluminum plate,cooper plate. | |||||
| Optional double seat slitting machine,unloading arm | |||||
| Main Technical Parameters | |||||
| Model | ZCL-1 | ZCL-2 | ZCL-3 | ZCL-4 | |
| Material thickness | 0.2-1 | 0.3-2.0 | 0.4-3.0 | 0.5-4.0 | |
| Material Width | 300-1250 | 800-1600 | 800-1800 | 300-1800 | |
| Finished length | 300-3000 | 300-3000 | 300-4000 | 400-6000 | |
| Length accuracy | 0.3 | 0.3 | 0.3 | 0.3 | |
| Diagonal accuracy | 0.5 | 0.5 | 0.5 | 0.5 | |
| Leveling accuracy | 1 | 1 | 1 | 1 | |
| Line speed | 70m/min | 60m/min | 60m/min | 60m/min | |
| Coil Weight | 5.10.15 | 10.15.20 | 10.15.20 | 20.25.30 | |
