Applications
This machine is a widely utilized piece of process equipment in the pharmaceutical, food, chemical, and dairy industries, offering integrated functions for mixing, granulating, and drying.
Features
● The main unit incorporates the company's most advanced design concepts, utilizing powder granulation (mixing, granulating, and drying) to enhance material flowability.
● The entire operation is conducted within a closed, negative-pressure system.
● The equipment features a sealed sampling function.
● The air inlet control valve employs proportional regulation.
● The air inlet heating system offers a choice between electric heating and steam heating methods.
● The complete unit is equipped with an advanced WIP (Wash-in-Place) cleaning system.
● The entire machine complies with FDA and cGMP production requirements.
● Upon user request, the machine can be provided with a 10-Bar pressure-resistant (explosion-proof) design.
**Working Principle**
After being purified and heated, air is drawn into the lower section of the fluid-bed granulator-dryer by an induced draft fan. It passes through the distribution plate within the material bin, causing the material—whether fine powder particles or wet granules—to enter a fluidized state within the container. The material is then preheated and mixed by the purified, heated air. During the granulation phase, a binder solution is atomized and sprayed into the chamber, causing individual particles to agglomerate into clusters bound by the adhesive. As the hot air continuously dries the material, moisture within the clusters evaporates and the binder solidifies. This process repeats continuously, ultimately forming ideal, uniform, and porous spherical granules.
