Model: JRF-SL-0535
Overall dimensions: Length × Width × Height 255 × 205 × 155 (L×W×H)
Gross weight of equipment: 3kg
Power: 30W
Power supply: AC100-220V/50-60Hz
Blade material: High-speed tool steel
Slice thickness: 0.4 ≤ t ≤ 3mm
Sample wire outer diameter range: 0.5-3.5mm
Sample length range: ≥50mm
Usage conditions:
1. Ambient temperature: 0-40℃
2. Relative humidity: Below 75%
3. The air contains no corrosive gases, oil, steam, or severe dust
4. Good natural ventilation
Product Overview: The JRF-SL-3&80 slicer is a machine used to prepare cross-sectional samples of cable sheaths. These samples can be directly used by intelligent image measuring instruments to detect various characteristics of the cable sheath cross-section, thereby determining if the cable sheath meets the standard. This slicer features simple operation and reliable performance.
Model: JRF-SL-0512
Overall Dimensions: Length × Width × Height 435×200×250mm
Net Weight of Equipment: 2.5kg
Power: 20W
Power Supply: AC100-220V/50-60Hz
Blade Material: SUS304
Sample Diameter Range: 0.5~12mm
Sample Length Range: 35-50mm
Usage Conditions:
1. Ambient Temperature: 0-40℃
2. Relative Humidity: Below 75%
3. The air contains no corrosive gases, oil, steam, or severe dust
4. Good natural ventilation
Product Overview:
The JRF-SL-3&80 slicing machine is a device used to prepare cross-sectional samples of cable sheaths. These samples can be directly used by intelligent image measuring instruments to detect various characteristics of the cable sheath cross-section, thereby determining if the cable sheath meets the standard. This slicing machine features simple operation and reliable performance.
Model: JRF-SL-3&80
Overall Dimensions: Length × Width × Height 370×250×270mm
Net Weight: 5kg
Power: 65W
Power Supply: AC100-220V/50-60Hz
Blade Material: SUS304
Sample Diameter Range: 3-80mm
Sample Length Range: 25-45mm
Sample Wall Thickness Range: 1-20mm
Optimal Sample Cutting Thickness: ≤10mm
Usage Conditions:
1. Ambient Temperature: 0-40℃
2. Relative Humidity: Below 75%
3. The air contains no corrosive gases, oil, steam, or severe dust
4. Good natural ventilation
