AU G170EG01 V.1 Core Parameters (Industrial Grade 17 ")
?? Basic information
Brand: AUO
Size: 17.0 " (diagonal line)
Resolution: 1280 × 1024 (SXGA)
Ratio of width to height: 5: 4
Panel Type: a-Si TFT-LCD, TN, Normal White, Transmissive [_ _ LINK _ ICON]
Status: Discontinued [_ _ LINK _ ICON]
?? Physical dimensions
Display Area: 337.92 × 270.336 mm (H × V)
Dimensions: 358.5 × 296.5 × 18 mm (W × H × D)
Weight: 1.35kg (typical)
Surface: fog surface + 3 H hardened coating
?? Optical parameters
Brightness: 350 cd / m2 (typical)
Contrast ratio: 800: 1 (typical)
Response time: 20 / 10 ms (Tr / Td, typical) [_ _ LINK _ ICON]
Viewing angle: 80 / 80 / 60 / 80 ° (up / down / left / right, CR ≥ 10)
Color: 16.7 M (6-bit + Hi-FRC), sRGB 93%
Backlight: WLED side entry, life ≥ 50,000h, built-in driver [_ _ LINK _ ICON]
Refresh rate: 60 Hz
?? Electrical & Interfaces
Interface: LVDS (2 channels, 8-bit), 30pin
Backlight interface: 6 pin (3806K-F06Y-03R) [_ _ LINK _ ICON]
Power consumption: 22 W (typical)
Power supply: 5 V / 12V (built-in driver)
??? Environment and Reliability
Working temperature: -30 ° C ~ + 85 ° C
Storage temperature: -30C ~ + 85C [_ _ LINK _ ICON]
Vibration: 1.5 G (14.7 m / s2) [_ _ LINK _ ICON]
RoHS compliance [_ _ LINK _ ICON]
