Product Name: Wire Bending Tester
Product Model: JRF-XCWQSYJ
Technical Parameters:
Machine Dimensions: 500 (Width) * 450 (Depth) * 370 (Height)
Power Supply: Single-phase AC220V 50Hz
No connection for gas or water pipes
Bending Frequency: 1000 times/Min (Customizable)
Sample Wire Length: ≥150mm
Sample Wire Diameter: 10mm Max
Break Detection Voltage: DC 24V
Overall Voltage Input: AC220V
Overall Power: 750W
Equipment Usage Environment:
Temperature: 5-30℃
Relative Humidity: 35-85％RH (No condensation)
Atmospheric Pressure: 86-106Kpa
No strong vibrations around; No strong air currents around
No direct sunlight or strong light exposure, or direct radiation from other heat sources
No strong electromagnetic fields around
No dust or corrosive substances around (Best in a clean room)
Protective grounding wire should be connected separately and not shared with grounding wires of other equipment
Flat and well-ventilated floor
Adequate maintenance space should be left around the equipment
